17 Port QNAP QSW-M5216-1T Managed Switch, 16x 25GbE SFP28 1x 10GbE BASE-T, 1x 1GbE MGMT RJ45, 820Gbps S/C, Rackmount
MORE INFO
MORE INFO

Scan code: LN141401 Manufacturer code: QSW-M5216-1T

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • SCANPROTECT Protect against installation damage for 28 days.

Suggested Alternatives

Product Overview

Ultra High Acceleration

The QSW-M5216-1T is a versatile 16-port 25GbE SFP28 fiber managed switch that includes one 10GbE NBASE-T port. With Layer 2 switching capabilities and an intuitive web user interface for network management, the QSW-M5216-1T offers an accessible solution for managing networks, even for those without IT expertise. Boasting lightning-fast 25GbE speeds and switching capacity of 820Gbps, this switch can function as a central hub for connecting to 25G servers and NAS in server rooms, as well as linking to 25G/10G switches to enhance high-speed storage, video editing, virtualisation, and AI applications. The QSW-M5216-1T comes equipped with adaptable network interfaces for enhanced compatibility at a budget-friendly price, making it easier for small businesses to upgrade to a high-speed network by seamlessly integrating with their existing infrastructure.


820Gbps Switching Capacity

The QSW-M5216-1T boasts sixteen 25GbE SFP28 fiber ports and a powerful backbone switching capacity of 820Gbps, ensuring optimal performance for every port. It is ideal as a core switch for linking to 25G/100G Servers and NAS in server rooms, or for connecting to 25G/10G edge fiber switches.


Flexible Deployment

Transitioning to ultra-high-speed 25GbE is a seamless process that offers numerous benefits. The ultra-high-speed 25GbE provides cost advantages and ensures compatibility in SMB server rooms as a result, catering broadly to networking needs. With 25GbE, bandwidth requirements for high-speed storage, virtualisation and AI applications are met, enhancing overall performance and efficiency. Its backwards compatibility with 10GbE SFP+/1GbE SFP, along with the ability to connect to 50GbE/100GbE via Breakout DAC, allows for easy integration into existing network infrastructure, and despite being 2.5 times faster than 10GbE, the cost of 25GbE remains less than 2 times higher, making it a sustainable upgrade to your system.


QSS: Online Management Software

The QSW-M5216 uses the QNAP Switch System (QSS), which features an easy-to-use Web GUI with value-added functions to simplify network set up and management. This software visually represents all the ports for easy accessibility and understanding, and includes a setting guide, with a status chart reference and automatic firmware updates. These entry-level features reduce learning and management costs, providing nervous networking beginners with an intuitive entry point into the field.


Features

• Ultra-High-Speed Fiber-Managed Switch.
• Intuitive Web Management with QSS.
• Jumbo Frame Support: 9,000
• Input Voltage (AC): 100-240V, 50/60Hz
• Power Supply Included*

Specifications
Edition Smart Managed Switch
Form Factor Rackmount
Total Network Ports
  • 1 x 1000/10Gb RJ-45
  • 16 x SFP28 (25/10/1GbE)
PoE Support Type N/A
No. of Ports Providing PoE
Other Non-Network Ports
  • 1 x 9-pin DB-9 D-Sub (Console)
  • 1 x Management RJ-45
Switching Capacity 820Gbps
Non-Blocking Throughput 410Gbps
Forwarding Rate N/A
MAC Address Table Size 32K Entries
Network Capacity N/A
Built-in Flash Memory N/A
RAM Memory N/A
Network Protocols
  • IEEE 802.1ab
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1w
  • IEEE 802.3
  • IEEE 802.3ab
  • IEEE 802.3ad
  • IEEE 802.3ae
  • IEEE 802.3an
  • IEEE 802.3x
Acoustic Noise
Max. Power Consumption 32.602 W
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply External Power Supply (Included)
Material Metal
Includes Rack Mounting Brackets
Dimensions (WxHxD) 285 x 43.5 x 237.7 mm
Weight 2.15 kg
