Palmer ORBIT 11 - Active coaxial 3-way studio monitor
Palmer - ORBIT 11, Active Coaxial 3-way Studio Monitor
Email me when the availability or price changes
Finance this product
- From £24.13 / month (APR 16.9%) for 36 months or 0% for 4 months
- With a 10% deposit from just £17.21 / month (APR 15.9%)
- SCANPROTECT Protect against installation damage for 28 days.
Active Coaxial 3-way Studio Monitor
Palmer - Orbit 11
Engineered in Germany The Palmer ORBIT 11 is an active coaxial 3-way studio monitor designed for mixing, mastering, post-production, sound design, broadcasting, and content creation. Its coaxial True Point Source design combines a 6.5″ midrange driver and a 1″ tweeter on a single acoustic axis and provides consistent 120° × 120° dispersion for stable imaging and reliable balance across the listening area.
The controlled, consistent dispersion pattern helps to maintain reliable balance and translation, while the cardioid front baffle reduces rearward energy to limit room interaction.
Low frequencies are handled by two impulse-compensated 8″ woofers mounted in a sealed, die-cast aluminium enclosure with 5 to 16 mm wall thickness, which is designed to counteract mechanical forces and minimise cabinet vibration, delivering an impressively deep bass response down to 28 Hz.
Internal processing operates at 96 kHz/24-bit with FIR filtering for linear-phase behaviour and time-coherent driver integration.
For fast setup, the top-mounted control panel provides direct access to the input pad, 3-band EQ, Desk and Rear Wall presets, and an 80 Hz high-pass filter. Connectivity options include a balanced XLR line input and AES3 via XLR, with an AES3 Thru output for daisy-chaining.
For wall or ceiling installation, the ORBIT 11 features threaded mounting points and an M8 eye-bolt point for safety attachment, and it is compatible with the Gravity Tilt-and-Swivel Mount GSPWMBS20B.
Engineered in Germany with musical sensitivity, the ORBIT 11 is built for reliable monitoring with time-coherent reproduction and extended low-frequency response, made for those who listen.
116 dBMax. SPL peak
28 - 28,000 HzFrequency response (-3 dB, rel. Avg)
1,000 WPeak output power
at a glance
• Coaxial true point source (6.5" mid + 1" tweeter)
• True 3-way design for full-range accuracy and clarity
• Cardioid design for controlled directivity and reduced room interaction
• FIR filters for linear phase with minimal latency
• Advanced low-end design improves wall coupling and reduces cancellations
• High-resolution 96 kHz / 24-bit DAC and DSP
• Die-cast aluminium housing for ultra-low resonance
Palmer Orbit11 | For Those Who Listen
The Tech Spec
| Features | Specification | General | Type
Active Peak output power 1,000 W RMS output power 400 W Amp class Class D Max. SPL peak 116 dB Frequency response (-3 dB, rel. Avg) 28 - 28,000 Hz Crossover frequency 250 Hz / 1800 Hz Beam angle 120° (hor.) / 120° (vert.) Number of inputs 2 Number of outputs 1 Protection features Limiter, Multiband Limiter, Overheating Colour Black |
|---|---|
| Inputs | Number of AES3 inputs
1 AES3 connector type XLR 3-pole female Number of line inputs 1 Line-In connector type XLR 3-pole female |
| Line input performance | Nom. Sensitivity (< 1% THD, 1 kHz, max. Gain)
0 dBu Nom. input clipping, balanced (< 1% THD, 1 kHz, unity) 22 dBu Input impedance (balanced) 10 kΩ |
| Outputs | Output signal type
AES/EBU Number of AES3 outputs 1 AES3 outputs connector type XLR 3-pole female |
| Signal processing | AD/DA converter bit depth
24 Bit AD/DA converter sampling rate 96 kHz Min. Signal-to-noise ratio (SNR) 103 dB Max. THD+N (1 kHz, +4 dBu, unity, unweighted) 0.01 % Max. THD+N (30 Hz, +4 dBu, unity, unweighted) 0.02 % |
| Bass driver | Size
8 " Quantity 2 Magnet Ferrite Voice coil 1.5 " |
| Mid range | Size
6.5 " Voice coil 2 " Magnet Ferrite |
| Tweeter | Driver size
1 " Magnet Neodymium Voice coil 1 " |
| Dimensions & weight | Width
217 mm Height 293 mm Depth 292 mm Weight 13.9 kg |
