Broadcom NetXtreme 4x 1GbE PCIe Network Interface Card
Broadcom NetXtreme BCM5719-4P PCIe NIC, 4x 1GbE RJ45, Wake-on-LAN Support, 802.3az-2010/802.3ap
Email me when the availability or price changes
-
Pay in
3
interest-free payments of
£31.00
- Spend over £280.00 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
High-Performance & Feature-Rich
Designed for today's enterprise and data center environments, Broadcom's NetXtreme® 1G Ethernet Adapters are the ideal solution for multicore servers, delivering full line-rate throughput across all ports.
The BCM5719 PCIe NIC is a 13th-generation 10/100/1000BASE-T and 10/100/1000BASE-X Ethernet LAN controller solution for high-performance server and networking applications. The host interface supports a separate PCI Express function for each LAN interface. The BCM5719 includes I/O Virtualization (IOV) features such as 17 receive and 16 transmit queues, and 17 MSI-X vectors with flexible vector-to-queue association. These IOV features enable the BCM5719 to support VMWare® NetQueue and Microsoft® VMQ technologies.
The BCM5719 includes a comprehensive set of hardware features that the system may use to implement IEEE 1588 or IEEE 802.1AS-based time synchronization. These hardware features include a high-precision clock, timestamp registers for receive/transmit packets, and programmable trigger inputs and watchdog outputs.
• Energy Efficient Ethernet compliant with IEEE Std 802.3az-2010.
• IEEE 802.3ap Clause 73 auto-negotiation.
• Quad 10/100/1000BASE-T full-duplex/half-duplex MACs.
• Virtualization support with VMware NetQueue and Microsoft VMQ.
• Wake-on-LAN support.
• Energy Efficient Ethernet (EEE).
Applications:
• Cloud and Web2.0 data center servers.
• Enterprise data center servers.
• Private Cloud.
• Machine Learning (ML) clusters.
• High-Performance Computing (HPC) clusters.
• Multi-node container platforms.
• NVMe storage disaggregation (NVMe-oF™).
• Database servers.
