NVIDIA Single-port 400Gb/s OSFP DR4 Single Mode Transceiver for ConnectX-7
NVIDIA Single-port 400Gb/s OSFP DR4 Single Mode Transceiver for ConnectX-7
Scan code: LN148892 Manufacturer code: 980-9I31N-00NM00
£3,359.99Item currently awaiting an ETA
Pre Order
Pre order
  • Thumbnail 1 : NVIDIA Single-port 400Gb/s OSFP DR4 Single Mode Transceiver for ConnectX-7
  • Thumbnail 2 : NVIDIA Single-port 400Gb/s OSFP DR4 Single Mode Transceiver for ConnectX-7
  • Thumbnail 3 : NVIDIA Single-port 400Gb/s OSFP DR4 Single Mode Transceiver for ConnectX-7
  • Thumbnail 4 : NVIDIA Single-port 400Gb/s OSFP DR4 Single Mode Transceiver for ConnectX-7

NVIDIA Single-port 400Gb/s OSFP DR4 Single Mode Transceiver for ConnectX-7

NVIDIA MMS4X00-NS400 OSFP DR4 Single Mode Transceiver, Single Port, 400Gb/s, 100m, MPO/APC Connector, Hot Pluggable
MORE INFO
MORE INFO

Scan code: LN148892 Manufacturer code: 980-9I31N-00NM00
£3,359.99
£5.48 NEXT DAY DELIVERY
Item currently awaiting an ETA
Pre Order
Pre order

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • From £94.74 / month (APR 16.9%) or 0% for 4 months
    Monthly Payment: £280.00
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £3,359.99
    Total inc. interest: £3,359.99
    Monthly Payment: £140.00
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £3,359.99
    Total inc. interest: £3,359.99
    Monthly Payment: £117.66
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £3,359.99
    Total inc. interest: £4,235.68
    Monthly Payment: £94.74
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £3,359.99
    Total inc. interest: £4,547.30
    Example
    Minimum Spend: £99
    Instalment Rate: N/A
    Cost of purchase: £99
    Total inc. interest: £99
    If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

    Representative Example:

    Purchase Rate: 23.9% p.a. (variable)

    Representative: 23.9% APR (variable)

    Assumed Credit Limit: £1,200

    Subject to status. Terms and Conditions apply.
  • With a 10% deposit from just £89.29 / month (APR 19.9%)
Product Overview

NVIDIA MMS4X00-NS400 Single-port 400Gb/s OSFP Single Mode DR4 Transceiver

The NVIDIA MMS4X00-NS400 is an InfiniBand (IB) and Ethernet (ETH) 400Gb/s, Single-port, OSFP, DR4 single mode parallel transceiver using a single, 4-channel MPO-12/APC optical connector. The Datacenter Reach 4-channel (DR4) design uses 100G-PAM4 modulation and has a maximum fibre reach of 100-meters and assumes two optical patch panels in the link. It has identical design and internals as the QSFP112 version with different connector shells. The transceiver firmware supports both InfiniBand and Ethernet and is automatically enabled depending on the protocol of the connected switch. The OSFP shell has a flat-top and utilizes the riding heat sink on the ConnectX-7 connector cage.

Please Note: When linked to 1:2 splitter fibre cable split end has only 2 channels and will activate only 2-channels in the 400G transceiver automatically creating a 200G speed and reducing power consumption. Single mode optics are denoted by a yellow-coloured pull tab and optical fibre. Green plastic shell on the MPO-12/APC optical connector denotes Angled Polish Connector (APC) and is not compatible with the aqua coloured Ultra-flat Polished Connectors (UPC).


Features

• Used in ConnectX-7/OSFP adapters linked to Twin-port transceivers in 2x400G IB/EN switches.
• IB and ETH support.
• 400G DR4 single mode transceiver with 100m max reach.
• 4-channels of 100G-PAM4 electrical and optical modulation.
• 1310nm EML single mode laser (Class 1 laser safety).
• OSFP connector shell. With a single MPO-12/APC optical connector.
• 9W max (4-channels), 5W max (2-channels).
• Single 3.3V power supply.
• Hot pluggable, RoHS compliant.
• Adaptive Tx input equalizer.
• OSFPmsa.org compliant and CMIS 4.0 compliant.

Specifications
Edition
Form Factor OSFP
Total Network Ports 1 x OSFP
PoE Support Type
No. of Ports Providing PoE
Other Non-Network Ports
Switching Capacity
Non-Blocking Throughput
Forwarding Rate
MAC Address Table Size
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
Acoustic Noise
Max. Power Consumption
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply
Material Fibre
Includes
Dimensions (WxHxD) 22.58±0.10 x 14.15 x149.20 mm
Weight
Additional Information
Scan Code LN148892
Model Number 980-9I31N-00NM00
GTIN 7290110491154
