Neumann KH310-A Studio Monitor - Paired speakers

Product Overview The KH 310 is designed for use as a near-field monitor, as a front loudspeaker in mid-sized multi-channel system, or as a rear loudspeaker in a larger multi-channel system. It can be used in project, music, broadcast centers, OB vans, and post production studios for tracking, mixing, and mastering.

The KH 310 three-way analog active studio monitor features a Mathematically Modeled Dispersion™ Waveguide (MMD™), flexible acoustical controls, various input options, analog class-AB amplifiers, and an extensive range of mounting hardware. This allows the loudspeaker to be used in diverse acoustical conditions, with any source equipment and in a wide variety of physical locations. The KH 310 represents the latest in acoustic and electronic simulation and measurement technologies to ensure the most accurate sound reproduction possible. Features • 8 1/4" composite-sandwich membrane woofer, 3" soft dome midrange, 1" alloy fabric dome tweeter with Mathematically Modeled Dispersion™ (MMD™) Waveguide and protective grille
• 210 + 90 + 90 W class A/B-amplifiers with thermal protection
• Compact, sealed, horizontally-oriented enclosure (separate left and right versions)
• Frequency response: 34 Hz - 21 kHz, (-3 dB)
• Maximum SPL: 116.3 dB at 1m
• Input gain control, output level control, ground lift
• Fourth-order crossover and 4-position bass, low-mid and treble acoustical controls
• Self-generated noise level <0 dB(A) at 1 m
• Limiters: Excursion, Bass, Mid, Treble
• Independent thermo limiters for woofer, midrange dome and tweeter. Woofer soft clip and excursion limiters.
• Two-color dimmable Neumann logo
• Magnetic shielded
• XLR-balanced analog input
• Universal switched-mode power supply
• Dimensions: 253 x 383 x 292 mm (10" x 15 1/8" x 11 1/2") (HxWxD)
• Weight: 13.0 kg (28 lbs 11 oz)
• Full range of accessories and mounting hardware

Full Technical Specs


Measurements/Response Graphs
