Scan code: LN110294 Manufacturer code: WAX610-100EUS

NETGEAR WAX610 Wireless WiFi6 Dual-Band 2.5GbE WiFi Access Point

NETGEAR WAX610-100EUS, Business Managed WiFi Access Point, MU-MIMO, Dual-Band (600+1200Mbps), 2.5GbE, 802.11ax, PoE

Thumbnail 1 : NETGEAR WAX610 Wireless WiFi6 Dual-Band 2.5GbE WiFi Access Point Thumbnail 2 : NETGEAR WAX610 Wireless WiFi6 Dual-Band 2.5GbE WiFi Access Point Thumbnail 3 : NETGEAR WAX610 Wireless WiFi6 Dual-Band 2.5GbE WiFi Access Point Thumbnail 4 : NETGEAR WAX610 Wireless WiFi6 Dual-Band 2.5GbE WiFi Access Point
Scan code: LN110294 Manufacturer code: WAX610-100EUS
£159.98Item overdue since 07 September 2020
Pre order
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Ultimate Speed and Capacity with WiFi 6

Offer customers and employees the best WiFi with higher speeds, less congestion, higher device density and higher battery life for WiFi 6 devices with WAX610.
• Up to 70% higher speed for client devices.
• 4x more client devices per unit (when all devices support WiFi 6).
• Dual-band 4-stream: each unit can deliver up to 1.8 Gbps of data throughput.
• One 2.5G Ethernet port for multi-gig wired network connectivity.
• Enhanced security features.
• SMD IT Budget.
• Centralised remote monitoring and management.

WiFi Security for your Business

Small and medium organizations now enjoy enterprise level security without the enterprise budget. Insight helps you configure and maintain the security of the network easily.
• WPA3 for the highest level of WiFi connection security.
• 8 separate wireless networks (SSIDs) can be used for administration, employees, guests and IoT devices (WiFi surveillance cameras, thermostats, door locks and sensors).
• Separate VLANs for network separation and segregation between admin network, employee, visitor, HR, Finance, etc.
• Peer-to-peer separation: Total user separation on the same VLAN, preventing guest accessing other guests’ devices.
• Dynamic VLAN per RADIUS user assignment, a feature specially designed for businesses who use RADIUS to efficiently manage user accounts and access (Note: Feature available in October 2020 firmware release).

Remote monitoring and management with NETGEAR Insight

• 1-Year Insight subscription included.
• Instant discovery & set-up.
• Local and Cloud monitoring and management through the Insight app or Cloud Portal.
• Remote access and multi-device configuration.
• No additional Cloud controller, appliance, network manager, or PC/server is necessary.
• QR code initial configuration for instant installation.


Insight cloud remote monitoring and management: 1-Year Insight subscription included.
• WiFi 6 Dual Band AX1800 Access Point, up to 1.2Gbps in 5GHz band and 600Mbps in 2.4GHz.
Multi-Gigabit Speed and PoE: Includes a 2.5 Gbps Ethernet port with PoE for high speed and easy wiring.
• Faster and more reliable WiFi due to higher throughput and more coverage with the use of both 2.4Ghz and 5Ghz band simultaneously.
• Ideal for high density WiFi environments, supported by robust and seamless roaming between a large number of WAX610 and other NETGEAR Business WiFi APs.
High Performance: Get 4 Streams of WiFi 6 and speeds up to 1.8 Gb.
Greater Capacity and Battery Life: Enjoy 4X more connection capacity than WiFi 5 with improved efficiency for longer device battery life.
• Compatible with WAC505/510/540 specifically but not WiFi 5 APs in general.
Dual-Band Wireless Mesh: wire-free installation with other WAX610, WAX610Y, WAC540 or WAC564. One of the bands is then shared between the wireless backhaul and the devices.

Networking, Connectivity & Ports
Model WAX610
Form-Factor Desktop
Device Type Wireless Access Point
Compatible Internet Connections Existing WiFi Network
Network Connectivity 10/100/1000/2500
Network Ports 1 x RJ45 10/100/1000/2500 (2.5 Gigabit) for LAN
Other Connectors N/A
USB Applications
Wired Protocols IEEE 802.11i
Total LAN Connections 1
Total WAN Connections
64 Bytes L3 Forwarding Performance
512+ Bytes L3 Forwarding Performance
Wireless Speed N/A
Wireless Protocols
  • IEEE 802.11a
  • IEEE 802.11ac
  • IEEE 802.11ax
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
Wireless Band Dual Band
  • 2.4 GHz
  • 5 GHz
Operation Channel
Wireless Transmitter Power N/A
Antenna Internal 3.8/4.5dBi
Core Features
Router/Modem Processor
Internal RAM Memory
Internal RAM Memory Type
Internal Flash Memory
LED Indicators
  • 1 x 2.4 GHz Wi-Fi LED
  • 1 x 5 GHz Wi-Fi LED
  • 1 x LAN LED
  • 1 x Power LED
Buttons 1 x Reset Button
OS Support
Max. Power Consumption 15.3 W
PSU Type
Security & VPN
Security Protocols
  • MAC Address Authentication
  • WPA
  • WPA2
  • WPA2-Enterprise
  • WPA3
Firewall/NAT No
  • Cloud Access
  • Remote Management
VPN Support
Physical Specifications
Dimensions 160.9 x 160.9 x 33.25 mm (WxHxD)
Weight 412 g
Additional Specifications
Note N/A
Additional Information
Scan Code LN110294
Model Number WAX610-100EUS
GTIN 606449149227

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

12 months
DOA Period:
28 days
RTB Period:
1 months
Manufacturer Contact Details
