Dobot Magician E6 6-Axis Collaborative Robot Arm
Dobot Magician E6 6-Axis Collaborative Robot Arm
Scan code: LN162525 Manufacturer code: 1100000203
£4,119.98
Get it Tomorrow, 11 JulIn stock
  • Thumbnail 1 : Dobot Magician E6 6-Axis Collaborative Robot Arm
  • Thumbnail 2 : Dobot Magician E6 6-Axis Collaborative Robot Arm
  • Thumbnail 3 : Dobot Magician E6 6-Axis Collaborative Robot Arm
  • Thumbnail 4 : Dobot Magician E6 6-Axis Collaborative Robot Arm

Dobot Magician E6 6-Axis Collaborative Robot Arm

Dobot Magician E6 Robot Arm, 6-Axis, 750g Max Payload, 0.5m/s Max Speed

Scan code: LN162525 Manufacturer code: 1100000203
£4,119.98
Order in the next 27 mins and get it tomorrow (upgrade to Saturday delivery at checkout)
Get it Tomorrow, 11 JulIn stock

Email me when the availability or price changes

  • By DPD On 13th Jul Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free

Finance this product

  • From £116.17 / month (APR 16.9%) for 48 months or 0% for 4 months
  • With a 10% deposit from just £102.90 / month (APR 15.9%)

Magician E6 Desktop Cobot for Education and Research from DOBOT

E6 Collaborative Robot from DOBOT

Collaborative Robot The DOBOT Magician E6 is a 6-axis desktop cobot crafted for educational and research applications. It accurately replicates diverse automation situations, enabling hands-on learning and experimentation. With multiple interfaces for advanced development and dedicated robotics curriculum resources, the Magician E6 offers new opportunities in education. It serves as an excellent platform for exploring AI, intelligent manufacturing, and related disciplines.

Magician Cobot

Magician E6
Safety

High Level Of Safety Sleek body design with built-in collision detection ensures safer operation. A status indicator ring allows for easy monitoring of the Magician E6’s activity at a glance.

Simple Deployment

Simple Deployment Compact, lightweight, and flexible, the Magician E6 is easy to set up on any desktop. Its integrated control box minimises external wiring, providing a straightforward, plug-and-play setup.

Easy to Use

Easy to Use Exclusive trajectory replay technology enables intuitive drag-to-teach programming without code. With support for graphical programming, the Magician E6 is simple for anyone to learn and operate.

Specifications
DOF 6
Safeskin No
Weight 7.2 Kg
Max. Payload 0.75 Kg
Working Radius 450 mm
Maximum Working Speed 0.5 m/s
Range of Motion (J1) ±360 °
Range of Motion (J2) ±135 °
Range of Motion (J3) ±154 °
Range of Motion (J4) ±160 °
Range of Motion (J5) ±173 °
Range of Motion (J6) ±360 °
Max. Working Speed (J1) 120 °/s
Max. Working Speed (J2) 120 °/s
Max. Working Speed (J3) 120 °/s
Max. Working Speed (J4) 120 °/s
Max. Working Speed (J5) 120 °/s
Max. Working Speed (J6) 120 °/s
Force Sensor (Range)
Force Sensor (Overload)
Force Sensor (Accuracy)
Force Sensor (Precision)
End Effector IO (DI) 1 Channels
End Effector IO (DO) 1 Channels
End Effector IO (AO)
Repeatability ±0.1 mm
IP Rating IP20
Temperature Range 0~40 °C
Power Consumption 130 W
Installation Method Floor or Side mount
Cable Length (Robot-to-Control)
Material(s)
  • ABS Plastic
  • Aluminium Alloy
Additional Information
Scan Code LN162525
Model Number 1100000203
GTIN 1100000203
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
30 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
SCAN
Telephone:
01204-474747
Buying Guide
Need help? Read our Robotics Buying Guide
