Silverstone SST-ALD1B Alta D1 Workstation Chassis

Silverstone Alta D1 Modular and Flexible Workstation Chassis, Up to 3x 360mm Rads, Dual PSU Support, Upto 11 PCI Slots
MORE INFO
MORE INFO

Scan code: LN152662 Manufacturer code: SST-ALD1B
£799.99
Item currently awaiting an ETA
Pre Order
Pre order

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free

Finance this product

  • From £28.02 / month (APR 16.9%) or 0% for 4 months
  • With a 10% deposit from just £21.26 / month (APR 19.9%)
  • SCANPROTECT Protect against installation damage for 28 days.
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan.

Suggested Alternatives

Product Overview

Built for Complete Server-Grade Compatibility

Designed for deployment in diverse high-computing applications, the ALTA D1 supports server-grade components, including SSI-EEB (12" x 13") and specialized form factor motherboards up to 15.12" x 13.2".

Boasting a maximum of 11 PCI slots, the ALTA D1 easily supports multiple graphics cards configuration to meet the demands of ever-increasing graphics computing.

Delivering substantial airflow performance right out of the box, the ALTA D1 includes two SilverStone staple 180mm intake fans and a 140mm rear exhaust fan, achieving highly efficient front-to-back directional airflow.


Peak Performance with Ultimate Modularity

The key feature of the ALTA D1 is its modular bays, which accommodate the included modular cages and fan/radiator brackets. These cages support storage drives, including 5.25" ODD, 3.5" HDD, and 2.5" SSD, allowing users to customize component placement and explore various system configurations.

The included fan/radiator bracket supports up to three 120mm fans and/or a 360mm radiator, providing ample surface area to manage the increased heat generated by server-grade components.

In addition to the storage cages, the ALTA D1 offers two PSU cages for a dual PSU system configuration. This setup is particularly beneficial for systems with high computational power requirements, offering extra performance and stability while extending the lifespan of other components.


Features


• Compatible with 12" x 13" SSI-EEB and 15.12" x 13.2" specialized form factor motherboards.
• Multiple modules for maximizing expansion, performance, and flexibility.
• Supports up to 11 PCI slots for multi-workstation GPU capability, with a total graphics card clearance of 407mm.
• Dual PSU support.
• Supports a maximum of three 360mm radiators.
• Crafted from high-grade steel, provides exceptional durability and robustness.
• Front I/O includes 1 x USB Type-C, 2 x USB 3.0.

Specifications
Core Chassis Specifications
Case Edition Alta D1 Workstation Chassis
Case Form Factor
Motherboard Form Factor
  • ATX
  • E-ATX (12" x 13")
  • MicroATX
  • Mini-ITX
  • SSI CEB
  • SSI EEB
  • XL-ATX
Back Connect Compatible No
I/O, Bays & Expansion
Front/Side/Top Panel I/O
  • 2 x USB 3.0
  • 1 x USB Type-C
Drive Bays
  • 8 x 2.5" Internal
  • 4 x 5.25" / 3.5" External
Standard Expansion Slots 11 (without modular kit occupied) / 7 (with modular kit occupied)
Vertical Expansion Slots
Fans & Filters
Fan Bays
  • 3 x 120mm
  • 10 x 120mm / 7x 140mm
  • 1 x 140mm
  • 2 x 180mm
Fans Included 2 x 180mm
Fan Controller/Hub
Dust Filters
Liquid Cooling Support
Front Radiator Compatibility
Top Radiator Compatibility
Bottom Radiator Compatibility 1 x 120/240/360mm
Rear Radiator Compatibility 1 x 120mm
Side Radiator Compatibility 2 x 120/140/240/280/360mm
Clearances
Max CPU Cooler Height 191 mm
Max GPU Card Length 407mm (without installing front mounted fans) mm
Cable Routing Space
Side Panels
Window/s No
Window Configuration
Window Construction
LED Lighting Functionality
LED Lighting No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control
Power Supply Compatibility
PSU Included No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support ATX
PSU Mounting Location
Max PSU Length
Chassis Physical Specifications
Colour Black
Chassis Construction Materials Steel
Dimensions 265mm (W), x 651mm (H), x 457mm (D) (WxHxD mm)
Weight 21.3 kg (Approx)
