Kiloview D350 4K H.265/H.264 IP Video Decoder
Kiloview D350 4K IP Video Decoder, H.265/H.264, 1x 3G-SDI, 2x HDMI 2.0, 2x RJ45, 16 Channel, USB-A/C
Email me when the availability or price changes
Kiloview - 'D350 4K H.265/H.264 Decoder'
Professional 4K Video DecoderThe Kiloview D350 is a professional hardware decoder capable of simultaneously decoding up to 9 network video streams and outputting via both 3G-SDI and HDMI interfaces in synchronisation with up a 4Kp60 output resolution.
The built-in LCD screen allows users to monitor the IP status and decoding parameters in real-time. The D350 additionally allows dynamic switching, background/Logo overlay, custom split display of a video stream and other features.
Up to 16 Channel Decoding
Outstanding Decoding PerformanceThe D350 concentrates on every decoding detail for a better decoding quality.
D350 supports simultaneous decoding of up to 16 channels of video streams(It depends on the resolution*). It allows for customization of multi-output display including grid and PIP. With D350’s incredible performance and three output ports (two HDMI 2.0 ports and one 3G-SDI port), It’s also capable for outputting in three ways: Independently, combine multi-channels video flows or replicate of one single flow to stream simultaneously.
Besides outstanding performance in video decoding, D350 is also super powerful in audio decoding. With a long list of audio formats supported including AAC/AAC/MPEG-4/MPEG-2/G.711/Opus/LPCM. It’s also capable of switching audio On/Off, audio mix and audio gain in real time to output alternatively through its HDMI ports, SDI port and 3.5mm line out port.
*Up to 16 channels of 1080P30, 9 channels of 1080P60, 4 channels of 4KP30, 2 channels of 4KP60 or 1 channel of 4Kp60 in Full NDI.
Wide Protocol Support including NDI
Full protocols Supported to meet all your demandsTo accommodate your various workflows, the D350 is compatible with all protocols, including NDI|HX2, NDI|HX3*, Full NDI, SRT, RTMP, RTMPS, HLS, TS over UDP, RTP, and RTSP.
* Support of NDI|HX3 is still in beta version.
Choose Your Output
Multiple Interfaces, Customisable OutputsD350 allows users to freely choose the output interface among 3G-SDI and 2 of 4K HDMI for outputting the same or different video sources in synchronization.
*Note: HDMI output up to 3840×2160 @60Hz, SDI output up to 1920×1080 @60Hz and can support frame rates such as 59.94/29.97
Less than 200ms Latency
Low Latency and High QualityThe D350 guarantees outstanding image quality and low transmission latency with a decoding delay of less than 200 ms and a packet loss rate of less than 10%.
Built-In LCD Display
LCD Screen for Realtime Status MonitoringAs an update to the D300, D350 is equipped with a 0.9-inch LCD screen for a better user experience. With the built-in LCD screen, users can easily check the IP and decoding status in real-time.
RTMP Support
RTMP Server SupportedWith RTMP Server, D350 can simplify the video decoding workflow by directly accessing a video encoder and outputting video streams through RTMP without any relay platform.
Customisable Output Display
User-Defined Display for Free OutputFree Layout: The users will be able to customize the output display in grids or a free layout like PIP, PBP, or POP.
Free Resolution: D350 also supports the adjustable output resolution, de-interlace, and frame rate.
9 Preview Streams
16 Preview + 9 Output with Dynamic SwitchingYou will be able to pick 9 of the streams for output on displaying screen from the 16 real-time video streams or images previewed on the web page. Unlimited video sources can be added, any video source can be freely selected for decoding, and dynamic switching can be performed.
Customisable Graphics
Customized Output Background and OSDUsers can configure background subjects including LOGO, frame, and graphic overlay with the D350. The PVW window will also display the personalized information at the same time.
Intercom via USB
Audio and IntercomEnd-to-end real-time intercom can be realized through the USB expansion headset. For group communication, you can deploy the Kiloview Intercom Server (KIS).
Kilolink Server
Centralized Management with KiloLink ServerD350 can connect to the KiloLink Server seamlessly which can optimize media transmission by any Kiloview products using any available network links. It helps to manage, monitor and control all the devices throughout the process.
D350 Applications
ApplicationSimultaneous decoding of 9 channels of network streams and split-screen output, network pull streaming on-screen/into the switcher, SRT video point-to-point transmission, program shooting monitoring, monitoring, video conferencing, audio and video engineering, conference engineering, etc.
The Tech Spec
| Features | Specification | Video Output | 2×HDMI2.0, up to 4KP60 1×3G-SDI, up to1080P60 |
|---|---|
| Audio Output | SDI/HDMI embedded or analog audio output |
| Video Formats | H.264(AVC) compatible with Baseline/Main/High Profile, up to Level 5.2； H.265(HEVC) compatible with Main Profile, up to Level 5.1； SpeedHQ(NDI High-bandwidth) |
| Video Decoding Capability | H.264(AVC)/H.265(HEVC): Up to 16 channels in 1080P30, 9 channels in 1080P60, 2 Channels in 4KP60 Full NDI: Up to 6 channels in 1080P30, 4 channels in 1080P60 or 1 channel in 4KP60 |
| Audio Formats | AAC/MPEG-4/MPEG-2/G.711/Opus/LPCM |
| Latency | FULL NDI&NDI|HX：＜50ms； Others：100~120ms(Adjustable) |
| Streaming Protocols | FULL NDI/NDI|HX2.0/NDI|HX3.0/SRT/RTMP/RTMPS/ HLS/TS over UDP/RTP/ RTSP |
| Layouts | 1/2/3/4/5/6/7/8/9 |
| Intercom | Yes |
| Display | 0.96”OLED Screen |
| OSD | Yes |
| Network | 2×100M/1000M RJ-45 Ethernet ports |
| USB | 1*USB Type-A, 1*USB Type-C |
| Power Supply | 12V, 1A DC |
| Tally | Yes |
| Management | WebUI/Kiloview KiloLink Server |
| Firmware Upgrade | WebUI/Kiloview KiloLink Server |
| Power Consumption | 7W(MAX) |
| Size | 162.85×104.00×25.00mm |
| Weight | 328.18g |
| Operating Temperature | -20~60°C |
