Scan code: LN116021 Manufacturer code: 6NG492HA0MR-00

Gigabyte G492-HA0 3rd Gen Xeon Ice Lake 4U 10 GPU Barebone Server

Gigabyte G492-HA0 3rd Gen Intel Xeon Dual Processor Barebones Server, 4U, 10x GPU, 12x Hot-Swap Bays, 2x 10Gb/s RJ45

Thumbnail 1 : Gigabyte G492-HA0 3rd Gen Xeon Ice Lake 4U 10 GPU Barebone Server Thumbnail 2 : Gigabyte G492-HA0 3rd Gen Xeon Ice Lake 4U 10 GPU Barebone Server Thumbnail 3 : Gigabyte G492-HA0 3rd Gen Xeon Ice Lake 4U 10 GPU Barebone Server Thumbnail 4 : Gigabyte G492-HA0 3rd Gen Xeon Ice Lake 4U 10 GPU Barebone Server
Scan code: LN116021 Manufacturer code: 6NG492HA0MR-00
£6,239.99Item currently awaiting an ETA
Pre order
From £170.43 / month (APR 14.9%)
Monthly Payment: £560.19
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £6,239.99
Total inc. interest: £6,722.20
Monthly Payment: £299.51
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £6,239.99
Total inc. interest: £7,188.27
Monthly Payment: £213.18
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £6,239.99
Total inc. interest: £7,674.32
Monthly Payment: £170.43
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £6,239.99
Total inc. interest: £8,180.18
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 21.9% and may be even lower.

Representative Example:

Purchase Rate: 21.9% p.a. (variable)

Representative: 21.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £155.85 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Product Overview

3rd Gen Intel® Xeon® Scalable Processors

GIGABYTE servers and Intel Xeon Scalable Processors deliver incredible 1P/2P performance from edge to data centre with incredible gains in I/O throughput and workload demands that need high performing CPUs with large, yet optimise, memory configurations.

Enhanced I/0:
Support for PCIe 4.0 allows for double the throughput of PCIe 3.0 for fast and large data transfers. Also, 64 lanes per socket with up to 128 lanes in a 2P configuration for fast data transmission from CPU to GPU, accelerator or storage.

CPU Performance Boost:
Now up to 40 cores per socket with greatly improved IPC on Intel’s 10nm architecture while operating CPUs at 105-270C. Also, an additional UPI lane is added for up to 11.2GT/s for a low latency interconnect between CPUs.

Next Gen Memory:
Support for DDR4-3200MHz (1DPC or 2DPC) DIMM. 8 channel memory has been added with up to 16 DIMMs per socket delivering up to 4TB of system memory via usage of 256GB DDR4 DIMM. Additionally, 2/4/6/8-way interleaves for optimal configuration.

Arrival of Intel Optane PMem 200 Series:
Optimised for improvements in latency while increasing system memory up to 6TB per socket as a mix of PMem and DDR. The 200 Series also has support for memory mode to expand capacity and app direct mode to act as fast flash storage.

Next Level Security:
New instructions and architecture deliver a high level of cryptographic operations for data privacy and protection. Cryptographic accelerators speed up encryption protocols as well as improvements in software guard extensions and memory encryption are added.

AI Acceleration:
AI inference and training are enhanced with DL Boost Technology for greater business, operational, and security insights. Applications include HPC, AI, and Media & Graphics.


Certified Ready with Software Partners

Being a member of key software alliance partner programs enables GIGABYTE to together rapidly develop and validate joint solutions, enabling our customers to modernise their data centres and implement IT infrastructure and application services with speed, agility, and cost optimisation. GIGABYTE servers have a compatibility across various ecosystems.


Support Various Computing Accelerators

GIGABYTE servers have been tested and validated across a range of workloads with various computing accelerators designed to deliver high levels of performance for deep learning, high performance computing (HPC), enabling data scientists, researchers, and engineers to tackle challenges that were once impossible.

