Scan code: LN139284 Manufacturer code: SSL0121

Solid State Logic B-Series Dynamics 500 Series Module

SSL - B-Series Dynamics 500 Series Module, with Compressor/Limiter and Gate/Expander

Scan code: LN139284 Manufacturer code: SSL0121
Order now and get it tomorrow, Tue 16th Apr
£599.00
Get it Tomorrow, 16 AprIn stock
FREE DELIVERY ON YOUR ENTIRE BASKET
From £20.98 / month (APR 16.9%) or 0% for 4 months
Monthly Payment: £54.27
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £599.00
Total inc. interest: £651.22
Monthly Payment: £29.25
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £599.00
Total inc. interest: £701.96
Monthly Payment: £20.98
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £599.00
Total inc. interest: £755.04
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

Representative Example:

Purchase Rate: 23.9% p.a. (variable)

Representative: 23.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £15.92 / month (APR 19.9%)
Delivery Options
  • By DPD On 16th Apr to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Solid State Logic - 4K B Dynamic 500 Series Module

Solid State Logic - 4K B Dynamic 500 Series Module

New analogue flavour, vintage SSL soundCapture the legendary SL 4000 B console compressor sound in the portable 500 Series format with the 4K B Dynamic 500 Series Module by SSL. This module pays homage to the compressor/limiter and gate/expander found in the channel strip of the iconic 80s consoles gracing 'The Stone Room' at Virgin's Townhouse Studio in London, Le Studio in Montreal, and the Record Plant in LA. Now, you can infuse your portable production toolkit with the distinctive, gripping, and saturated compression that was once exclusive to one of the most coveted studio consoles ever crafted.

For those in pursuit of the revered compression tones heard on timeless records like Phil Collins' "In the Air Tonight" and Peter Gabriel's "Intruder," your quest ends here with this faithful recreation.

at a glance • Compressor and Limiter
• Expander and Gate
• Five-Segment LED Indicator Meters
• Side-Chain High-Pass Filter
• Feedback Design with Peak Sensor
• Circuitry from the SL 4000 B Console

Its Own Unique Sonic Signature

Solid State Logic - 4K B Dynamic 500 Series Module

VCA ‘feedback’ design hasThe dynamics Section in the SL 4000 B console channel strip was unlike any other SSL channel dynamics module that followed, using the fader VCA as its gain element, rather than a dedicated VCA.

It had a design similar to the topology of the SSL Bus Compressor. This VCA ‘feedback’ design has been inherited by the B-DYN module, offering characterful and coloured compression, with its own unique sonic signature - very different from the later E and 9000 Series. These similarities are also evident from B-DYN’s ‘Auto’ release setting, which offers a program-dependent release time as found on the Bus Compressor.

De-Ess (DS) Mode

back

optimised for reducing sibilanceBy setting COMPRESSOR RATIO and RELEASE controls to ‘DS’ the B-DYN module is optimised for reducing sibilance (De-Essing). The De-Ess ratio is a 10:1 ratio with filtered S/C input signal, delivering broadband compression triggered by sibilance typically in vocal sources.

The ‘DS’ release is automatically varied in response to the processed signal between release rates of 30 & 50 ms. This is a much faster minimum release than you would normally expect from an SSL Dynamics section. The Attack time is also reduced to a fast 2 ms, slightly faster than the E-Series Dynamic module on its FAST setting)

Compressor/Limiter

Solid State Logic - 4K B Dynamic 500 Series Module

RATIO - Stepped compression ratios 2:1, 4:1, 10:1 and ‘ds’. The ‘ds’ setting is a fixed 10:1 with an additional sidechain filter. When ‘out, the compressor is bypassed.

THRESH - Whenever a signal exceeds the level set by this control, the compressor will start to act at the ratio set by the RATIO control. The THRESH’old control also provides automatic make-up gain. A small improvement to the linearity of this control has been made in the module over the original channel strip control. This helps with Threshold tuning using the smaller scale 500 series knobs.

HPF - A 6dB/Oct 185 Hz High Pass Filter in the compressor sidechain to help reduce bass pumping effects.

RELEASE - Switched/fixed release ranges from .2 ms to 1.6 ms with additional ‘DS’ & AUTO release options.

DS - The De-Ess mode changes the attack time from approx. 30 ms to 2 ms.

Solid State Logic B-DYN 500 Series Module
Overview and Tutorial

Product specialist, Luka Aziz gives you a guided tour of the B-DYN module, using a pair of them to process kick, snare, and vocals. As well as comparing them to the renowned E-DYN 500 Series module.

The Tech Spec

Features Specification
Processor Type VCA Compressor/Limiter
Number of Channels 1
Controls Threshold, Ratio, Release, Range
Threshold Battery Option, DC 9V Adapter (Not Included)
Ratio 2:1, 4:1, 10:1, DS
Side Chain Inserts Yes
Module Slot Size Single
Height 5.25"
Width 1.5"
