BOSS - RC-505MKII Loop Station

BOSS - RC-505MKII Loop Station, Five Simultaneous Stereo Phrase Tracks with Dedicated Controls and Independent Faders

Thumbnail 1 : BOSS - RC-505MKII Loop Station Thumbnail 2 : BOSS - RC-505MKII Loop Station Thumbnail 3 : BOSS - RC-505MKII Loop Station
Scan code: LN129687 Manufacturer code: RC-505MKII
Order in the next 29 mins and get it tomorrow
Get it Tomorrow, 26 JulIn stock
From £21.93 / month (APR 16.9%) or 0% for 4 months
Monthly Payment: £40.68
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £449.00
Total inc. interest: £488.12
Monthly Payment: £21.93
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £449.00
Total inc. interest: £526.14
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

Representative Example:

Purchase Rate: 23.9% p.a. (variable)

Representative: 23.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £11.93 / month (APR 19.9%)
Delivery Options
  • By DPD On 26th Jul to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Loop Station


Looping Magic at Your FingertipsThe BOSS RC-505mkII loop station comes packed with inspiring features for on-the-spot music creation. Brining next-generation power and flexibility to the world’s most popular tabletop looper, you can enhance your performances with five stereo tracks and four simultaneous Input FX and Track FX, and go even further with customizable buttons, expanded I/O, more mixing control, and other improvements requested by long-time RC-505 users. Designed for free-flowing expression on stage and in the studio, the RC-505mkII is a dream come true for beatboxers, vocalists, multi-instrumentalists, and other aspiring looping artists.

At A Glance • The industry-standard tabletop looper, updated and enhanced
• Input FX and Track FX sections, each with four simultaneous effects and four quick-access banks
• Five simultaneous stereo phrase tracks with dedicated controls and independent volume faders
• Class-leading sound quality with 32-bit AD/DA and 32-bit floating-point processing
• Customizable FX and Track buttons for each phrase track

Multiple New Features


More To LoveThe RC‐505mkII includes everything that made the original so highly rated, with an extra range of new features to make the looping experience even more creative and free flowing. The faders offer longer throw for finer adjustments and have a more solid feel under the fingers.

Each track now has dedicated FX and Track buttons, so it's easier to colour and control your loops in the heat of the moment. Undo/redo has also been further developed with a Mark Back function that lets you instantly jump back to a previous loop state while performing.

Customize Your Workflow


Double Your OptionsAlthough the original RC‐505 was very customizable, the RC‐505mkII takes things to the next level with a wider range of configurable controls. You can assign various CTL parameters to the FX and Track buttons and trigger them with a press, hold, or double‐click.

Pressing the Undo/Redo button reveals a secondary layer, doubling your options. Two external control jacks are also available for connecting footswitches or expression pedals, each with their own dedicated set of parameters. If you still want more, tap into the Assign screens to set up 16 different targets for hardware control and MIDI operation.

More Sonic Colours for Inspired Looping


Greater OptionsSonic variety helps make loop performances more compelling, and the RC‐505mkII provides a greatly expanded FX palette to colour your sounds during recording and playback. There are 49 Input FX and 53 Track FX types to go between, including powerful new vocal harmony effects, with the option of using up to four in each section at once.

In addition, groups of four Input FX and Track FX can be stored in four banks for quick recall, along with toggle or momentary button settings for each type. A step sequence function is also available in some FX to automate parameter changes for dynamic real‐time movement.

Connect & Mix


Extensive ConnectivityWith the RC‐505mkII’s extended connectivity and onboard audio processing, you can do more using less external gear. You have two XLR inputs for mics and two mono/stereo line input pairs for instruments and other devices, plus an input mixer with two mic compressors and independent EQs for all channels.

Three stereo output pairs and an output mixer are also available, together with assignable routing options and master reverb and compressor effects. You can also customize the headphones output to monitor individual tracks and rhythm sounds. And by using USB, you can integrate with computer DAWs and use BOSS Tone Studio to import/export WAV loops.

