Intel 8 Core Xeon 6507P Granite Rapids Server CPU/Processor

Intel® Xeon® 6507P processor

The Intel® Xeon® 6507P processor is a high-performance, server-grade CPU designed for modern data centers, cloud computing, and AI workloads. Featuring 8 cores and 16 threads, it operates at a base frequency of 3.50 GHz with a turbo boost of up to 4.30 GHz, ensuring excellent performance for demanding tasks. Built on Intel's advanced 3 process technology, it includes a 48 MB cache and supports DDR5 memory at speeds up to 6400 MT/s for enhanced data throughput. With scalability for dual-socket (2S) configurations, 88 PCIe 5.0 lanes, and advanced technologies like Intel® Deep Learning Boost and Advanced Matrix Extensions (AMX), the Xeon® 6507P delivers robust compute power and efficiency. Its thermal design power (TDP) is rated at 150W, with a maximum thermal specification (DTS Max) of 103°C, making it reliable for intensive workloads while maintaining energy efficiency.

Intel Xeon 6 processors with Performance-cores (P-cores)

Intel Xeon 6 processors with P-cores are optimised for high performance per core. With more cores, double the memory bandwidth, and AI acceleration in every core, Intel Xeon 6 processors with P-cores provide twice the performance for the widest range of workloads, including AI and HPC.1,2 Intel Xeon 6 processors with P-cores excel at a wide range of workloads, delivering better performance than any other general-purpose CPU for compute-intensive workloads like AI inference and machine learning (ML). Intel Xeon 6 processors with P-cores are great for public cloud workloads because they offer improved performance per vCPU for floating point operations, transactional databases, and HPC workloads.

• Cores and Threads: 8 cores, 16 threads
• Base Frequency: 3.50 GHz
• Max Turbo Frequency: 4.30 GHz
• Cache: 48 MB
• Memory Support: DDR5 up to 6400 MT/s, max memory size 4 TB
• Scalability: Dual-socket (2S) configuration
• PCIe Lanes: Up to 88 PCIe 5.0 lanes
• TDP: 150 W
• UPI Links: 3 at 24 GT/s
• Lithography: Intel 3 (5nm-class)
• Socket: FCLGA4710
• Max Operating Temperature (DTS Max): 103°C
