Product Overview

Scalable, High Performance 1U Server

ASUS RS700-E10-RS12U is a server powered by 3rd Gen Intel Xeon Scalable processors that supports up to 32 DIMMs, one dual-slot GPU, 12 NVMe, three plus one PCIe slots, optional OCP 3.0 slot, dual M.2 and ASUS ASMB10-iKVM.


3rd Gen Intel Xeon Scalable processors

The latest Intel Xeon scalable processors offer up to 1.42x more cores per CPU and 1.52x computing performance increase. ASUS RS700-E10-RS12U supports dual Intel Scalable processors to enable up to 32 DIMM slots, all flash and PCIe Gen 4.0.


PCIe 4.0 Ready

PCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility.


GPU and FPGA Support

Up to one dual-slot GPU card such as NVIDIA A100 in one 1U system and optimized acceleration for workloads across cloud, data centre and for hybrid cloud environment.


Cooling Solutions

Air or liquid-cooled solutions. Asetek's Direct-to-Chip (D2C) liquid-cooling technology achieving lower power-usage effectiveness (PUE) and optimized TCO for data centres.


Enhanced Security

PFR FPGA as the platform Root-of-Trust solution for firmware resiliency Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.

Features


• Powered by dual-socket 3rd Gen Intel Scalable processors, with 32 DIMMs and support for a maximum TDP of up to 270 W per socket.
• GPU-optimized design allows one dual-slot GPU for AI workloads.
• Up to 12 all-flash NVMe drives on front panel to enable extensive storage and high-throughput performance.
• Up to three PCIe® 4.0 slots to enable higher bandwidth and improved data-transfer rates.
• Flexible onboard LAN-module design to enable four 1 Gb LAN or two 10 Gb LAN options.
• Flexible air- and liquid-cooling solution to achieve lower power-usage effectiveness (PUE) and optimized TCO for data centres.
• Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller.
• Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency.
• High power efficiency with redundant 1600 W or 1200 W 80 Plus® Titanium/Platinum power supplies.

Specifications
Edition RS700-E10-RS12U
Form Factor 1U Rackmount
CPU Included No
CPU Type 2x Intel Xeon Scalable Processors
CPU Model
Architecture Ice Lake
Manufacturing Process 10 nm
Unlocked CPU No
Core
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
TDP 270 W
CPU Socket 4189
Chipset Intel C621A Express
Motherboard Form Factor Proprietary
Motherboard Model
Memory Type DDR4 RDIMM/LRDIMM
Memory Included No
Memory Capacity Included RAM Memory Not Included - Please Buy Separately
Memory Edition
Memory Channels Octa (8)
Memory Type (ECC) ECC/Non-ECC
Memory Type (R/U) RDIMM / LRDIMM / LRDIMM 3DS
Memory Speed (Mhz)
  • DDR4 - 2933
  • DDR4 - 3200
Max. Memory Capacity
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip Aspeed® AST2600
Discrete GPU No
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration No
Max. GPU Resolution
Graphics Interface PCIe 4.0 (x16) [PCIe 3.0 Backwards Compatible]
Expansion Slots 4 x PCIe 4.0 x16
SATA SATA3 / M.2
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Optical Drive None
Drive Bays 12 x 2.5"/3.5" NVMe/SATA/SAS Hot-Swap (Front)
Backplane I/O
RAID Support
Internal I/O N/A
Network Interface Type
Network Chip/Modules
  • 4 x Gigabit LAN
  • 1 x Intel® X710-AT2 (10G LAN)
  • 1 x Mgmt LAN
Front Panel
  • 1 x HDD Activity LED
  • 1 x Location LED
  • 1 x Power Switch with LED
  • 1 x Reset Switch
Back Panel
  • 2 x 10/100/1000 (LAN)
  • 1 x D-Sub (VGA)
  • 1 x Location LED
  • 1 x Message LED
  • 1 x Power Switch with LED
  • 1 x Q-Code/Port 80 LED
  • 1 x RJ-45 Mgmt LAN
  • 2 x USB 3.2 Gen1 Type-A
  • 1 x VGA
Cooling Fans
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 1600 W
PSU Efficiency Rating 80 PLUS Titanium
PSU Redundancy 1+1
Operating System Included No
Operating System N/A
Colour
Dimensions 842.5mm x 43mm x 439.5mm (mm WxHxD)
Weight 13.7 kg
Includes
Notes
Additional Information
Scan Code LN119227
Model Number 90SF0153-M00320
GTIN 4711081361671
