Magewell - 'Ultra Encode HDMI'

Magewell Ultra Encode HDMI

Stream to multiple platforms simultaneouslyIntroducing the Magewell Ultra Encode HDMI Universal Encoder, a powerful solution that lets you effortlessly broadcast your video content across multiple platforms simultaneously. Boasting versatile connectivity options with both Ethernet and Wi-Fi capabilities, this encoder ensures seamless integration into your setup. With HDMI 1.4a input and loop output, 16-channel embedded audio support, and 3.5mm audio input and output, the Ultra Encode HDMI offers a comprehensive suite of features. Capture stunning DCI 4K60 input and encode up to 1080p60 in H.264/265 with 2-channel AAC audio, providing high-quality streams. The dual streaming function enables a 16 Mb/s main stream and a 2 Mb/s sub stream, giving you flexibility in delivering your content. Whether you prefer to embed audio into the encoding stream or extract it via the 3.5mm line out, the Ultra Encode HDMI offers customizable options. Stream effortlessly to two destinations simultaneously, with native support for leading platforms such as Facebook, YouTube, and Twitch. Choose from a variety of streaming protocols, including RTSP, RTMP, RTMPS, SRT Caller, SRT Listener, NDI|HX2, HLS, TS over UDP, and TS over RTP. Take control with ease through the Web UI or HTTP APIs, and enjoy the flexibility of desktop use or secure mounting using the included T-Bracket with a 1/4"-20 thread.

Up to DCI 4K60Input/Loop Out

Dual Stream H.264/265Encoding with AAC

16-Channel HDMIEmbedded Audio

diagram of the magewell ultra encode hdmi

The Tech Spec

Features Specification
Input Features Video
Supports HDMI 1.4a, DVI-D
Typical resolution/frame rate:
4096x2160 60fps 4:2:0
4096x2160 30fps 4:4:4/4:2:2
4096x2160p/3840x2160p 23.98/24/25/29.97/30/59.94/60
2560x1080p 23.98/24/25/29.97/30/50/59.94/60
1920x1080p 23.98/24/25/29.97/30/50/59.94/60/100/119.88/120
1920x1080i 25/29.97/30/50/59.94/60
1280x720p 23.98/24/25/29.97/30/50/59.94/60/144
720x576p 50/100/144
720x576i 25/50
720x480p 59.94/60/144
720x480i 29.97/30
Colour depth: 8/10/12-bit
Colour sampling: RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2
Custom EDID

Audio
HDMI embedded audio: 8-Channel, 24-bit, 192kHz sample rate
Audio from 3.5 mm LINE IN: 2-Channel, 24-bit, 192kHz sample rate
Encode Video
Bitrate: 16Mbps
Dual-stream encoding: main stream and sub stream
Main stream Resolution/frame rate:
2048x1080p/1920x1200p 60/59.94/50/30/29.97/25/24/15/10/5
1920x1080p/1920x720p 60/59.94/50/30/29.97/25/24/15/10/5
1664x936p/1600x1200p/1600x900p 60/59.94/50/30/29.97/25/24/15/10/5
1440x1080p/1440x900p 60/59.94/50/30/29.97/25/24/15/10/5
1280x1024p/1280x960p/1280x800p/1280x720p 60/59.94/50/30/29.97/25/24/15/10/5
1024x768p 60/59.94/50/30/29.97/25/24/15/10/5
960x540p/800x600p 60/59.94/50/30/29.97/25/24/15/10/5
768x576p/720x576p/720x540p/720x480p 60/59.94/50/30/29.97/25/24/15/10/5
640x480p/640x360p 60/59.94/50/30/29.97/25/24/15/10/5
480x360p/480x270p 60/59.94/50/30/29.97/25/24/15/10/5
Sub stream
Supports enabling/disabling sub stream
Resolution/frame rate:
1920x1080p/1920x720p 60/59.94/50/30/29.97/25/24/15/10/5
1664x936p/1600x1200p/1600x900p 60/59.94/50/30/29.97/25/24/15/10/5
1440x1080p/1440x900p 60/59.94/50/30/29.97/25/24/15/10/5
1280x1024p/1280x960p/1280x800p/1280x720p 60/59.94/50/30/29.97/25/24/15/10/5
1024x768p 60/59.94/50/30/29.97/25/24/15/10/5
960x540p/800x600p 60/59.94/50/30/29.97/25/24/15/10/5
768x576p/720x576p/720x540p/720x480p 60/59.94/50/30/29.97/25/24/15/10/5
640x480p/640x360p 60/59.94/50/30/29.97/25/24/15/10/5
480x360p/480x270p 60/59.94/50/30/29.97/25/24/15/10/5
H.264/H.265 (HEVC) Codec:
System timecode or RP–188 standard timecode for SEI Message setting
H.265 (HEVC) SEI message supports carrying interlacing signal mark
Video aspect ratio conversion

Audio
Encoding 2-channel AAC
Bitrate: 256/192/128/96/64/48/32/16 kbps
Output source embedded audio and line in through LINE OUT
Live stream Natively supports streaming to:
Twitch
YouTube, publishing to timeline or a new event and setting “made for kids”.
Facebook, enabling backup stream and publishing to timeline or a new event.
Supports streaming protocols:
RTSP
RTMP/RTMPS
SRT Caller/SRT Listener
NDI®|HX2
HLS
TS over UDP/TS over RTP
TVU ISSP
Supports sessions over the same streaming protocol, such as:
Up to 6 sessions of TS over RTP and TS over UDP simultaneously
Up to 6 sessions of SRT Caller and SRT Listener simultaneously, containing one SRT Listener session at most (max 8 clients simultaneously)
Up to 6 sessions of RTMP and RTMPS simultaneously
Supports streaming only 1 session of HLS, RTSP, or NDI|HX2
Supports specifying a video stream and an audio stream for each streaming session
Web UI Access Web UI via PC and smartphone
View real-time device status
Preview encoded video
Set input sources
Customize encoding parameters
Manage streaming destinations, start/stop streaming, view streaming status
Manage recording tasks
Set up to 8 overlays for each stream, including text, picture, and clock
Update firmware
Supports registering Magewell Control Hub for centralized management
Supports Microsoft Edge/Firefox/Chrome/Safari/Opera web browsers
API Provides APIs for 3rd party control system
Network Connections Ethernet: 1x RJ45 port, 10/100/1000 Mbps Base-T
Wi-Fi: 802.11 a/b/g/n/ac, Station and AP modes supported
4G/5G USB modem (not supplied)
USB Net
Input/Output Ports 2 x HDMI ports
1 x 3.5mm LINE IN
1 x 3.5mm LINE OUT
1 x USB Type-A
LED Indicators LEDs indicating the status of power, input signal, streaming, Ethernet and Wi-Fi connection
Power Supply and Consumption DC 5V/3A
Max power consumption: ~8.62W
Form Factor 106.6mm x 106.2mm x 25mm
Accessories 1 x 5V Power Adapter
1 x HDMI Cable
1 x USB Type A to Type B cable
1 x Wi-Fi Antenna
1 x T-bracke
Screw Mounting Hole 2 x M3 threaded hole
A standard 1/4"-20 socket provided by T-bracket
Working Environment Operating temperature: 0 to 40 deg C
Storage temperature: –20 to 40 deg C
Relative humidity: 5% to 90% non-condensing
