Moog SUB37 Analogue Synthesizer
Moog SUBsequent 37 Paraphonic Analogue Synthesizer, 37-Note Keybed, Improved Multidrive, High Power Headphone Output
- By DPD On 7th Aug to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
- Collect instore Collect from our Bolton store, BL6 6PE | Free
Subsequent 37 Synthesizer from Moog
2-note paraphonic analogue synthesizer Introducing the Subsequent 37 from synthesizer gods Moog, this is a 2-note paraphonic analogue synthesizer that builds upon the award-winning design of the ultra-powerful Sub 37 Tribute Edition. Its control panel is home to 40 knobs and 74 switches, placing a vast array of analog sound-design tools and onboard sequencing options immediately at your command.
An Array of Sound Design Tools at your Command
Subsequent 37's Sonic EnhancementsThe Subsequent 37 improves upon its source through the implementation of a number of user-requested sonic and functional enhancements. Each enhancement maintains the magic and character of its predecessor while also providing access to new dimensions of sound and improved playability.
Featuring Multidrive Circuitry
Even More HeadroomThe Sub 37 mixer section has double the headroom of that in the Sub 37 Tribute Edition. This provides access to a new range of classic clean tones in both mono and duo performance modes.
Leveraging the mixer’s newfound flexibility, gain-staging in the Ladder filter has been reshaped to boost harmonic saturation and analogue compression, resulting in an overall richer low end. While a re-tuned Multidrive circuit that extends well beyond the grit and growl of the original Sub 37.
Upgrades all Round
Fantastic optionsIn addition to the sound engine augmentation, each SUBSEQUENT 37 comes with an upgraded keybed for improved playability, a high-powered headphone amplifier strong enough to drive the most demanding headphones, and a software plugin/editor for both Windows and Mac platforms.
The Subsequent 37 put through its Paces
Precision Audio AnalysisIn the spirit of continuous improvement, the award-winning Sub 37 Tribute Edition has been discontinued from production to make way for a new standard: The Subsequent 37. Implementing upgraded sonic modifications and functional enhancements, the Subsequent 37 features increased headroom in the mixer, a modified filter section, re-tuned MultiDrive circuit, high-powered headphone amplifier and an upgraded keybed. The new Subsequent 37 will be the standard production model moving forward.
The Tech Spec
| Features | Specification | Sound Engine Type | Analogue 2x Variable Waveshape Oscillators 1x Square Wave Sub Oscillator 1x Analogue Noise Generator 1 External Input/Filter Feedback |
Number of Keys | 37 | Number of Presets | 256 Presets - 16 Banks x 16 presets | Type of Keys | Semi-weighted with After Pressure |
|---|---|
| Other Controllers | Pitch Bend, Mod Wheel, After Pressure, Velocity |
| Polyphony | Selectable Monophonic or Paraphonic (can be poly-chained) |
| LFO | Triangle, Square, Sawtooth, Ramp, Sample & Hold |
| Filter | 20Hz-20KHz Moog Ladder Filter with 6/12/18/24 dB/Oct Filter Slopes and MultiDrive |
| LCD | 128 X 64 pixel LCD with white backlight |
| Glide Module | Assign to Osc1/Osc2/Both. Type - LCR, LCT, EXP, Gated, Legato |
| Arpeggiator/Sequencer | Up, Down, Order, Random, Latching, Back/Forth, Invert, +/-2 Range, Tie, Rest, MIDI Sync, 64-note sequencer |
| Midi I/O | Din In/Out, and Midi over USB | Audio Inputs | 1 x 1/4" TS |
| Audio Outputs | 1x 1/4" TS, 1x 1/4" TRS Headphones |
| Height | 6.75" |
| Width | 26.75" |
| Depth | 14.75" |
| Weight | 10kg |
