Scan code: LN109168 Manufacturer code: UC3200

Synology Unified Controller UC3200

Synology Unified Controller UC3200, Active-Active IP SAN, Intel Xeon D-1521 Dual Controller, 12 Bay, Hot Swappable

Thumbnail 1 : Synology Unified Controller UC3200 Thumbnail 2 : Synology Unified Controller UC3200 Thumbnail 3 : Synology Unified Controller UC3200
Scan code: LN109168 Manufacturer code: UC3200
£6,119.99Item currently awaiting an ETA
Pre order
From £143.02 / month (APR 5.9%) or 0% for 4 months
Monthly Payment: £526.02
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £6,119.99
Total inc. interest: £6,312.15
Monthly Payment: £270.55
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £6,119.99
Total inc. interest: £6,492.99
Monthly Payment: £185.48
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £6,119.99
Total inc. interest: £6,677.21
Monthly Payment: £143.02
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £6,119.99
Total inc. interest: £6,864.79
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 21.9% and may be even lower.

Representative Example:

Purchase Rate: 21.9% p.a. (variable)

Representative: 21.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £152.86 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview

Delivering Reliable, Highly Available iSCSI Services

Realising high-availability architecture in just one single chassis, the two controllers in Synology UC3200 work simultaneously and can automatically fail over to each other in the event of disaster, delivering services without any interruptions.

12 x 3.5”/2.5” HDD/SSD

High-performance SAS interface drive slots with maximum 576TB raw capacity. Supporting SED (Self Encrypting Drive) to encrypt all data to hard drives, UC3200 provides upmost data security at the hardware level.

Active-Active Controller Module

Dual controller modules work simultaneously to provide high performance and non-disruptive iSCSI services.

Redundant Power Supply

Modularised and swappable 500W power supply prevents service downtime in the event of a power supply failure.

PCIe 3.0 slot

Further boost network bandwidth with optional 10GbE/25GbE network interface cards' expansion.

2 x 1GbE & 1 x 10GbE

Onboard RJ45 interfaces of 1GbE and 10GbE with the Link Aggregation support.

Mini-SAS HD port

Connect up to 2 x RXD1219sas for flexible plug-and-play volume expansion.


Armed with Intel® Xeon® D-1521 4-core 2.4 GHz processor burst up to 2.7 GHz, UC3200’s dual CPUs provide enterprise-class performance of 140,000 4K random write IOPS with low latency.

4 x DDR4 Memory Slots

8GB ECC UDIMM, expandable up to 64GB to boost system performance.


Redundant, modularised fans for easy maintenance and replacement, minimizing service downtime.


The dedicated SATA DOM isolates the operating system from the regular data stored in hard drives.

Non-Transparent Bridge (NTB)

Connect two controller modules at a blazingly fast speed and instantly sync memory data between the controllers to prevent cached data loss when one controller is unavailable.

Optimised for Virtualisation Environments

• Integrated with VMware vSphere® 6.5, Microsoft Hyper-V®, and VAAI to offload storage operations and optimize computational efficiency.
• Windows Offloaded Data Transfer (ODX) is supported to speed up data transfer and migration rates.
• Turn Synology UC3200 into a block-based storage component with the support of OpenStack® Cinder.
• Compliance with iSCSI industry standard ALUA allows hosts to identify the optimized paths to increase data transfer performance and efficiency.

A System Built Exclusively for iSCSI

DSM UC, an operating system designed to ease the learning curve, allows you to manage the two controllers from one single portal. The built-in monitor applications display the status at a glance and send prompt notifications when important events occur, so that IT administrators can stay alert to potential problems and respond in the shortest time possible.

Disaster-Proof Your Critical Data

Snapshot Replication is put in place with the support of Btrfs file system, offering scheduled and near-instantaneous data protection. Supporting up to 4,096 system-wide snapshots for local volumes or offsite servers, UC3200 brings application-aware snapshot protection and instant recovery of virtual machines in iSCSI LUNs in the event of a disaster.

• High performance, active-active storage solution to provide non-disruptive iSCSI services.
• Over 140,000 4K Random Write IOPS1, enterprise-class performance with low latency.
• Flexible capacity able to scale up to 36 drives with RXD1219sas expansion units.
• Virtualisation-ready with VMware vSphere®, Microsoft Hyper-V®, Citrix® XenServer and OpenStack® Cinder compatibility
• Resilient cache protection mechanism to prevent data loss.
• Instant data protection with built-in snapshot and replication technologies.
• Simple and unified user interface to effortlessly manage data and storage tasks.
Edition UC3200
NAS Form Factor
Bays 12 Bay
Total Storage Included N/A
Type of Drives Included
Edition of Drives Included
Capacity of Drives Included
Max. Storage Capacity 192 TB
Drive Interface Support
  • 1 x 2.5" SAS
  • 1 x 3.5" HDD
Drive Form Factor Support 1 x 2.5"/3.5"
Internal Flash Memory No
Internal Flash Memory Capacity
DOM Module No
DOM Capacity
CPU Type Intel Xeon
CPU Model D-1521
CPU Cores Quad Core
CPU Speed 2.4 GHz
RAM Memory Included
RAM Memory Type DDR4 ECC
Max. RAM Memory Supported 64GB (16x4GB)
Cache Drive Interface
Included Cache Drive Capacity
Included Cache Drive Type
LAN Type 1GbE + 10GbE
Expansion Slots
External Connectivity
Cooling Fan
Noise Level 51.3 dB(A)
PSU Type Redundant
PSU Wattage 500 W
Max. Power Consumption 417.48 W
Physical Security
Dimensions 430.5 x 88 x 692 (WxHxD mm)
Weight 19.7 kg
Additional Information
Scan Code LN109168
Model Number UC3200
GTIN 4711174723126
