Yamaha DXS18 800W 18" Powered Subwoofer
Yamaha - DXS18, 18" 800W (1020W Peak Power Capacity) Active Subwoofer
Active PA Subwoofer Speaker
Yamaha - DXS18
SERIOUS. BASS. PERFORMANCE.
For smaller venues or temporary sound reinforcement setups that require serious power with a professional edge, look no further than this compact powerhouse. The new DXS18 is equipped with an upgraded 1020W power amplifier producing an impressive 136dB and reaching as low as 32Hz producing clean, clear, heart-stopping bass that defies its lightweight construction.
Try selecting our D-XSUB “BOOST” or “XTENDED LF” low frequency processing settings, turn up the volume, and watch the eyes widen and jaws drop. All this in a small, easy to install enclosure. Listeners will need to search for the source of this much low frequency performance.
at a glance
• Optimized Bandpass Enclosure
•
Durable Line-X Elastomeric Coating
• XLR In and Thru Connectors
• M20 & 35mm Pole Sockets
• Integrated Handles
• D-XSUB Processing
Great Bass Sound Speaks For Itself. Period.
versatility, dependability, and powerIf you like your bass prominent and powerful, DXS Series high-output, powered subwoofers will ensure your bottom-heavy audio is heard loud and clear. Featuring high-efficiency Class-D amplifiers and a customized woofer housed in a sturdy plywood band-pass enclosure, DXS subwoofers are capable of delivering up to an impressive 1020W of distortion-free power with supreme clarity.
The lineup features the acclaimed DXS18 and recently upgraded versions of the 15” and 12” models, the DXS15mkII and DXS12mkII, which have adopted technologies and features from the DXS18 for an added professional edge and boost in performance. All feature Yamaha's state-of-the-art DSP, protection functions, and flexible crossover control allowing for seamless compatibility with Yamaha's vast lineup of full-range speakers, and reliable management of your bottom end.
We've worked tirelessly to develop subwoofers with this level of versatility, dependability, and power because for Yamaha, great bass is serious business. Make it your business too.
The Tech Spec
Features | Specification | Speaker type | 18" Powered subwoofer, Band-pass type |
---|---|
Frequency range (-10dB) | 32Hz – 120Hz |
ComponentsLF | 18" cone, Voice Coil:4" |
Output power | Dynamic:1020W / Continuous: 800W |
Max SPL | 136dB SPL |
I/O connectors | INPUT: XLR3-31 x2 , THRU: XLR-3-32 x 2(THROUGH or HPF POST) |
Processors | D-XSUB: BOOST, XTD LF, NORMAL |
Cooling | Natural convection |
Power requirements | 100V – 240V, 50Hz/60Hz |
Power consumption | 100W |
Pole socket | 35 mm (depth 80 mm) & M20 (threaded depth 25 mm) |
Dimensions | Width: 563mm (22.2") Height: 683mm (26.8") Depth: 721mm (28.4") |
Net weight | 49.7kg (110lbs) |
