Mackie Big Knob Studio Monitor Controller and 2 x 2 USB Audio Interface
Mackie Big Knob Studio Monitor Controller and 2 x 2 USB Audio Interface, Analogue Volume Control, Onyx Mic Preamps
Studio Monitor Controller
Mackie - 'Big Knob'
'more than meets the eye'Studios of any size can benefit from the professional source/monitor selection and precise level control of the Big Knob Series. Plus, with the addition of high-resolution Onyx™ USB recording and playback, studios get a powerful, hybrid solution that is truly greater than the sum of its parts.
Sure, we all know the Mackie Big Knob is the go-to monitor controller for studios the world over. But, now that we've added in the high-resolution goodness of an Onyx recording and playback solution, Big Knob truly becomes the nerve center for your studio. Or, if you are looking for excruciatingly simple volume control/monitor switching, the Big Knob Passive delivers at an amazing price. No matter what size studio, Big Knob is always at the top of the recording studio equipment shopping list.
24-Bit / 192 kHzResolution
USB 2.0USB I/O
20 Hz - 20 kHzFrequency Response
at a glance
• Choose between 3 sources and 2 monitor pairs
• Independent trim on all sources and monitor outs
• Classic Big Knob volume control
• Mono, mute and dim functions
Killer Mackie Features!
mackie - big knob Take a look at just some of the reasons Mackie's 'Big Knob' Series offers all the solutions you're looking for!
Than meets the eyeThe Mackie Big Knob has proven itself for more than a decade as the go-to monitor controlling solution for home and professional studios. The all-new Big Knob family takes the best of this classic workflow, delivering the right solution for the modern studio.
Hi-RezBoth the Big Knob Studio and Big Knob Studio+ offer high-resolution USB interfacing at resolutions up to 192 kHz, featuring dual Onyx mic preamps, delivering an ultra-wide 60 dB of gain range and award-winning sound quality.
Flexible IntegrationThe expanded Big Knob lineup offers models with unique feature sets and I/O to suit a huge range of applications. Features like dual headphone outs, a dedicated amp-driven studio out, a true cue mix and more ensure Big Knob will fit right into your studio or workspace.
Free Recording Software!
WAVEFORM OEM™ DAWWaveform OEM is a multi award-winning workstation, featuring powerful and creative tools to inspire the modern musician. Unlike typical ‘Lite’ versions, it does not impose any restrictions – you get unlimited track count, powerful features, compatibility with all popular plug-ins and efficient performance on MacOS®, Windows®, and Linux® operating systems.
Big Knob Series - An Overview
Keeping your hands on the mix is just part of the job. Precision level control, swapping between monitors and routing sources all make your mix better. That’s why the Big Knob has been the go-to studio command center for more than a decade. But, studios are different now. More nimble and flexible than ever. It’s time for a new tool.
The all-new Big Knob Series expands functionality big time, with built-in high-resolution recording and playback up to 192kHz. There’s three models so you always get the features you need and maybe a couple that allow you to grow. The all-new Big Knob Series is here.
The Tech Spec
| Features | Specification | Inputs | 2 x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Inputs 2 x 1/4" TRS Balanced/Unbalanced Line Inputs 1 x 1/8" / 3.5 mm TRS Unbalanced Stereo Input |
|---|---|
| Outputs | 2 x 1/4" TRS Balanced/Unbalanced 2-Track Line Outputs 4 x 1/4" TRS Balanced/Unbalanced Monitor Outputs 2 x 1/4" TRS Unbalanced Headphone Outputs |
| USB I/O | 1 x USB 2.0 Type-B |
| Resolution | 24-Bit / 192 kHz |
| Frequency Response | 20 Hz to 20 kHz (±0.5 dB, Unity Gain, +4 dBu Input) |
| Noise | Mic Inputs to Outputs: < -125 dBu RMS, A-Weighted (150 ohms Terminated, 22 kHz Bandwidth) Line Inputs to Outputs: < -90 dBu RMS, Unweighted (150 ohms Terminated, 22 kHz Bandwidth) |
| THD + N | <0.01% Unweighted (Unity Gain, 1 kHz at +4 dBu Input, 80 kHz Bandwidth) |
| Crosstalk | < -60 dB at 1 kHz (Unity Gain, -1 dBFS Input) |
| Attenuation | Muted: -60 dB Dim: -20 dB |
| Maximum Input Level | +22 dBu |
| Maximum Output Level | +22 dBu |
| Power Requirements | 100 to 240 VAC, 50/60 Hz, 0.75 A via Universal Power Supply |
| Dimensions (W x D x H) | 6.4 x 9.9 x 3.2" / 16.3 x 25.1 x 8.1 cm |
| Weight | 3.5 lb / 1.6 kg |
