Silverstone CS383 8-Bay SAS-12G / SATA-6G E-ATX NAS/Workstation Chassis

Eight-Bay Hot-Swap Storage

At the heart of the CS383 is its eight hot-swappable drive trays, each capable of accommodating either 3.5-inch or 2.5-inch SAS-12G and SATA-6G drives. Every bay is paired with dual LED indicators, allowing instant visibility of drive power and activity. Combined with its integrated 8-port backplane, the chassis delivers enterprise-level storage performance that scales seamlessly from standard desktop setups to full server-grade environments.

Built for Workstation-Grade Hardware

This chassis supports more than conventional NAS hardware. It accommodates SSI-EEB, SSI-CEB, Extended ATX, ATX, Micro-ATX, and Mini-ITX motherboards, making it compatible with workstation-class builds as well as compact designs. With eight PCI expansion slots, the CS383 enables complex configurations such as multiple GPU setups or high-speed networking cards, bridging the gap between NAS storage solutions and full-scale workstation or server systems.

Cooling Without Limits

The CS383 has been engineered for advanced cooling options. A pre-installed 140mm rear fan and dual 92mm internal fans provide strong baseline airflow, while the top panel supports radiators up to 420mm in length. Additional mounting positions accommodate up to three 120mm or 140mm fans, giving users a wide range of choices for liquid or air cooling. Depending on configuration, CPU cooler height allowances extend up to 186mm without a GPU bracket or 158mm with the bracket installed, ensuring compatibility with high-performance thermal solutions.

Even More Storage

In addition to its primary eight-bay array, the CS383 provides internal mounting options for system or auxiliary drives. Users can configure the space to hold a single 3.5-inch drive paired with two 2.5-inch devices, or alternatively install three 2.5-inch drives. This flexibility makes it possible to separate operating system disks, cache SSDs, or smaller high-speed volumes from the main hot-swap bays, extending both the capacity and versatility of the chassis.

Flexible Front Expansion Options

The front panel provides space for three 5.25-inch devices, offering additional options for optical drives, hot-swap bays, or other expansion modules. Alternatively, this section can be repurposed as a secondary PSU slot, accommodating an additional ATX (PS2) power supply of up to 200mm in length. This flexibility makes the CS383 suitable for redundant or high-load power configurations, while the primary PSU bay supports units up to 240mm.

Expansion Card and GPU Support

With room for expansion/interface cards up to 340mm in length and 164mm in width, the CS383 provides ample space for today’s largest GPUs and add-in cards. Multi-GPU setups are fully supported thanks to its eight-slot layout, making the chassis a strong candidate for rendering workloads, simulation tasks, or other GPU-intensive applications alongside its NAS functionality.

Front I/O and User Convenience

The chassis is equipped with a modern front I/O panel, including a USB Type-C port, dual USB 3.0 ports, and a combo audio jack. LED indicators on both the chassis and individual drive trays provide real-time feedback on system power, LAN activity, and storage access. Dust filters are also included in key intake areas, ensuring that airflow remains unobstructed while maintaining cleaner internal components over time.

• High-capacity workstation/NAS chassis with 8 hot-swappable bays, SSI-EEB motherboard support, and liquid cooling. compatibility.
• Supports up to eight 3.5" or 2.5" SAS-12G / SATA-6G drives with dual LED status indicators.
• Compatible with SSI-EEB, SSI-CEB, E-ATX, ATX, Micro-ATX, and Mini-ITX motherboards.
• Eight PCI expansion slots with clearance for graphics or interface cards up to 340mm in length and 164mm in width.
• Internal storage flexibility with support for either 1 x 3.5" plus 2 x 2.5" drives, or 3 x 2.5" drives.
• Top panel supports liquid cooling radiators up to 420mm, with pre-installed 140mm and dual 92mm fans included.
• Dual PSU support with primary 240mm ATX (PS2) and optional secondary 200mm PSU in front bay area.
• Front I/O panel equipped with USB Type-C, 2 x USB 3.0, and combo audio jack.
• Integrated dust filters positioned in key airflow areas for cleaner long-term operation.
