Noctua NH-C14S CPU Cooler - 140mm

140mm Noctua NH-C14S Top-Flow CPU Cooler, NT-H1 Thermal Compound, 140mm NF-A14 Fan, SecuFirm2™
MORE INFO

MORE INFO

Scan code: LN65215 Manufacturer code: NH-C14S

£79.99

Thermal Grizzly Aeronaut Thermal Paste - Worth £8 MSRP - LN143471 - One Per Customer

£5.48 NEXT DAY DELIVERY

Order now and receive it by Friday, 13th December

Add To Basket

Get it Friday, 13 DecIn stock

By DPD On 13th Dec Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
UPS and DPD Pickup Pickup from local convenience store | £4.79 Collect your parcel from your newsagents, petrol stations and convenience stores

Spend over £280.00 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.

0% UP TO MONTHS Spend £99 or more and choose PayPal at checkout. More info
SCANPROTECT Protect against installation damage for 28 days. More info

Frequently Bought Together

LN65215 Noctua NH-C14S CPU Cooler - 140mm £79.99
LN53109 Noctua NF-A14 PWM 140mm Premium Case Fan with AAO £24.98
LN59515 Noctua NF-S12A 120mm PWM Cooling Fan £21.98
Total Price:
£

Product Overview

Based on the Award-Winning NH-C14

Having received more than 200 awards and recommendations from leading international hardware websites and magazines, the NH-C14 has become an established reference for 140mm top-flow coolers. With its deeper fin stack and more efficient NF-A14 PWM fan, the new S-version provides similar performance and further improved compatibility.

C-Type Top-Flow Design

The c-type top-flow design of the NH-C14S not only allows for superb quiet cooling performance while maintaining a much lower profile than today’s 140mm tower-style coolers but also ensures excellent airflow over RAM modules and near-socket motherboard components.

Low Profile Mode

Run with the NF-A14 fan installed underneath the fin stack, the NH-C14S stands only 115mm tall, which is much lower than tower coolers with 140mm or 120mm fans and allows it to fit many desktop style or HTPC cases.

High Clearance Mode

Run with the NF-A14 fan installed on top, the NH-C14S provides extended clearance underneath the fin stack. This way, it is fully compatible with chipset coolers and RAM modules with heat-spreaders of up to 70mm height.

Offset Design for PCIe Clearance

Compared to the original NH-C14, the layout of the NH-C14S has been offset in two axis. Thanks to this measure, the heatsink will clear the top PCIe slot on most micro-ATX and ATX motherboards when the bendings of the heatpipes face the PCIe slots or the I/O panel.

NF-A14 140mm Premium Fan

Featuring sophisticated aerodynamic optimisations such as Flow Acceleration Channels, the NF-A14 is renowned to be among the best quiet 140mm fans on the market. Combined with the deeper fin stack of the NH-C14S, it allows the cooler to achieve similar performance levels as its dual fan predecessor despite only using a single NF-A14.

PWM Support and Low-Noise Adaptor

The NF-A14 premium fan supplied with the NH-C14S supports PWM for convenient automatic speed control through the motherboard. In addition, the maximum fan speed can be reduced from 1500 to 1200 RPM using the supplied Low-Noise Adaptor for even quieter operation.

SecuFirm2 Mounting System

Noctua’s SecuFirm2 mounting systems have become synonymous with quality, safety and ease of use. Supporting Intel LGA115x (LGA1150, LGA1151, LGA1155, LGA1156), LGA2011 (LGA2011-0 & LGA2011-3), LGA2066 and AMD (AM3(+), AM2(+), FM1, FM2(+)), the SecuFirm2 mounting included with the NH-C14S guarantees perfect contact pressure and maximum convenience on all current sockets.

Compatibility with Past and Future Sockets

Complying with the open SecuFirm standard, the NH-C14S can be made compatible with the older LGA1366 and LGA775 sockets using the optional NM-I3 mounting kit, which is provided by Noctua free of charge. If technically possible, Noctua will also provide upgrade kits for future sockets.

NT-H1 Thermal Compound

Having received more than 100 awards and recommendations from hardware journalists around the world, Noctua’s NT-H1 is a proven professional grade TIM solution that provides minimum thermal resistance, excellent ease of use and outstanding reliability.

Six Years Warranty

Noctua products are renowned for their impeccable quality and outstanding longevity. Like all Noctua fans, the supplied NF-A14 features an MTBF rating of more than 150,000 hours and the entire NH-C14S package comes with a full six years manufacturer’s warranty.

Features • Six heatpipe C-type design.
• NF-A14 140mm fan supplied.
• Low profile option.
• Excellent component cooling.
• SecuFirm2 multi-socket mounting system.
• NT-H1 thermal compound.
• Compatible with Intel LGA2011/1150/1/5/6/ and AMD FM1/FM2+/AM3+/AM3/AM2+/AM2.

