Highpoint ThunderBolt 3 to 4x USB 3.1 External Adapter Box
HighPoint RocketStor 6661A-4USB Thunderbolt3 to 4x USB 3.1 10Gb/s External Enclosure
Email me when the availability or price changes
- SCANPROTECT Protect against installation damage for 28 days.
Outstanding Performance without Compromise
Experience the performance of Thunderbolt™ and the convenience of USB, without compromise. The RocketStor 6661A-4USB allocates the 40Gb/s of transfer bandwidth provided by Thunderbolt™ 3 connectivity to power four dedicated 10Gbs USB 3.1 channels. This 4-in-1 combination is ideal for high-performance USB storage configurations but is also fully capable of supporting any USB 3.1/3.0/2.0 USB device or peripheral such as input devices, printers & scanners, or flash drives.
The RocketStor 6661A-4USB takes full advantage of HighPoint’s performance driven USB 3.1 architecture. Unlike conventional USB cards, docks and hubs, which split a single 10Gb/s channel between two or more ports, the RocketStor 6661A-4USB provides dedicated 10Gb/s USB 3.1 transfer bandwidth for each Type-A connector. This unique approach to USB connectivity is ideal for high-speed USB-based storage applications.
• Integrated 4-Port 10Gb/s USB 3.1 Controller.
• 1x Thunderbolt™ 3 to PCIe Expansion Unit.
• 1x 40Gb/s Thunderbolt™ 3 cable.
• 1x External Power Supply.
• 1x Power Cord.
• Quick Installation Guide.
• Optional Accessories Not Included.
Thunderbolt™ 3 Cables
• Look at LN89242 - TB3-040G-505 - 0.5M, 40Gb/s cable.
• Look at LN89240- TB3-040G-510 - 1M, 40Gb/s cable.
USB 3.1 Cables
• Look at LN90432 - USB-A31-1MC – 1M, USB-A to USB-C cable.
• Look at LN90434 - USB-A31-06B – 1M, USB-A to Micro-B cable.
System Requirement
• Computer with a USB-C (Thunderbolt™ 3).
• Computer with a Thunderbolt™ 2 (via Thunderbolt™ 3 to Thunderbolt™ 2 Adapter).
• macOS 10.10 and later.
• Windows 8 and later.
TB3 Technology
• Daisy Chain up to 6 devices.
• Bi-directional, dual-protocol (PCI Express and DisplayPort).
• 8 lanes of DisplayPort 1.2 supports dual 4K displays or one 5K display.
• Power delivery 15W to bus-powered devices.
• Backwards compatible with Thunderbolt™ 2 devices.
• USB-C ports are compatible with existing USB devices via USB-C cable, support up to USB 3.1 10Gb/s speed.
• Host Ports - 2x Thunderbolt™ 3 Ports.
• I/O Ports - 4x USB 3.1 Gen 2 Type-A Ports.
• Number of Channel / Port 10Gb/s Per USB 3.1 Gen 2 Port.
• Number of Devices 4x USB 3.1/3.0/2.0 devices or peripherals.
• Daisy Chain - Support Daisy Chain connections of up to six Thunderbolt™ devices.
• Note: the Daisy Chain will end if you connect a USB or Display device via USB-C.
