Digitech Whammy Ricochet Pitch-Shift Pedal
Digitech - Whammy Ricochet Pitch-Shift Pedal, 7 Pitch Intervals Shift Across a 4 Octave Range
- SCANPROTECT Protect against installation damage for 28 days. More info
Pitch-Shift Pedal
DigiTech - Whammy Ricochet
Legendary whammy effects in a single stompbox pedalThe Whammy Ricochet gives you the ability to bounce your playing up or down in pitch in controlled or crazy shifts. A momentary switch and customizable independent rise and fall time ballistics, allow you to get the Whammy action you know and love without the use of a treadle. Just hold your foot on the footswitch and let the Ricochet go to work. Seven pitch selections – 2nd, 4th, 5th, 7th, Octave, Double Octave, and Octave+Dry, as well as a toggle to select up or down for the selected pitch.
The Whammy Ricochet also has latching footswitch mode so you can rise or fall to pitch and stay there, and an LED ladder that shows your shift trajectory at all times. All these controls together create classic Whammy pitch-shifting as well as new sounds never heard before.
At A Glance
• Bounce your playing up or down in pitch in controlled or crazy shifts
• 7 pitch intervals shift across a 4 octave range
• Visualize your pitch shifting rate and direction with LED lights
• Momentary on/off switch for quick-fire use
The Tech Spec
| Features | Specification |
|---|---|
| Controls | Ballistics Control, Pitch Control, Range Switch, Momentary Switch, Effect On/Off | Sample Rate | 44.1 kHz in classic mode, 22 kHz in chords mode |
| Frequency Response | 20 Hz–16 kHz (classic mode), 20 Hz–11 kHz (chords mode) |
| Signal To Noise Ratio | > -106dB (A weighted); ref = max level, 22 kHz bandwidth |
| THD | 0.004% @ 1 kHz; ref = 1 dBu w/ unity gain |
| A/D/A Conversion | 24 bit | Power Consumption | 2.1 Watts (235 mA typical @ 9 VDC) |
| Power Requirements | 9V DC External Adapter (sold separately) |
| Power Supply | PS0913DC-01 (US, JA, EU); PS0913DC-02 (AU, UK) |
| Power Adapter Output 9V DC 1.3A | 9V DC 1.3A |
| Dimensions | Width: 2.875" (76mm) Height: 1.75" (47mm) Depth: 4.75" (122mm) |
| Weight | 0.8 lbs. |
| Output | 1/4" Unbalanced (Tip-Sleeve) |
| Max Output Level | +10 dBu |
| Ouput Impedance | 1 kΩ (Effect enabled or effect bypassed w/ Momentary switch on) True Bypass (Effect bypassed w/ Momentary switch off) |
| Input | 1/4" Unbalanced (Tip-Sleeve)1/4" Unbalanced (Tip-Sleeve) |
| Max Input Level | +5 dBu |
| Input Impedance | 1 MΩ (Effect enabled or effect bypassed w/ Momentary switch on) True Bypass (Effect bypassed w/ Momentary switch off) |
