Tascam US-2x2HR USB Desktop Audio Interface

Tascam US-2x2HR High-Resolution USB Audio Interface, 2 in / 2 out, iOS compatibility

Thumbnail 1 : Tascam US-2x2HR USB Desktop Audio Interface Thumbnail 2 : Tascam US-2x2HR USB Desktop Audio Interface Thumbnail 3 : Tascam US-2x2HR USB Desktop Audio Interface
Scan code: LN111929 Manufacturer code: US-2x2HR
£115.00Item currently awaiting an ETA
Pre order
From £10.42 / month (APR 16.9%) or 0% for 4 months
Monthly Payment: £10.42
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £115.00
Total inc. interest: £125.03
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

Representative Example:

Purchase Rate: 23.9% p.a. (variable)

Representative: 23.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

High-Resolution USB Audio Interface
Tascam - 'US-2x2HR'

Tascam US-2x2HR

includes Cubasis LE software!The gorgeous ‘US-2x2HR’ represents the mid-range of the new family of ‘US-HR’ series of high-resolution USB audio interfaces from Tascam. The US-2x2HR offers two mic/line/instrument switchable inputs and a pair of balanced line outs too, alongside MIDI I/O to both your Windows/Mac system and your iPad/iPhone. This is the ideal choice for those who seek simple operation and studio-quality sound, for music creation when recording at home.

full ios compatibilityThe tidy and compact US-2x2HR boasts a wealth of excellent features, such as 24-bit/192kHz sample rates, super-low latency, Ultra-HDDA mic preamps, ultra-low noise and a fantastic software package so you can be producing top-tier audio in no time at all! The interface is the ideal solution for mobile production or live streaming using your iPhone/iPad with the included Cubasis LE! In short, the US-2x2HR assists you in creating and distributing superb sounding audio, wherever your projects take you!

192kHzMax Sample Rate

20Hz – 40kHzFrequency Response

101dBS/N Ratio

• Advanced version of Tascam's popular US-2x2 with even greater sound quality
• Can be used with Windows, Mac, iOS, iPadOS
• Standard 6.3-mm headphones output
• Low-latency monitoring function

Outstanding Performance!

Tascam US-2x2HR

Ultra-HDDA microphone preamplifier!Such high resolution reproduction in the US-HR series has been achieved thanks to Tascam's tireless dedication to recreating sound as close to the original as possible. Therefore, the in-house developed Ultra-HDDA mic preamp combined with a newly improved audio circuit, delivers enhanced audio performance with the most transparent and low-noise sound!

world-renowned softwareThe US-HR models come bundled with world-renowned software that will enhance the user's production workflow. At the core of music production, Steinberg's Cubase LE/Cubasis LE 3 DAW is included, along IK Multimedia's Sample Tank SE, which comes free of charge with a massive 30 GB sound library encompassing more than 2,000 different musical instruments.

Perfect Podcast Prodution

Tascam US-1x2HR

handy Loopback function! For online broadcasting, Internet communication and other live streaming applications, the US-2x2HR interface offers a Loopback function which can blend signals coming from your computer (each can be set to mono or stereo) and send that mix to the broadcasting or other software on the computer.

A software slider allows to adjust the final “broadcast” volume independently from the unit’s line output level setting.

Tascam - 'US-2x2HR'

The Tech Spec

Features Specification
Maximum input level (Mic/Line/Inst) +10 dBu / +20 dBu / +10 dBV
Maximum input gain 56dB
Maximum output level +20 dBV
Mic preamp equivalent input noise −128 dBu
S/N ratio 108 dB / 110 dB
Distortion (THD+N, mic to computer) 0.0013%
Crosstalk ≥ 95 dB
Power supply USB / DC 5 V, 700 mA
Power consumption 1.75 W
Overall dimensions (W × H × D) 186 mm × 65 mm × 160 mm
Weight 1.1kg
Computer Interface Type USB 2.0 Type-C
Connections (Input)
  • 2 x 6.35mm (1/4") TRS - Insert
  • 1 x MIDI
  • 2 x XLR / Jack Combo
Mic Preamps (Max) 2
Instrument Inputs (Max) 2
Phantom Power Yes
Sample Rate (Max) 192 kHz
Bit Resolution 24
iPad Compatible Yes
Connections (Output)
  • 1 x Headphone (TRS 6.35mm Jack)
  • 1 x MIDI
  • 1 x Stereo TRS 1/4" Monitor Outputs
Dimensions (mm)
DSP Processing No
Misc. Notes
Additional Information
Scan Code LN111929
Model Number US-2x2HR
GTIN 4907034132751
