PreSonus Quantum ES 4 USB-C Audio Interface

PreSonus - Quantum ES 4, 4 x 4, 24-bit / 192 kHz USB-C Audio Interface

Thumbnail 1 : PreSonus Quantum ES 4 USB-C Audio Interface Thumbnail 2 : PreSonus Quantum ES 4 USB-C Audio Interface Thumbnail 3 : PreSonus Quantum ES 4 USB-C Audio Interface Thumbnail 4 : PreSonus Quantum ES 4 USB-C Audio Interface
Scan code: LN146801 Manufacturer code: 2777700504
Order now and get it tomorrow, Wed 17th Jul
£284.00
Get it Tomorrow, 17 JulIn stock
FREE DELIVERY ON YOUR ENTIRE BASKET
From £13.87 / month (APR 16.9%) or 0% for 4 months
Monthly Payment: £25.73
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £284.00
Total inc. interest: £308.73
Monthly Payment: £13.87
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £284.00
Total inc. interest: £332.82
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

Representative Example:

Purchase Rate: 23.9% p.a. (variable)

Representative: 23.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £7.55 / month (APR 19.9%)
Delivery Options
  • By DPD On 17th Jul to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview The PreSonus ES 4 features four newly redesigned high-definition MAXHD mic preamps with +75 dB of gain – making it perfectly suited for popular modern microphones. Guitarists and bassists will love the instrument inputs, which were co-developed with Fender engineers. An Auto Gain button sets the perfect gain level for your microphones and instruments, while an illuminated push encoder gives you flexible control over gain level and output volume. A bright and responsive LED metering provides easy visual feedback for your inputs and outputs, making self-produced recording easier.

The PreSonus custom low-latency driver provides incredibly low audio latencies when recording, and high-performance converters complete the front end to ensure that you sound your best throughout the entire signal chain. The Quantum ES 4 features four newly designed mic preamps with +75 dB of gain. The high-definition MAX-HD preamps are transparent, low-noise, and digitally-controlled analogue, making them perfect for today’s most popular microphones. Features Features Specification
Inputs and Outputs Microphone Inputs: 4
Guitar Inputs: 2
Line Inputs: 4
Line Outputs (DC coupled): 4
Headphone Outputs: 2
USB-C ports: 1
Aux power ports: 1

AD / DA Conversion
Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192
Bit Depth: 24
Analogue I/O Inputs
Microphone (CH 1 - 2)
Connector Type: 4x Combo-style, XLR / TRS
Max Input: +14 dBu (balanced, minimum gain)
Gain Range: 0 dB to +75 dB
Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (unity gain, reference 1 kHz)
Dynamic Range: 113 dB (A-weighted, minimum gain)
THD+ N: 0.001% (1 kHz, minimum gain)
EIN: -129 dBu (max gain, 150 Ohms, 22 kHz BW, A-weighted)
Input Impedance: 1600 Ohms

Line In (CH 1 - 2)
Connector Type: 4x Combo-style, XLR / TRS
Max input level: +15 dBu (balanced, minimum gain)
Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (unity gain, reference 1 kHz)
Dynamic Range: 114 dB (A-weighted, minimum gain)
THD + N: 0.001% (1 kHz, minimum gain)
Input Impedance: 10K Ohms
Digital Trim: -10 to +10 dB

Instrument In (Ch 1)
Connector Type: 2 x ¼-inch Female
Gain Range: -7 dB to +68 dB
Max input level: +15 dBu (unbalanced, minimum gain)
Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (unity gain, reference 1 kHz)
Dynamic Range: 111 dB (A-weighted, minimum gain)
THD + N: 0.002% (1 kHz, minimum gain)
Input Impedance: 1M Ohms

Outputs
Main Out (CH 1 - 2)
Connector Type: 2x ¼-inch Female, TRS
Max Output Level: +15 dBu (Balanced)
Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (unity gain, reference 1 kHz)
Dynamic Range: 117 dB (A-weighted)
THD + N: 0.001% (1 kHz, +4 dBu)
Output Impedance: 51 Ohms
Trim Range: -inf dB to 0 dB

Headphone Out
Connector Type: 2x ¼-inch Female, TRS Stereo
Max Output Level: 7.5 dBu (50 Ohms)
Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB(unity gain, reference 1 kHz)
Dynamic Range: 111 dB (A-weighted)
THD + N: 0.02% (1 kHz)
Output Impedance: 22 Ohms
Trim Range: -inf dB to 0 dB
Aux Power DC Connector USB-C (USB-C to USB-C cable required, not included)
Aux Power DC Requirements 5VDC, 1.8A
Product Dimensions Length 8.4’’ (213 mm)
Width 6.2’’ (157 mm)
Height 1.9’’ (48 mm)
Weight 1.8 lb (0.81 kg)
Specifications
Computer Interface Type USB 2.0 Type-C
Connections (Input)
  • 2 x 6.35mm (1/4") Instrument
  • 4 x 6.35mm (1/4") TRS Jack
  • 4 x XLR
  • 4 x XLR / Jack Combo
Mic Preamps (Max) 4
Instrument Inputs (Max) 4
Phantom Power Yes
Sample Rate (Max)
  • 176.4 kHz
  • 192 kHz
  • 44.1 kHz
  • 48 kHz
  • 88.2 kHz
  • 96 kHz
Bit Resolution 24
iPad Compatible No
Connections (Output)
  • 2 x 6.35mm (1/4") TRS Jack
  • 2 x Headphone (TRS 6.35mm Jack)
Dimensions (mm) 157 x 48 x 213 WxHxD
DSP Processing No
Misc. Notes
Additional Information
Scan Code LN146801
Model Number 2777700504
GTIN 673454012204
