Sennheiser XSW 1-CI1-E Guitar / Bass Instrument Wireless Set
Sennheiser XSW 1-CI1-E All-In-One Wireless System for Instruments,Upto 10 Compatible Channels,Selectable UHF frequencies
Scan code:
LN97552
Manufacturer code:
506998
Free Delivery
From
£8.71
/ month (APR 0%)
spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
- By DPD On 9th Dec To 11th Dec to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
- Collect instore Collect from our Bolton store, BL6 6PE | Free
- UPS and DPD Pickup Pickup from local convenience store | £4.79
- SCANPROTECT Protect against installation damage for 28 days. More info
Product Overview
Amplify your tunes. Go for XS WIRLESS 1 and rely on a solid wireless transmission with up to 10 compatible channels in a stable UHF band. The XS WIRELESS 1 INSTRUMENT SET is an easy to use all-inone wireless system for guitarists and bassists, excellent for live sound. The set includes an intuitive stationary receiver for quick set-up and hassle-free handling, as well as a compact bodypack transmitter and a robust instrument cable. Features
• Compact bodypack transmitter, rugged instrument cable
• Antenna-switching diversity reception
• Integrated antennas
• Automatic frequency management and synchronization via remote channel for easy setup
• Selectable UHF frequencies within a large bandwidth
• Up to 10 compatible channels
What's in the Box
1 receiver EM-XSW 1
1 bodypack transmitter SK-XSW
1 instrument cable Cl1
1 power supply NT 12-5 CW
2 AA batteries
Technical specifications
• THD, total harmonic distortion = 0.9%
• Signal-to-noise ratio = 103 dBA
• RF output power: 10 mW
• Switching bandwidth: up to 24 MHz
• Operating time: approx. 10 hrs
• Modulation: Wideband FM
• Output voltage: 1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu
• Housing: Rugged ABS housing
• Frequency: 8 frequency banks, each with up to 10 factory-preset channels
•Frequency range:
-A: 548-572 MHz, GB: 606-630 MHz
-B: 614-638 MHz
-C: 766-790 MHz
-D: 794-806 MHz
-E: 821-832 MHz, 863-865 MHz
-K: 925-937.5 MHz
• Sensitivity: < 3 µV at 52 dB(A)rms S/N
• SPL for peak deviation: 130 dB
• Squelch: adjustable from 3 dBµV to 28 dBµV (combined with pilot tone)
• Synchronization: 2.4 GHz, Low Power OQPSK (only active during synchronization)
• Input sensitivity: 1.5 mV / Pa
• AF frequency response: Receiver: 50 to 16,000 Hz (–3 dB)
• Adjustment Range Transmitter: 0 to -30 dB, adjustable in 10 dB steps
• Audio adjustment range: 45 dB, adjustable in 5-dB steps
• Line / Mic level: 20 dB, switchable
• Temperature Range: operation: 0°C to +40°C, storage: –20°C to +70°C
• Receiver Principle: double superheterodyne
• Diversity principle: Antenna switching diversity via internal antennas
Dimensions
• Receiver: approx. 200 x 42 x 127 mm
• Bodypack transmitter: approx. 71 x 96 x 28 mm
Power supply
• Receiver: 12 V DC nom. / 300 mA
• Transmitter: 2 AA size batteries, 1.5 V
• Antenna-switching diversity reception
• Integrated antennas
• Automatic frequency management and synchronization via remote channel for easy setup
• Selectable UHF frequencies within a large bandwidth
• Up to 10 compatible channels
What's in the Box
1 receiver EM-XSW 1
1 bodypack transmitter SK-XSW
1 instrument cable Cl1
1 power supply NT 12-5 CW
2 AA batteries
Technical specifications
• THD, total harmonic distortion = 0.9%
• Signal-to-noise ratio = 103 dBA
• RF output power: 10 mW
• Switching bandwidth: up to 24 MHz
• Operating time: approx. 10 hrs
• Modulation: Wideband FM
• Output voltage: 1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu
• Housing: Rugged ABS housing
• Frequency: 8 frequency banks, each with up to 10 factory-preset channels
•Frequency range:
-A: 548-572 MHz, GB: 606-630 MHz
-B: 614-638 MHz
-C: 766-790 MHz
-D: 794-806 MHz
-E: 821-832 MHz, 863-865 MHz
-K: 925-937.5 MHz
• Sensitivity: < 3 µV at 52 dB(A)rms S/N
• SPL for peak deviation: 130 dB
• Squelch: adjustable from 3 dBµV to 28 dBµV (combined with pilot tone)
• Synchronization: 2.4 GHz, Low Power OQPSK (only active during synchronization)
• Input sensitivity: 1.5 mV / Pa
• AF frequency response: Receiver: 50 to 16,000 Hz (–3 dB)
• Adjustment Range Transmitter: 0 to -30 dB, adjustable in 10 dB steps
• Audio adjustment range: 45 dB, adjustable in 5-dB steps
• Line / Mic level: 20 dB, switchable
• Temperature Range: operation: 0°C to +40°C, storage: –20°C to +70°C
• Receiver Principle: double superheterodyne
• Diversity principle: Antenna switching diversity via internal antennas
Dimensions
• Receiver: approx. 200 x 42 x 127 mm
• Bodypack transmitter: approx. 71 x 96 x 28 mm
Power supply
• Receiver: 12 V DC nom. / 300 mA
• Transmitter: 2 AA size batteries, 1.5 V
