Magewell Pro Convert AES67

Magewell Pro Convert AES67, Multi-format Bidirectional Analog/IP Audio Converter

Scan code: LN154575 Manufacturer code: 642400000

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores
  • paypal short logo blue 0% UP TO   MONTHS Spend £99 or more and choose PayPal at checkout. More info
  • SCANPROTECT Protect against installation damage for 28 days. More info
Product Overview

A multi-format IP audio converter and capture device


The Pro Convert AES67 multi-format IP audio converter and capture device from Magewell. Encode or decode analog audio between a 3.5mm or XLR input and AES67 multicast streams from the 2-channel 3.5mm unbalanced input and output, and 2-channel 4.4mm balanced input and output. The RJ45 ethernet port transmits or receives up to 8-channel AES67 encoded multicast and unicast encoded streams and 4-channel 240bit streams for use with Icecast, SRT, or NDI streams.


The converter can also output UAC audio via the USB-B port for use with applications that support UAC. The included XLR cable adapters plug into the 4.4mm ports to connect various XLR sources and destinations. You can configure and control the converter using an easy-to-use WebUI or Magewell Cloud.



Features

Input/Receiving Features
Receiving up to 46 audio channels
• 1 x 2-channel 3.5mm unbalanced in
• 1 x 2-channel 4.4mm balanced in
• 1 x 4-channel 24-bit/48k UAC in
• Receiving 4 x 8-channel 24-bit AES67 streams both multicasted and unicasted
• It is optional to receive 1 x 4-channel 16-bit SRT stream or 1 x 4-channel 16-bit NDI® stream or 1 x 4-channel 16-bit Icecast stream

Output/Sending Features
• 1 x 2-channel 3.5mm unbalanced out
• 1 x 2-channel 4.4mm balanced out
• 1 x 4-channel 24-bit/48k UAC out
• Multicast and unicast up to 8 x 8-channel 24-bit AES67 streams
• Encoding 1 x 4-channel 16-bit audio for Icecast/SRT/NDI® stream simultaneously

Audio routing and mixing Features
• Any analog or IP-based input channel can be routed and mixed into any analog, IP or UAC output via a web-based user interface

Others
• Plug-and-play as a UAC device
• Provide comprehensive information regarding the device and signals in real-time
• Remote control via Web GUI and Control Hub
• Support USB RNDIS/ECM
• Provide HTTP APIs
• Provide Crestron Plugins
