Earthquaker Devices Hummingbird V4 Repeat Percussions Tremolo

Earthquaker Devices Hummingbird V4 Repeat Percussions Tremolo Effects Pedal, 3 Modes, Flexi-Switch, True Bypass

Thumbnail 1 : Earthquaker Devices Hummingbird V4 Repeat Percussions Tremolo Thumbnail 2 : Earthquaker Devices Hummingbird V4 Repeat Percussions Tremolo Thumbnail 3 : Earthquaker Devices Hummingbird V4 Repeat Percussions Tremolo Thumbnail 4 : Earthquaker Devices Hummingbird V4 Repeat Percussions Tremolo Earthquaker Devices Hummingbird V4 Repeat Percussions Tremolo : video thumbnail 1
Scan code: LN97098 Manufacturer code: EQDHBV4
£163.97
Free Delivery
spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 23rd Aug 2019 to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview The Hummingbird is a choppy, sawtooth tremolo modeled on the vintage “repeat percussion” unit and similar to those found in old Valco and Vox amplifiers. It is capable of producing everything from classic “50’s style” shimmering tremolo to a synthy, delay-like chop that turns your signal into a burst of short pings and on through to near ring modulation speeds. Simply choosing between modes 1 (slow), 2 (mid-tempo) or 3 (fast) and adjusting the rate and depth controls will unlock a whole new world of amplitude modulation at your feet. The Rate is also expression pedal accessible to allow instant changes on the fly. Using an expression pedal opens up the possibility of true random amplitude modulation! In addition to the modulation, the Hummingbird has plenty of clean gain on-tap allowing you to either boost or cut the signal using the level control. If the Depth is turned to zero, the Hummingbird will become a JFET clean boost!

More information can be found in the User Manual below:
Data Sheet Features Controls
• Depth: This adjusts how much the oscillator affects the signal. All the way clockwise produces a full chop, all the way counterclockwise produces no chop and the Hummingbird can be used as a simple JFET booster.
• Mode: Three way toggle switch which selects the range of the oscillator. Mode 1 is slow, Mode 2 is mid tempo and Mode 3 is fast.
• Rate: This adjusts the speed of the oscillator. Faster clockwise, slower counterclockwise.
• Level: Adjusts the output volume
• Expression Jack: Use an expression pedal to adjust the rate with your foot! When an expression pedal is in use the Rate control is defeated. We recommend the Moog EP-2 expression pedal.

Tech Specs
• Measures: 4.75" x 2.50" x 2.25" with knobs
• Current Draw: 10mA
• Input Impedance: 50K Ohm
• Output Impedance: <10K Ohm
• Flexi-Switching: This device features Flexi-Switch™ Technology! This relay-based, true bypass switching style allows you to simultaneously use momentary and latching style switching. Since the switching is relay based, it requires power to pass signal.
- For standard latching operation, tap the footswitch once to activate the effect and then tap again to bypass.
- For momentary operation, hold the footswitch down for as long as you’d like to use the effect. Once you release the switch the effect will be bypassed.
• Power: For best results, please use the included 9v center-negative 1-amp DC power supply.