Features
• Up to 10 x PCIe Gen4 GPU cards.
• 3rd Gen. Intel® Xeon® Scalable Processors.
• 8-Channel RDIMM/LRDIMM DDR4 per processor, 32 x DIMMs.
• Intel® C621A Express Chipset.
• Dual ROM technology supported.
• Supports Intel® Optane™ Persistent Memory 200 series.
• 2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2).
• 1 x dedicated management port.
• 4 x 3.5" or 2.5" SATA/SAS hot-swappable HDD/SSD bays.
• 8 x 3.5" or 2.5" SATA/SAS/Gen4 NVMe hot-swappable HDD/SSD bays.
• 3 x low profile PCIe Gen4 expansion slots.
• 1 x OCP 3.0 Gen4 x16 mezzanine slot.
• 3 x 80 PLUS Platinum 2200W (240V) redundant PSU.
Specifications
Edition G492-HA0
Form Factor 4U
CPU Included No
CPU Type 2x Intel Xeon Scalable Processors
CPU Model
Architecture Ice Lake
Manufacturing Process 10 nm
Unlocked CPU No
Core
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
Max. TDP upto 270 W
CPU Socket 4189
Chipset Intel C621A Express
Motherboard Form Factor Bespoke/Custom
Motherboard Model MG62-G41
Memory Type DDR4 RDIMM/LRDIMM
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels Octa (8)
Memory Type (ECC)
Memory Type (R/U) RDIMM / RDIMM 3DS / LRDIMM / LRDIMM 3DS
Memory Speed (Mhz)
  • DDR4 - 2666
  • DDR4 - 2933
  • DDR4 - 3200
Max. Memory Capacity
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip Aspeed® AST2600
Discrete GPU No
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration No
Max. GPU Resolution
Graphics Interface PCIe 4.0 (x16)
Expansion Slots
  • 10 x PCIe 4.0 x16
  • 3 x PCIe 4.0 x16, LP, HL
  • 1 x PCIe Gen 4.0 x 16, OCP 3.0
SATA SATA3
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
Optical Drive None
Drive Bays
  • 8 x 2.5"/3.5" SATA/SAS/Gen4 NVME Hotswap
  • 4 x 2.5/3.5" SAS/SATA Hot-swap
Backplane I/O 12 x SAS-3 (12Gb/s)/SATA3 (6Gb/s) Ports (Rear)
RAID Support Intel® SATA RAID 0/1/10/5
Internal I/O
  • 1 x Front VGA Connector
  • 1 x Serial (COM) Header
  • 1 x TPM Header
  • 1 x VROC Connector
Network Interface Type Dual Wired 10G LAN + Mgmt LAN
Network Chip/Modules
  • 2 x Intel® X550-AT2 (10GbE LAN)
  • 1 x Mgmt LAN (10/100/1000)
Front Panel
  • 1 x ID button with LED
  • 1 x MLAN
  • 1 x NMI button
  • 1 x Power Button with LED
  • 1 x Reset Button
  • 2 x RJ45
  • 1 x System Status LED
  • 2 x USB 3.0
  • 1 x VGA
Back Panel
Cooling Fans
  • 4 x 40mm
  • 6 x 60mm
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 2200 x 3 W
PSU Efficiency Rating 80 PLUS Platinum
PSU Redundancy N/A
Operating System Included No
Operating System N/A
Colour
Dimensions 448 x 176 x 880 (mm WxHxD)
Weight
Includes
  • 1 x Barebone Server
  • 2 x CPU Heatsink/s
  • 1 x Rail Kit
  • 1 x VROC Module
Notes
Storage Drives
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Additional Information
Scan Code LN116021
Model Number 6NG492HA0MR-00
GTIN 1
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Direct
DOA Period:
28 days
RTB Period:
28 months
Manufacturer Contact Details
Manufacturer:
Gigabyte Uk
Gigabyte G492-HA0 3rd Gen Xeon Ice Lake 4U 10 GPU Barebone Server
