Product Overview

QNAP TL-R1220Sep-RP 12 Bay SAS Storage Expansion Enclosure

The TL-R1220Sep-RP SAS 12Gb/s storage expansion enclosure is designed for expanding the storage space of your QTS or QuTS hero NAS. Up to sixteen expansion enclosures can be daisy-chained via high-speed mini SAS HD cables to support up to 3.4PB raw capacity, ideal for archiving/backing up virtualization applications, surveillance recordings, large data, or multimedia. Featuring Broadcom® SAS DataBolt™ bandwidth optimization technology, the TL-R1220Sep-RP consolidates 6Gb/s infrastructure into 12Gb/s. With four mini SAS HD SFF-8644 Wide Ports, the TL-R1220Sep-RP delivers up to 192Gbps transfer speed when connected to a single host. When connected to a QTS/QuTS hero NAS that supports multipath routing, the TL-R1220Sep-RP can achieve smoother data transmission and continuous system operation.


Achieve up to 96Gb/s with Link Aggregation

The TL-R1220Sep-RP is powered by a low-power 28nm SAS35x28R SAS Expander and supports 12/6 Gb/s SAS/SATA drives. Also, it has four 12 Gb/s SAS 3.0 (x4 Lane) SFF-8644 SAS Wide Ports. By connecting the TL-R1220Sep-RP to the host NAS and daisy-chaining multiple JBODs with two wide ports configured with link aggregation, the solution delivers up to 96Gb/s transfer speed.


Supports SAS DataBolt™ Technology

Featuring Broadcom® SAS DataBolt™ bandwidth optimization technology, the TL-R1220Sep-RP features an intelligent data buffer for transferring data to drives at speeds that match the performance of the host NAS. Whether the TL-R1220Sep-RP uses 12Gb/s or 6Gb/s drives, the NAS host will transfer data to the TL-R1220Sep-RP at 12Gb/s, allowing you benefit from high-speed 12Gb/s SAS transmission with existing 6Gb/s infrastructure.


Connect up to 16 JBODs, support up to 3.4PB Raw Capacity

Multipath Routing to Ensure Continuous System Operations

By daisy chaining the TL-R1220Sep-RP, data transmission loads can be balanced with multipath routing to achieve high availability. If one route fails, another transmission route can be used to access the data and ensure continuous system operations. The TL-R1220Sep-RP also features a redundant power supply to ensure system uptime.


Flexible Daisy Chaining Modes

By daisy-chaining your NAS to multiple TL SAS JBODs and REXP SAS JBODs, you can take advantage of multipath routing and link aggregation to benefit from higher transfer speeds and system availability.


Storage Management

By using Storage & Snapshot Manager on the host NAS, you can configure and manage the TL-R1220Sep-RP's storage space by setting RAID groups, storage pools and snapshots, or configuring the JBOD as the storage volume of host NAS, allowing you to easily expand NAS storage to accommodate massive data or backup files. You can also configure and manage the TL-R1220Sep-RP via the Console Port.


Speed up Remote File Transfers with JBOD Migration

Moving many small files or a single large data file over a network can be time-consuming and negatively impact network performance. By setting up the RAID configuration on the TL-R1220Sep-RP, you can use it to move files to another computer or NAS. Simply save the files to the TL-R1220Sep-RP, connect it to the destination device, and then copy the files over.


Standard 5-Year Warranty

The TL-R1220Sep-RP is backed by a 5-year warranty at no extra cost. This premier warranty demonstrates QNAP's dedication to your essential business needs for continuous operations and non-interrupted services.


Features


Supported NAS System: Expand the storage space of a QTS/QuTS hero NAS, supports up to 3.4PB raw capacity by daisy-chaining up to 16 expansion enclosures.
Supported Server: Certified with Windows Server 2019; can be daisy-chained to flexibly expand the storage spaces of Windows servers.
DataBolt Bandwidth Optimization: Combine two 6Gb/s connections into one 12 Gb/s data stream to achieve faster speed with existing 6Gb/s infrastructure.
Multipath Routing: Ensure smooth data transmission and continuous operation by using the TL-R1220Sep-RP with a NAS that supports multipath routing.
Storage Management: Manage the storage space and settings of the TL-R1220Sep-RP with Storage & Snapshot Manager on the host NAS, windows users can manage the storage space and settings of the TL-R1220Sep-RP with the QNAP JBOD Manager app.
SAS Zoning: With the QNAP JBOD Manager app, the storage space of the TL-R1220Sep-RP can be divided into four zones. Different host servers can only access a single zone through different Wide Ports.
Remote Files Transfer: Conserve network bandwidth and performance by using the TL-R1220Sep-RP to transfer huge files from one device to another.
Easy Installation & Storage: With a short-depth design, the TL-R1220Sep-RP is suitable for universal deployment.


Specifications
Edition TL-R1220Sep-RP
NAS Form Factor 2U Rackmount
Bays 12 Bay
Total Storage Included N/A
Type of Drives Included
Edition of Drives Included
Capacity of Drives Included
Max. Storage Capacity
Drive Interface Support
  • 12 x SAS
  • 12 x SATA III - 6Gb/s
Drive Form Factor Support 12 x 2.5"/3.5"
Internal Flash Memory No
Internal Flash Memory Capacity
DOM Module No
DOM Capacity
CPU Type
CPU Model
CPU Cores
CPU Speed
RAM Memory Included
RAM Memory Type
Max. RAM Memory Supported
Cache Drive Interface
Included Cache Drive Capacity
Included Cache Drive Type
LAN Type N/A
Expansion Slots
External Connectivity
Cooling Fan
Noise Level
PSU Type Redundant
PSU Wattage 300 (x2) W
Max. Power Consumption 163.38 W
Physical Security
Dimensions 482.2 x 88.65 x 423.8 (WxHxD mm)
Weight 10.66 kg
Additional Information
Scan Code LN141386
Model Number TL-R1220Sep-RP
GTIN 4713213518571
