Scan code: LN133790 Manufacturer code: CDHR12MUK

Yamaha DHR12M 1000W 12" Powered Loudspeaker

Yamaha - DHR12M, 1000W Powered Loudspeaker with Coaxial 12" LF and 1.75" HF Drivers

Thumbnail 1 : Yamaha DHR12M 1000W 12" Powered Loudspeaker Thumbnail 2 : Yamaha DHR12M 1000W 12" Powered Loudspeaker Thumbnail 3 : Yamaha DHR12M 1000W 12" Powered Loudspeaker Thumbnail 4 : Yamaha DHR12M 1000W 12" Powered Loudspeaker
Scan code: LN133790 Manufacturer code: CDHR12MUK
Call for price
FREE DELIVERY ON YOUR ENTIRE BASKET
Delivery Options
  • By DPD to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

2-Way Coaxial 12" Active Floor Monitor
Yamaha - DHR12M

Yamaha - DHR12M

Performance. Optimized.The DHR Series offers an ideal solution for anyone ready to step up their sound reinforcement game to a new level of professional quality, accuracy, and performance. Premium plywood cabinets finished in a tough polyurea coating provide durability not found on other loudspeakers in this class.

Each model in the series has been optimized to meet the demands of a variety of sound reinforcement applications, with a 10” model for fixed installation and utilities, a 12” model designed for use as a floor monitor, and a 15” version for FOH applications—all featuring custom transducers driven by DSP-equipped class-D power amplifiers to deliver stunning sound quality and clarity. Combined with practical features adapted for their specific applications, the series gives you the flexibility to choose the ideal speaker for a wide variety of sonic environments. Isn’t it time you audition DHR quality and performance to improve your sound?

The DHR12M is a 2-way bi-amp powered loudspeaker with a 12-inch woofer and a 1.75-inch HF driver in a space saving coaxial configuration, perfect for use as a floor monitor. Combining a 1000W amplifier and high performance DSP with the same plywood construction found on Yamaha’s high-end DZR Series, the DHR12M offers best-in-class sound quality and durability.

1000 W PeakTotal Power Capacity

90° H x 90° VCoverage Angle

129 dBMaximum SPL

at a glance • The coaxial driver delivers precise, smooth phase and frequency response characteristics ideal for use in monitoring applications
• Compact, low profile, plywood enclosure with a polyurea coating for a robust, scratch-resistant surface
• Proprietary FIR-X™ tuning, provides FIR filtering and corrective EQ, minimizing phase distortion
• Featuring a plywood cabinet that delivers a clear sound with minimal vibration
• A pole socket for use on a stand

Yamaha Powered Loudspeaker "DHR Series" and Loudspeaker "CHR Series"

The Tech Spec

Features Specification
Configuration Active 2-Way
Enclosure Type Bass-Reflex Loudspeaker/Floor Monitor
Total Power Capacity 465 W RMS 1000 W Peak
Amplifier Power Rating HF: 1 x 200 W LF: 1 x 800 W
Amplifier Class Class-D
HF Driver 1 x 1.75" / 44.45 mm Horn-Loaded Compression Driver with 1" / 25 mm Throat
LF Driver 1 x 12" / 304.8 mm Woofer
LF Voice Coil 2.5" / 63.5 mm
Magnet Ferrite
Frequency Range 55 Hz to 20 kHz -10 dB
Maximum SPL 129 dB
Coverage Angle 90° H x 90° V
Protections DC Fault, Output Limiter, Overcurrent, Overvoltage, Power Supply, Thermal
Audio I/O 1 x Combo speakON-1/4" 3-Pin Female Balanced/Unbalanced Mic/Line Input 1 x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Line Input 1 x Stereo RCA TS Female Unbalanced Line Input 1 x XLR 3-Pin Male Balanced Line Thru/Output
Mounting 1 x 1.4" / 35 mm Pole Socket (Bottom, Side)
Dimensions 19.7 x 17.9 x 13.5" / 500.4 x 454.7 x 342.9 mm
Weight 36.4 lb / 16.5 kg
Specifications
Number of Input Channels N/A
Frequency Response -3dB N/A
Frequency Response -10dB N/A
Max SPL N/A
Power rating (Peak) N/A
Power rating RMS N/A
Speaker size N/A
Enclosure Type N/A
Dimensions
Net weight
Shipping weight N/A
Connectivity N/A
Connectivity (Output)
Colour
Bluetooth No
Battery Powered No
Wifi No
App control No
Rigging Points No
Pole Mountable No
Integrated Bracket No
Sub Woofer No
Built in DSP No
Front of House No
Floor Monitor No
Additional Information
Scan Code LN133790
Model Number CDHR12MUK
GTIN 4957812662093
