PreSonus Quantum HD 8 USB-C Audio Interface

PreSonus - Quantum HD 8, 20 x 30, 32-bit 192 kHz USB-C Audio Interface

Thumbnail 1 : PreSonus Quantum HD 8 USB-C Audio Interface Thumbnail 2 : PreSonus Quantum HD 8 USB-C Audio Interface Thumbnail 3 : PreSonus Quantum HD 8 USB-C Audio Interface Thumbnail 4 : PreSonus Quantum HD 8 USB-C Audio Interface
Scan code: LN146799 Manufacturer code: 2777704502
Order now and get it tomorrow, Wed 17th Jul
£863.00
Get it Tomorrow, 17 JulIn stock
FREE DELIVERY ON YOUR ENTIRE BASKET
From £30.22 / month (APR 16.9%) or 0% for 4 months
Monthly Payment: £78.19
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £863.00
Total inc. interest: £938.21
Monthly Payment: £42.14
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £863.00
Total inc. interest: £1,011.32
Monthly Payment: £30.22
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £863.00
Total inc. interest: £1,087.92
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

Representative Example:

Purchase Rate: 23.9% p.a. (variable)

Representative: 23.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £22.93 / month (APR 19.9%)
Delivery Options
  • By DPD On 17th Jul to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

USB-C Audio Interface
PreSonus - Quantum HD 8

PreSonus Quantum HD 8

the recording interface for
project studios and full band recordings
The PreSonus Quantum HD 8 features eight newly redesigned high-definition MAX-HD mic preamps with +75 dB of gain – making it perfectly suitable for today’s most popular microphones. Guitarists and bassists will love the two instrument inputs, which were codeveloped with Fender engineers.

An Auto Gain button sets the perfect gain level for your microphones and instruments. You also get two re-amp outputs so you can send audio from your DAW to your guitar or bass amp and re-record it to experiment with different amps, pedals, and mic placements. An illuminated push encoder gives you flexible control over gain level and output volume, making it great for self-produced recording.

The custom low-latency driver provides exceptionally low audio latencies when recording, and high-performance converters with 124 dB dynamic range let you hear and capture audio with stunning clarity and fidelity. The eight newly designed high-definition MAX-HD preamps feature +75 dB of gain, with transparent, low-noise, and digitally-controlled analogue.

+18 dBuMax Input

0 dB - +75 dBGain Range

124 dBDynamic Range

At a glance • 20 x 30, 32-bit 192 kHz USB-C Audio Interface
• High-performance converters deliver audio with stunning clarity and fidelity
• Custom low-latency driver provides exceptionally low audio latencies when recording
• PreSonus MAX-HD preamps provide transparency and accuracy across the frequency range
• A full-colour, high-resolution screen lets you monitor your input and output meters
• 16 channels of ADAT Optical input (up to 48 kHz) plus stereo S/ PDIF I/O

High-Performance & User-Friendly

PreSonus Quantum HD 8

Co-Developed With FenderBuilt by the best ears in the business, guitarists and bassists will love the instrument input co-developed with Fender engineers – industry experts who purposely designed them for guitar and bass.

Recording Software IncludedJump into 12 months of Studio One+ with access to Studio One Professional Edition, add-ons, and more.

Auto GainAn Auto Gain button sets the perfect gain level for your microphones and instruments, so you get the perfect take every time.

Re-Amp OutputsRe-amp audio directly from your DAW and use amps and effects to sculpt your sounds. Send audio from your DAW to your guitar or bass amp and re-record it to experiment with different amps, pedals, and mic placements.

Universal Control App

PreSonus Quantum HD 8

extra convenientQuantum works using any mobile or desktop device, so you’re ready to record whenever inspiration strikes – if on your phone, tablet, or in your home studio. Critical preamp functions like preamp gain, phantom power, and more can be controlled with the Quantum HD 8’s flexible front panel, or right from Studio One and the Universal Control app, so you can dial in the perfect gain staging without looking away from your recording session.

