Scan code: LN83103 Manufacturer code: NA381TB3

NetStor NA381TB3, 24 bay Storage, PCIe expansion

NetStor NA381TB3 4U 24 bay Thunderbolt™ 3 Combo SAS/SATA JBOD and PCIe Expansion Chassis with redundant 650W PSU

Thumbnail 1 : NetStor NA381TB3, 24 bay Storage, PCIe expansion Thumbnail 2 : NetStor NA381TB3, 24 bay Storage, PCIe expansion Thumbnail 3 : NetStor NA381TB3, 24 bay Storage, PCIe expansion
Scan code: LN83103 Manufacturer code: NA381TB3
£2,324.48Item currently awaiting an ETA
Pre order
With a 10% deposit from just £58.05 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Product Overview The Ideal Companion to Thunderbolt 3 Mac
Designed to have Thunderbolt™ 3 greatly 40Gbps high-bandwidth for the fastest ever data storage access and operation with multiple professional PCIe cards, which meant to be the perfect companion to your empowered Thunderbolt Mac or workstation.

The Netstor NA381TB3 is the Ideal Companion the Thunderbolt 3 Mac offering a massive storage solution of 4U 24 bays (3.5"/2.5") of Thunderbolt™ 3 Storage and PCIe Expansion this takes your MacBook Pro to the next level of System storage which is perfect for video editing and production. Based on the application and demands, users and professionals are able to choose their own desired brand, model of RAID card in the Thunderbolt™ 3 rackmount storage to work.

By utilizing a twenty-four port RAID adapter card inside, the Netstor JBOD immediately turns into an enterprise RAID storage with RAID level protection including 0, 1, 10, 3, 5, 6, 30, 50, and 60. Not only that but also provides three PCIe 3.0 slots within the storage chassis that allow the users to make an easy expansion of varied specialty PCIe cards to the Thunderbolt 3 Mac. Except the necessary RAID adapter card to be added, the professionals can still choose to attach two more pro cards such as video capture, video transcoding, audio accelerator, network card and so on in the NA381TB3 to add extra performance to Thunderbolt Mac.

Built for 24/7 Operation Application The built-in server-grade 650W redundant PSU ensures application running 24/7 with no system downtime to continuously working with the Thunderbolt 3 Mac server.

The Netstor NA381TB3 Comes with Dual Thunderbolt 3 Ports - using these two Thunderbolt™ 3 (USB-C) ports, users can have the first port to computer while the second port to daisy-chain of up to five additional Thunderbolt peripheral devices with two 4K displays or one 5K display being positioned at the very end of the chain. USB 3.1 Gen 2 (10Gbps) is also supported: connecting one USB device to the second port for application is available.

Mac certified, Working with All Series of Thunderbolt Mac
The Thunderbolt™ 3 NA381TB3 has passed Apple's strict certification test process and is Mac certified, working with all series of Thunderbolt Mac.
Features Host Interface
Thunderbolt™3 (Dual Port USB-C for Daisy Chain)
Data Transfer Rate 40Gbps

HDD Interface
SAS/SATA (6G/3Gbps)

RAID Levels
Requires a RAID card with internal 24 port and Thunderbolt driver(RAID card sold separately)

Power Supply
650W Redundant PSU (High-Efficiency & Low Noise)
Input: 90-230 VAC/50-60 HZ
Output: +5V and +12V

System Support
MacBook Pro(2016) with a Thunderbolt 3 port using Mac OS X 10.12.3 above

Note: Thunderbolt 2 Mac will request a Thunderbolt 3(USB-C) to Thunderbolt 2 adapter from Apple.

PCIe card Driver Request
Third-party PCIe card should support Mac OS with Thunderbolt aware's driver

PCIe card Size Available
Card length within 305mm and full height PCIe card

Package Content
Enclosure x 1
HDD Tray x 24 (Installed)
Internal miniSAS cable x 6
Thunderbolt3-40Gbps cable x 1 (2 meter)
Hard Disk Drive mounting screw x 96
Key for HDD tray x 2
Power Cord x 2
Specifications
NAS Form Factor 4U Rackmount
Bays 24 Bay
Storage (Included) N/A
Max. Storage Capacity
HDD Interface 24 x SAS 3 (12Gbps) / SATA 3 (6Gbps)
HDD Form Factor 24 x 3.5"/2.5"
Internal Flash Memory No
Internal Flash Memory Capacity
DOM Module No
DOM Capacity
CPU
CPU Model
Cores
CPU Speed
RAM Memory Included
RAM Memory Type
Max. RAM Memory Supported
Cache Drive Interface
Included Cache Drive Capacity
Included Cache Drive Type
LAN Type N/A
Expansion Slots 3 x PCIe 3.0 x8
External Connectivity 2 x Thunderbolt 3 / USB 3.1 Gen2 Type-C
Cooling
Noise Level
PSU Type Redundant
PSU Wattage 650 W
Max. Power Consumption 650 W
Dimensions 482 x 176 x 559 (WxHxD mm)
Weight
Additional Information
Scan Code LN83103
Model Number NA381TB3
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
1 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
Scan
