Gigabyte G482-Z50 2nd Gen EPYC Rome CPU 4U 22 Bay Barebone Server

Gigabyte G482-Z50 AMD EPYC™ 7002 Dual Processor Server System, 4U Rackmount, 12x 3.5" + 10x 2.5" SATA Hot-Swap Bays

Thumbnail 1 : Gigabyte G482-Z50 2nd Gen EPYC Rome CPU 4U 22 Bay Barebone Server Thumbnail 2 : Gigabyte G482-Z50 2nd Gen EPYC Rome CPU 4U 22 Bay Barebone Server Thumbnail 3 : Gigabyte G482-Z50 2nd Gen EPYC Rome CPU 4U 22 Bay Barebone Server Thumbnail 4 : Gigabyte G482-Z50 2nd Gen EPYC Rome CPU 4U 22 Bay Barebone Server
Scan code: LN104414 Manufacturer code: 6NG482Z50MR-00
£6,299.99Item currently awaiting an ETA
Pre order
With a 10% deposit from just £157.34 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Product Overview

Carefully Selected Components

GIGABYTE’s passive components are carefully selected to guarantee a stable operating environment and allow the processors and the memory to deliver their maximum performance. GIGABYTE’s server motherboards are built with long lasting components for a high degree of reliability and durability.


Design Features for Easy Maintenance

GIGABYTE’s AMD EPYC 7002 Series server platforms contain many tool less design features for easy installation, maintenance and removal – never worry about forgetting your toolbox or losing a screw again!


Efficient, Reliable Power Supply

GIGABYTE’s AMD EPYC 7002 Series server are designed to guarantee high conversion efficiency regardless of load. Redundant 80 Plus ‘Titanium’ or ‘Platinum’ PSUs, combined with GIGABYTE’s precision engineering, translates to super efficient power usage which maximizes the system’s power : performance ratio and reduces OPEX for the user.


Intelligent Power Management Features

To take advantage of the fact that a PSU will run at greater power efficiency with a higher loading, GIGABYTE has introduced a power management feature called Cold Redundancy for servers with dual PSU. When the total system loading falls lower than 40%, the system will automatically place one PSU into standby mode, enabling the other PSU to take over the greater load. This can enable total system power efficiency savings of up to 10%.


SCMP (Smart Crises Management / Protection)

SCMP is a GIGABYTE patented feature that will automatically force the system’s CPU to enter ULFM (ultra-low frequency mode for minimum power consumption) when the BMC is alerted to a PSU fault or error (such as power loss, power surge, overheating or a fan problem). This feature will prevent shutdown in systems with less than 1 + 1 PSU redundancy when one PSU is lost.


Dynamic Fan Speed Control

GIGABYTE servers are enabled with dynamic fan speed adjustment. Individual fan speed will be automatically adjusted according to the system’s current temperature (according to CPU, DIMM, M.2, HDD, GPU temperature sensors), to achieve the best cooling and power efficiency. When the BMC detects a temperature change, fan speed will be automatically adjusted accordingly. Fan speed profiles may also be manually created and edited* when necessary according to the user’s custom requirements.


Environmental Compliance

GIGABYTE maintains its commitment to green products, and adheres to the latest RoHS regulations (in effect July 2017).


VMware Technology Alliance Partner

Recognized as an Advanced Partner in VMware’s Technology Alliance Partner (TAP) program enables GIGABYTE to rapidly develop and certify joint solutions or go-to-market products that leverage VMware virtualization and cloud solutions, enabling our customers to modernize their data centers and implement IT infrastructure and application services with speed, agility, and cost optimization.


Features
• Up to 10 x PCIe GPGPU cards.
• Dual AMD EPYC™ 7002 series processor family.
• 8-Channel RDIMM/LRDIMM DDR4 per processor, 32 x DIMMs.
• 2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2).
• 2 x 1Gb/s BASE-T LAN ports (Intel® I350-AM2).
• 1 x dedicated management port.
• 8 x 2.5" NVMe, 2 x SATA/SAS 2.5" hot-swappable HDD/SSD bays.
• 12 x 3.5" SATA/SAS hot-swappable HDD/SSD bays.
• 1 x low profile PCIe Gen3 expansion slot.
• Aspeed® AST2500 remote management controller.
• 3 x 80 PLUS Platinum 2200W redundant PSU.
Specifications
Edition G482-Z50 (rev. 100)
Form Factor 4U Rackmount
CPU Included Yes
CPU Type AMD EPYC™ 7002 Series
CPU Model
Architecture
Manufacturing Process 7 nm
Unlocked CPU No
Core
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
Max. TDP
CPU Socket N/A
Chipset N/A
Motherboard Form Factor
Motherboard Model MZ52-G40
Memory Type DDR4
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels Octa (8)
Memory Type (ECC) N/A
Memory Type (R/U) RDIMM / LRDIMM
Memory Speed (Mhz)
  • DDR4 - 2933
  • DDR4 - 3200
Max. Memory Capacity 128GB
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip Aspeed AST2500 Integrated
Discrete GPU No
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration Yes
Max. GPU Resolution 1920x1080 (Full HD)
Graphics Interface PCIe 3.0 (x16)
Expansion Slots
  • 10 x PCIe 3.0 x16
  • 1 x PCIe 3.0 x16 (x8 Bandwidth), LP, HL
  • 1 x PCIe 3.0 x16, LP, HL
SATA SATA3
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
Optical Drive None
Drive Bays
  • 10 x 2.5" NVMe/SATA/SAS Hot-Swap
  • 12 x 3.5" SATA Hot-swap
Backplane I/O
  • 10 x 2.5" Port
  • 12 x 3.5" Port
RAID Support Yes
Internal I/O
  • 1 x Front Panel Audio Header
  • 1 x TPM Header
Network Interface Type Dedicated Management Ports
Network Chip/Modules
  • 2 x Intel® i350-AM2 Dual Port (GbE)
  • 2 x Intel® X550-AT2 (10GbE LAN)
  • 1 x Mgmt LAN
Front Panel
  • 1 x HDD Activity LED
  • 1 x ID button with LED
  • 1 x MLAN
  • 1 x NMI button
  • 1 x Power Button with LED
  • 1 x Reset Button
  • 2 x RJ45
  • 1 x System Status LED
  • 2 x USB 3.0
  • 1 x VGA
Back Panel
  • 1 x Management LAN
  • 2 x RJ-45
Cooling Fans
  • 4 x 40mm
  • 6 x 60mm
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 2200 W
PSU Efficiency Rating 80 PLUS Platinum
PSU Redundancy 2+1
Operating System Included No
Operating System N/A
Colour
Dimensions 448 x 176 x 880 (mm WxHxD)
Weight 29.5 kg
Includes
  • 2 x CPU Heatsink/s
  • 1 x Rail Kit
Notes
Storage Drives
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Additional Information
Scan Code LN104414
Model Number 6NG482Z50MR-00
GTIN 4719331191214
