Dynatron K199 1U Active Server Cooler LGA1156

Dynatron K199 Active Server CPU Cooler, LGA1156, 80mm PWN Fan, For 1u Server

MORE INFO
MORE INFO
Thumbnail 1 : Dynatron K199 1U Active Server Cooler LGA1156 Thumbnail 2 : Dynatron K199 1U Active Server Cooler LGA1156 Thumbnail 3 : Dynatron K199 1U Active Server Cooler LGA1156 Thumbnail 4 : Dynatron K199 1U Active Server Cooler LGA1156
Scan code: LN97135 Manufacturer code: K199
Order in the next 1 hr 11 mins and get it tomorrow
£39.98
Add To Basket
Get it Tomorrow, 17 MayIn stock
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 17th May to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview Dynatron K199 Active Server CPU Cooler Recommend for Intel® Core™ i5 I5-750; Xeon® Processor 3400 Series; Core™ i7 ProcessorsI7-870 & I7-860; Socket LGA1156. 80.0 x 15.0 mm Fan with PWM function, Copper Heatsink up to TDP 95 Watts for 1U server solution. Features • CPU Support: Intel
• CPU Socket: LGA 1156
• Weight: 355 g
• Material: Copper Heatsink with Skiving Fins
• Solution: 1U Server
• Dimensions: 85.0 x 81.5 x 28.5mm
• Fan Dimension: 80 x 15
• Rated Voltage: 12V
• Bearing: 2 Ball Bearing
• Speed:
- At Duty Cycle 20%: 1200 RPM
- At Duty Cycle 50%: 2600 RPM
- At Duty Cycle 100%: 5000 RPM
• Power:
- At Duty Cycle 20%: 0.60 W
- At Duty Cycle 50%: 1.44 W
- At Duty Cycle 100%: 9.60 W
• Air Flow :
- At Duty Cycle 20%: 3.533 CFM
- At Duty Cycle 50%: 7.645 CFM
- At Duty Cycle 100%: 14.719 CFM
• Noise Level:
- At Duty Cycle 20%: 20.71 dBA
- At Duty Cycle 50%: 37.5 dBA
- At Duty Cycle 100%: 51.7 dBA
• Static Pressure:
- At Duty Cycle 20%: 2.083 mm-H2O
- At Duty Cycle 50%: 9.780 mm-H2O
- At Duty Cycle 100%: 36.168 mm-H2O
• Lead Wire Pin Out :
- Pin1-Black (-)
- Pin2-Yellow (+)
- Pin3-Green (Techometer/Signal output)
- Pin4-Blue (PWM)
Specifications
Cooler Specifications
Edition K199
Cooler Form Factor Server
Heatpipes
Cooler Features Copper Base
Socket Compatibility 1156
Max. TDP
Fan Specifications
Included Fan Configuration 1 x 80mm
Fan Edition
PWM Fan Yes
Fan Bearing Type Dual Ball Bearing
Fan Colour Black
LED Lighting
Fan/Pump Connectors
Max. Fan Speed 5000 rpm
Max. Fan Airflow 17.719 CFM
Max. Air Pressure 36.168 mm H²O
Max. Sound Level 51.7 dBA
Materials
Cooler Materials Copper
Included TIM (Thermal Interface Material) Included (Pre-Applied)
Dimensions & Weight
Heatsink/Radiator Dimensions
Total Dimensions 85 x 28.5 x 81.5 mm (WxHxD)
Weight 355 g
Additional Information
Scan Code LN97135
Model Number K199
GTIN 0855700010022
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
Scan Computers International Limited
Telephone:
0871-472-4747

do I need a bracket

Do I need a bracket to mount this? Or it comes with a bracket? Or it is just a twist in screw type without the need for a bracket at the back of the motherboard?
