Panorama P1 MIDI Controller by Nektar
NEKTAR PANORAMA P1
The Panorama P1 is an incredible controller with some of the most intuitive workflow going. With extremely deep Reason & Cubase implementations, along with vast pre-mapped MIDI setups for Bitwig Studio, Logic Pro, MainStage, Nuendo and Reaper also now available, it means that whatever your choice of sequencer you can focus on your music instead of the equipment.
The enormous controlling power of Panorama P1 is contained in a compact case about the size of a 17" laptop and a crystal clear 3.5" colour TFT display delivers the information you really need, for each mode or menu. Regardless of whether you are operating Cubase, Reason or programming MIDI assignments in internal mode, the display is capable of providing detailed information that makes your workflow extremely fluent and fast.
An almost unrivalled amount of assignable controls makes Panorama the most comprehensive and fully featured MIDI controller around. 16 encoders, 9 45mm faders, 10 LED buttons, 28 buttons and a foot switch jack gives you immediate control of up to 61 parameters at any one time. Settings can be stored in 20 pre-sets with individually save and loadable F-keys maps for more than 1200 combinations.
The Panorama also puts the transport controls right at your fingertips with an extended 11 button transport bar, positions right where you need it controlling: Return to L, Forward to R, Undo, Click on/off, Record Mode, Cycle on/off, Back, Forward, Stop, Play and Record. Using the shift button, these also double up as 11 function buttons each assignable to MIDI commands or even QWERTY macro's.
With those QWERTY macros software that has a ton of features and functions, can now be activated using QWERTY shortcut commands. Assigning a command to a button on the controller so you don't have to be near your computer makes life a lot easier however assigning a string of up to 8 commands takes it to a whole new level. With this powerful feature you could for example enter edit mode, zoom in and select a tool with just one button press. Or create an instrument or effects track and locate a folder containing your pre-sets so you can select them from Panorama, all with one button press and without looking at your computer.
9x 45 mm faders
10x assignable LED buttons
11x dedicated transport buttons
20x preset locations store all settings
11x assignable Function Keys (accessible using shift and transport keys)
Load or Save to any of 10 F-Keys maps
F-Keys assignable even in 3 Reason modes
Foot switch (sustain) 1/4" jack input (pedal not included)
USB port for communication with computer
Weight & Dimensions
Dimensions (L x D x H): 387 x 235 x 51 mm
Weight: 2.8 lbs.
6x dedicated assignable navigation buttons
ASCII / QWERTY macros assignable to buttons and pads
3.5" high-resolution TFT display provides incredible navigation and user visibility
Incredible Cubase, Nuendo & Reason implementations that lets you use your DAW, as if it's hardware
4 modes when used with Cubase, Nuendo or Reason switch between Mixer, Instrument, Transport and Internal
Presets and setup files for major DAW's and VI’s
|Product Type||Midi Controller|
|Connectivity (Input)||2 x 1/4" Balanced / Unbalanced (L/R)|
|Frequency Response (Input)||N/A|
|Frequency Response (Output)||N/A|
|Maximum Input Level||N/A|
|Maximum Output Level|
