NUX Zeus Guitar Pedal Power Supply
NUX - Zeus, Low Noise Isolated Pedal Power Supply, 6 x 9V / 500mA Inputs, 3 x 9V/12V/18V Adjustable Inputs
Email me when the availability or price changes
Finance this product
- Spend over £280.00 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
- SCANPROTECT Protect against installation damage for 28 days.
Isolated Pedal Power Supply
NUX - Zeus
powerful integrated percussion padAs a musical instrument brand, NUX have already built lots of pedals and multi-effects. For users who use high gain distortion pedals always have headache with the power supply. The DC daisy-chain can drive several pedals, but the ground noise will occur easily especially while you connect analogue pedals and digital pedals at the same time. To be an industry pioneer, NUX has the mission to build a reliable, extreme-low-noise, light-weight, universal power, high current, all-isolated power supply.
Zeus provides 10 high current isolated DC power. It equips 10 isolated switching power transformers to offer clean and stable source for your pedals. As a modern musician, guitarists like digital post effects like Eventide, Strymon etc. So Zeus comes with 3 adjustable high current outputs (9v/500ma | 12v/300ma | 18v/200ma), and 1 tweakable high current output (6v~9v~12v). It means you can use Fuzz or Phaser with the tweakable output to find the best sound. For working musicians, Zeus has USB port for your mobile device charging. Zeus’ universal AC power in can let you work all the world without any AC mistake. It’s reliable and durable to power your pedals.
At A Glance
• 6 x 9V / 500mA inputs
• 3 x 9V/12V/18V adjustable inputs
• 6V~12V tweakable input
• USB 5V/1.5A for Pad
• Self-Regulated Output (Ultra Low Impedance)
• Universal AC Power (100V~240V World Tour Ready)
• Tweakable Dial Control (Sag or Rise for the best sounding)
• Optical Negative Feedback Control
• Extremely Low Noise
The Tech Spec
| Features | Specification | AC Power Input | 100~240V AC 50/60 Hz |
|---|---|
| DC Outputs | 9V / 500mA*6, 9V/12V/18V adjustable*3, 6V~12V tweakable*1, USB 5V/1.5A for Pad |
| Cables | DC LINK CABLE (2.1MM BARREL CONNECTORS-RIGHT-ANGLE TO STRAIGHT ENDS) 50CM*5 DC LINK CABLE (2.1MM BARREL CONNECTORS – RIGHT-ANGLE TO STRAIGHT ENDS) 30CM*5 REVERSE POLARITY CABLE-2.1MM RIGHT-ANGLE 50CM*1 3.5MM MINI PLUG CABLE-RIGHT-ANGLE 50CM*1 HX CURRENT DOUBLER ADAPTOR (2*2.1MM JACK TO 2.5MM RIGHT-ANGLE PLUG) 10CM*1 |
| Dimensions | 195mmx101mmx42mm |
| Weight | 658g |