Specifications

Cooler Specifications
Edition	NH-C14S
Cooler Form Factor
Heatpipes	6
Cooler Features	Aluminium Fins Copper Base Copper Heatpipes
Socket Compatibility	1150 1151 1155 1156 1700 1851 2011 2011-3 2066 AM2+ AM3+ FM1 FM2+
Max. TDP

Fan Specifications
Included Fan Configuration	1 x 140mm
Fan Edition
PWM Fan	Yes
Fan Bearing Type	SSO2
Fan Colour	Beige/Brown
LED Lighting
Fan/Pump Connectors
Max. Fan Speed	1500 rpm
Max. Fan Airflow	82.5 CFM
Max. Air Pressure
Max. Sound Level	24.6 dBA

Materials
Cooler Materials	Aluminium / Copper
Included TIM (Thermal Interface Material)

Dimensions & Weight
Heatsink/Radiator Dimensions	140 x 142 x 163 mm (WxHxD)
Total Dimensions
Weight	1015 g

Additional Information
Scan Code	LN65215
Model Number	NH-C14S
GTIN	4716123315698

Buying Guide

Need help? Read our Air Cooling Buying Guide

Intel Branding Part I
Date Issued: 1st Jul 2009

Intel’s been on a mission of late. That mission revolves around grouping and standardising key technologies under various banners that are designed to ensure hardware compatibility and consumer ease of use. We’ll take a closer look at three such technologies that fall under the headings of Centrino, Viiv, and vPro, respectively.

Intel Core 2 Duo (Conroe)
Date Issued: 20th Oct 2008

The purpose of this TekSpek is to delineate the publicly known features of Intel’s next generation desktop microarchitecture. Codenamed Conroe and officially titled Intel Core 2 Duo, it’s loosely based on the current mobile Yonah (Core Duo) underpinnings.

AMD AM2
Date Issued: 20th Oct 2008

The purpose This TekSpek quickly and easily explains AMD’s new processor socket and related technology to the reader, comparing it to AMD’s previous socket types.

AMD 64 Processors
Date Issued: 20th Oct 2008

This TekSpek explains what AMD’s AMD64 CPU instruction set architecture (ISA) is, shows what CPUs implement it from both AMD and Intel, and explains what software is available to run on those 64-bit consumer processors.

Chassis Airflow
Date Issued: 20th Oct 2008

The modern PC is potentially a mass of heat output and heat production hot spots. With CPUs rated at more than 100W of heat output, single graphics boards carrying similar ratings (and people want to run two!), multiple hard drives the norm, lots of memory and mainboards covered in heatpipes to combat toasty core logic and PWM circuits, a PC appreciably warming up a room when it’s working hard is no joke.

Overclocking
Date Issued: 20th Oct 2008

This TekSpek explains why you’d want to overclock your graphics board, the risks in doing so and how you can go about doing it.

Core 2
Date Issued: 14th Jun 2008

There’s been a lot of hype about Intel’s Core 2 recently, even since they launched Core in fact. Words like Conroe, Badaxe and Allendale have been flying around. The bottom line is that Core 2 is the name of Intel’s latest line of CPUs, based on a new micro-architecture, designed for speed and efficiency.

System Noise Reduction
Date Issued: 5th Mar 2007

Anybody who has been near their share of computer systems will appreciate that not all systems make the same amount of noise. There are a number of reasons for why this is so. Firstly, a computer makes noise for different reasons. Generally, anything mechanical is going to make noise.

140mm Noctua NH-C14S Top-Flow CPU Cooler, NT-H1 Thermal Compound, LGA2066/2011/1150/1/5/6 + AMD FM1/2+/AM3+/3/2+/2 is rated 5.0 out of 5 by 4.

Rated 5 out of 5 by marsgle from Quality Fan and heat sink - super quiet As always with Noctua fans you get great cooling and super quiet. My Asus Rampage needed the fan sensor setting to ignore as when the pc booted it wasn't spinning at even the lowest 200rpm setting the bios monitor offered. Once up and running idling it sits about 600rpm (pwm). When gaming the fan is quiet (the fan in the gpu makes more noise so you cant actually hear this fan). My idle temp has dropped from 42-44 to 33-35 - impressive (previous fan was 120mm not 140mm). I had to go for this particular heatsink due to vengeance RAM so tall. Cooling a Xeon 3.5ghz 6 core chip that has a 130w tdp. I know the Noctua fan's are more expensive than others but to be honest all my pc's have them in now as I just love the low noise.

Date published: 2020-09-06

Rated 5 out of 5 by Hylander from Ryzen 2700x 4u server case So my rig is sitting in a custom 4u server case with 3 140mm fans at the front with a high flow 120mm as exhaust. Pc is in a server rack at current time of testing was at 25 deg ambient temperature. Ryzen 3700x OC on all 8 cores @4.2Ghz With the stock Wraith cooler with 3 minutes of cinebench i was hitting 84/85 deg. With the noctua i was hitting 76 deg. the wraith would of been screaming as where can barley hear it (noise not an issue to me its in the garage) Idle temps stock 45 deg, Noctua 33 deg (this is with both fans set to max) Hope this helps with someone with a similar setup to me

Date published: 2020-06-30

Rated 5 out of 5 by Armin from Fantastic cooler I liked this cooler very much, but it only performs well under certain environments. The cooler only works well when put in a system where the case exhaust runs parallel to the fans on the C14S. If intake and exhaust run perpendicularly to it, it can make temperatures significantly worse due to bad internal air turbulence. The one I got also came with some manufacturing defects, like bent heatsink fins. Although I am returning mine, I would still recommend the product for what it is.

Date published: 2015-11-30

Rated 5 out of 5 by MrBeeB from Quiet, effective cooling Easy to install after unscrewing motherboard from case. Much quieter than stock fan and knocks a good 10 degrees off operating temperature in comparison. It has no trouble keeping my overclocked Intel 4790k cpu cool and the down blowing fan keeps the RAM and other components cool.

Date published: 2015-09-01