The Tech Spec

Features Specification
Inputs and Outputs Microphone Inputs: 8
Guitar Inputs: 2
Line Inputs: 8
S/PDIF Input: 1
Optical Input: 2
MIDI Input: 1
Monitor Outputs (DC coupled): 2
Line Outputs (DC coupled): 8
Re-amp outputs: 2
S/PDIF Output: 1
Optical Output: 2
MIDI Output: 1
Headphone Outputs: 2
USB-C ports: 1

AD / DA Conversion
Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192
Bit Depth: 32
Analogue I/O Inputs
Microphone (CH 1 - 2)
Connector Type: 8x Combo-style, XLR / TRS
Max Input: +18 dBu (balanced, minimum gain)
Gain Range: 0 dB to +75 dB
Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (unity gain, reference 1 kHz)
Dynamic Range: 116 dB (A-weighted, minimum gain)
THD + N: 0.002% (1 kHz, minimum gain)
EIN: -130 dBu (max gain, 150 Ohms, 20 kHz BW, A-weighted)
Input Impedance: 1600 Ohms

Line In (CH 1 - 2)
Connector Type: 8x Combo-style, XLR / TRS
Max input level: +18 dBu (balanced, minimum gain)
Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (unity gain, reference 1 kHz)
Dynamic Range: 118 dB (A-weighted, minimum gain)
THD + N: 0.001% (1 kHz, minimum gain)
Input Impedance: 10K Ohms
Digital Trim: -10 to +10 dB

Instrument In (Ch 1 - 2)
Connector Type: 2 x 1/4-inch Female
Gain Range: -7 dB to +68 dB
Max input level: +21 dBu (unbalanced, minimum gain)
Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (unity gain, reference 1 kHz)
Dynamic Range: 111 dB (A-weighted, minimum gain)
THD + N: 0.003% (1 kHz, minimum gain)
Input Impedance: 1M Ohms

Outputs
Main Out (CH 1 - 2)
Connector Type: 2x 1/4-inch Female, TRS
Max Output Level: +18 dBu (Balanced)
Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (unity gain, reference 1 kHz)
Dynamic Range: 123 dB (A-weighted)
THD + N: 0.001% (1 kHz, +4 dBu)
Output Impedance: 51 Ohms
Trim Range: -inf dB to 0 dB

Line Out (Ch 3 - 4)
Connector Type: 8x 1/4-inch Female, TRS
Max Output Level: +18 dBu (Balanced)
Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (unity gain, reference 1 kHz)
Dynamic Range: 123 dB (A-weighted)
THD + N: 0.001% (1 kHz, +4 dBu)
Output Impedance: 51 Ohms
Trim Range: -inf dB to 0 dB

Re-Amp Out (Ch 5 - 6)
Connector Type: 2x 1/4-inch Female, TRS
Max Output Level: +4 dBu (Balanced)
Frequency Response: 20 Hz to 20 kHz, +/- 0.3 dB (unity gain, reference 1 kHz)
Dynamic Range: 117 dB (A-weighted)
THD + N: 0.001% (1 kHz, +4 dBu)
Output Impedance: 100 Ohms
Trim Range: -inf dB to 0 dB

Headphone Out
Connector Type: 2x 1/4-inch Female, TRS Stereo
Max Output Level: 11 dBu (50 Ohms)
Frequency Response: 20 Hz to 20 kHz, +/- 0.3 dB (unity gain, reference 1 kHz)
Dynamic Range: 118 dB (A-weighted)
THD + N: 0.001% (1 kHz)
Output Impedance: 33 Ohms
Trim Range: -inf dB to 0 dB
Digital I/O S/PDIF I/O
Connector Type 2x Phono RCA (1 in , 1 out)
Supported Sample Rates (kHz) 44.1, 48, 88.2, 96

ADAT I/O
Connector Type Optical TOSLINK (2 in, 2 out)
Format ADAT Digital Lightpipe with S/MUX II
• 16 channels at 44.1/48 kHz
• 8 channels at 88.2/96 kHz

MIDI I/O
Connector Type: 2x 5-pin DIN (off DB-9)

Synchronization Sources
Sources: Internal, ADAT, S/PDIF
Electrical Connector type DC Connector
Configuration Internal, Universal
Power Input 12V DC, 2A
Product Dimensions Length: 19” (483mm)
Width: 8.6’’ (219mm)
Height: 1.7’’ (44mm)
Weight 6.3lb (2.86 kg)
Specifications
Computer Interface Type USB 2.0 Type-C
Connections (Input)
  • 2 x 6.35mm (1/4") Instrument
  • 8 x 6.35mm (1/4") TRS Jack
  • 8 x XLR
  • 8 x XLR / Jack Combo
Mic Preamps (Max) 8
Instrument Inputs (Max) 8
Phantom Power Yes
Sample Rate (Max)
Bit Resolution
iPad Compatible No
Connections (Output)
  • 8 x 6.35mm (1/4") TRS Jack
  • 2 x Headphone (TRS 6.35mm Jack)
  • 2 x MIDI
  • 2 x RCA Phono
  • 2 x S/PDIF Optical
Dimensions (mm) 219 x 44 x 483 WxHxD
DSP Processing No
Misc. Notes
Additional Information
Scan Code LN146799
Model Number 2777704502
GTIN 673454012266