Creative Details


Quicker workflowTo meet the unique workflow demands of different performers, the RC‐505mkII offers many new creative details inspired by longtime Loop Station users. Three different overdub modes are available, including one that lets you replace the current sound in a loop track while it’s playing, and a new Bounce In function for capturing multiple tracks into one.

Half and double speed options are also on hand, and you can freely change the overall playback speed with or without pitch change. It is now also possible to assign the Auto Rec function to a panel button or footswitch for quick activation whenever you need it.

BOSS RC-505mkII Loop Station
Official Launch Video in collaboration with SBX

The Tech Spec

Features Specification
Sampling Frequency 44.1 kHz
AD/DA Conversion 32 bits
Processing 32-bit floating point
Recording/Playback Number of Tracks: 5
Data Format: WAV (44.1 kHz, 32-bit float, stereo)
Maximum Recording Time: Approx. 1.5 hours (1 track), Approx.13 hours (total of All memories)
Rhythm Type 200 types or greater
Rhythm Kit 16 types
Effect INPUT FX: 49 types
TRACK FX: 53 types
MASTER FX: 2 types
Memory 99
Nominal Input Level MIC 1, 2 INPUT: -40 dBu
INST 1, 2 INPUT: -10 dBu
Maximum Input Level MIC 1, 2 INPUT: 0 dBu
IINST 1, 2 INPUT: +7 dBu/+20 dBu (selectable)
Input Impedance MIC 1, 2 INPUT: 3k ohms
INST 1, 2 INPUT: 1 M ohms/25 k ohms (selectable)
Nominal Output Level MAIN OUTPUT: -10 dBu
SUB 1, 2 OUTPUT: -10 dBu
Maximum Output Level MAIN OUTPUT: +7 dBu
SUB 1, 2 OUTPUT: +7 dBu
Output Impedance MAIN OUTPUT: 1 k ohm
SUB 1, 2 OUTPUT: 1 k ohm
Recommended Load Impedance MAIN OUTPUT: 10 k ohms or greater
SUB 1, 2 OUTPUT: 10 k ohms or greater
Controls TRACK1--5 REC/PLAY button, TRACK1--5 STOP button, TRACK1--5 TRACK button, TRACK1--5 FX button, ALL START/STOP button, UNDO/REDO button, TAP TEMPO button, RHYTHM START/STOP button, RHYTHM EDIT button, INPUT FX A--D button, INPUT FX EDIT button, TRACK FX A--D button, TRACK FX EDIT button, MENU button, LOOP button, ENTER button, EXIT button, PAGE buttons, 1--4 knobs, OUTPUT LEVEL knob, TRACK1--5 LEVEL Faders
Display Graphic LCD (128 x 64 dots, backlit LCD)
Connectors MIC IN 1, 2 jack: XLR type (balanced, phantom power: DC 48 V, 10 mA Max
INST IN 1, 2 jacks, MAIN OUT jacks, SUB OUT 1, 2 jacks: 1/4-inch phone type
PHONES jack: Stereo 1/4-inch phone type
CTL1,2/EXP1 jack, CTL3,4/EXP2 jack: 1/4-inch TRS phone type
USB port: USB B type
MIDI (IN, OUT) connectors
DC IN jack
Power Supply AC adaptor
Current Draw 1.0 A (with phantom power)
0.9 A (without phantom power)
Accessories AC adaptor
Owner's Manual
Options (sold separately) Footswitch: FS-5U
Dual Footswitch: FS-6, FS-7
Expression Pedal: FV-500H, FV-500L, EV-30, Roland EV-5
Dimensions Width: 420 mm/16-9/16 inches
Height: 67 mm/2-11/16 inches
Depth: 234 mm/9-1/4 inches
Weight 1.8 kg
4 lbs
Voltage PSU (Included) Volts
Current 1.0 mA
Battery Compartment No
Output Channels Mono
Dimensions 420x67x234 mm (W x H x L)
Passive Pedal No
Impedance High
Additional Information
Scan Code LN129687
Model Number RC-505MKII
GTIN 761294516980
