Intel 12 Core Xeon 6505P Granite Rapids Server CPU/Processor

Intel® Xeon® 6505P processor

The Intel® Xeon® 6505P processor is a powerful and scalable server-grade CPU designed to meet the demands of modern computing environments. Featuring 12 cores and 24 threads, this processor delivers exceptional performance with a base frequency of 2.20 GHz and a turbo boost of up to 4.10 GHz. Built for scalability, the Xeon® 6505P supports dual-socket (2S) configurations, allowing two processors to work seamlessly together for enhanced performance in data centers, cloud computing, and AI workloads. With 48 MB of cache, support for DDR5 memory at speeds up to 6400 MT/s, and up to 88 PCIe 5.0 lanes, it ensures high-speed interconnectivity and resource optimization. Additionally, its advanced Intel 3 lithography and efficient 150W TDP make it ideal for handling demanding tasks while maintaining energy efficiency.

Intel Xeon 6 processors with Performance-cores (P-cores)

Intel Xeon 6 processors with P-cores are optimized for high performance per core. With more cores, double the memory bandwidth, and AI acceleration in every core, Intel Xeon 6 processors with P-cores provide twice the performance for the widest range of workloads, including AI and HPC.1,2 Intel Xeon 6 processors with P-cores excel at a wide range of workloads, delivering better performance than any other general-purpose CPU for compute-intensive workloads like AI inference and machine learning (ML). Intel Xeon 6 processors with P-cores are great for public cloud workloads because they offer improved performance per vCPU for floating point operations, transactional databases, and HPC workloads.

• Cores and Threads: 12 cores, 24 threads
• Base Frequency: 2.20 GHz
• Max Turbo Frequency: 4.10 GHz
• Cache: 48 MB
• Memory Support: DDR5 up to 6400 MT/s, max memory size 4 TB
• Scalability: Dual-socket (2S) configuration
• PCIe Lanes: Up to 88 PCIe 5.0 lanes
• TDP: 150 W
• UPI Links: 3 at 24 GT/s
• Lithography: Intel 3
