QNAP 10-Port Layer 2 Web Managed Half-Width Rackmount Switch for SMB Network Deployment

10 Port QNAP QSW-M2106R-2S2T Managed Switch, 6x 2.5GbE RJ45, 2x 10GbE BASE-T RJ45, 2x 10GbE SF28+, 110Gb S/C, Rackmount
MORE INFO
MORE INFO

Scan code: LN141397 Manufacturer code: QSW-M2106R-2S2T
£497.99
Item currently awaiting an ETA
Pre Order
Pre order
Pay in 3 interest-free payments of £166.00

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores

Finance this product

  • With a 10% deposit from just £13.23 / month (APR 19.9%)
  • SCANPROTECT Protect against installation damage for 28 days.

Suggested Alternatives

Product Overview

Extensive Ports

The switch boasts two 10GbE SFP+ fiber ports (backward compatible with 1G SFP) and two 10GbE RJ45 ports. Additionally, it offers six 2.5GbE RJ45 ports, allowing you to boost network speed by 2.5 times using existing Cat 5e cables. These ports support NBASE-T technologies, providing speeds of 10G, 5G, 2.5G, 1G, and 100M. 10GBASE-T delivers lightning-fast data transfer rates of up to 10 gigabits per second (Gbps), making it very reliable.


Efficient Network Management

Dive into advanced capabilities such as Link Aggregation Control Protocol (LACP), VLAN support, Access Control Lists (ACLs), and Link Layer Discovery Protocol (LLDP). These features empower you to optimise network performance, enhance security, and streamline traffic. The switch supports Rapid Spanning Tree Protocol (RSTP), a crucial feature for redundancy and loop prevention. By intelligently managing network paths, RSTP ensures uninterrupted connectivity even in the face of link failures. Furthermore, the switch is compliant with IEEE802.3x Flow Control, the QSW-M2108R-2C prevents packet loss during congestion. This ensures smooth data transmission across your network, regardless of traffic spikes.


QSS: Online Management Software

The QSW-M5216 uses the QNAP Switch System (QSS), which features an easy-to-use Web GUI with value-added functions to simplify network set up and management. This software visually represents all the ports for easy accessibility and understanding, and includes a setting guide, with a status chart reference and automatic firmware updates. These entry-level features reduce learning and management costs, providing nervous networking beginners with an intuitive entry point into the field.


Features

• High-Speed Fiber-Managed Switch.
• Intuitive Web Management with QSS.
• Jumbo Frame Support: 9,000
• Input Voltage (AC): 100-240V, 50/60Hz
• Power Supply Included*

Specifications
Edition Smart Managed Switch
Form Factor Rackmount
Total Network Ports
  • 6 x 10/100/1000/2.5G RJ-45
  • 2 x 100/1000/2.5G/5G/10G BASE-T RJ45
  • 2 x SFP+ 1000/10G (Dedicated)
PoE Support Type N/A
No. of Ports Providing PoE
Other Non-Network Ports 1 x Management RJ-45
Switching Capacity 110Gbps
Non-Blocking Throughput 55Gbps
Forwarding Rate N/A
MAC Address Table Size 16K Entries
Network Capacity N/A
Built-in Flash Memory N/A
RAM Memory N/A
Network Protocols
  • IEEE 802.1ab
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1w
  • IEEE 802.3
  • IEEE 802.3ab
  • IEEE 802.3ad
  • IEEE 802.3ae
  • IEEE 802.3bz
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3z
Acoustic Noise
Max. Power Consumption 40 W
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply External Power Supply (Included)
Material Metal
Includes Rack Mounting Brackets
Dimensions (WxHxD) 43.3 x 207 x 248.8 mm
Weight 1.53 kg
