Avantone Active MixCube Powered Full-Range Mini Reference Monitor (Single Black)
Avantone Active MixCube Powered Full-Range Mini Reference Monitor (Single Black) - 90 Hz - 17 kHz, XLR And TRS Inputs
- SCANPROTECT Protect against installation damage for 28 days. More info
Single Powered Full-Range Mini Reference Monitor
Avantone - Active MixCube
(Black)
THE MOST REVERED SAFETY-NET MONITORS — NOW POWEREDAvantone Mixcubes are designed to be a perfect stereo matching pair of monitors to replicate the wide range of “bass-challenged” devices such as car stereos, TVs, clock radios, computers, Bluetooth devices, etc. So you'll be able to create the perfect mix for all speaker systems.
Avantone Mixcube Actives are a huge upgrade from the original 5C Sound Cubes; from a newly engineered cabinet, to a more smooth, open, and transparent driver — and now with an over-engineered power amplifier. The bass response has been extended just slightly too, but the original character remains the same. The Mixcube Actives are perfect for the most demanding workflow.
5.25"Driver Size
90Hz - 17kHzFrequency Response
60WPower
At A Glance
• 5.25" shielded active full-range monitor
• Secure MDF cabinet sides and baffle for low resonance
• Reduced edge diffraction with radiused corners and edges for better imaging
• Custom paper cone with New Zealand pulp with mica fibers
• 6.5" high-gloss lacquer finished Cube cabinet
Precision Driver
REDUCED ELECTRONIC PATHThe original 5C Sound Cubes are known for always doing the job, but we couldn’t just stop there. We designed a proprietary 5.25” die cast, polished aluminum frame driver/cone assembly to exceed the performance of the originals.
The paper cone is custom designed & crafted using the finest New Zealand pulp with mica fibers added for lighter weight & rigidity. The cloth surround is made in Japan to exacting and uniform thickness.
The Top Plate and T-Yoke of the driver are made of Sumitomo 1008 low-carbon steel, enabling the highest modeled flux density in the gap. The magnets are Y- 40 GRADE (MIL-SPEC) yielding a 43oz. high-power, low-distortion motor structure.
The Monitoring Solution You've Been Missing
the ultimate solutionThe amp module has been designed from the ground up to be a true professional-grade amplifier. It uses “overkill” concepts in component selection as well as safety. The result is a “no-compromise” amp with plenty of headroom characteristics that will rival the performance of much higher priced studio rack mount amps.
Avantone Mixcube Actives are built using a dense MDF board, due to it’s low-resonance characteristics. The input posts are high-end, nickel plated and are dual-banana spaced on an aluminum terminal plate. The bottom of the cabinet has a 7mm thick neoprene pad to serve as a skid-resistant acoustic isolator.
If you're out of desk space or need to set them up quickly, and on-location, you're covered! The Mixcubes base includes a recessed, industry-standard 5/8”-27 mic stand mount. Just grab a spare mic stand, and you’re good to go!
Add that mounting capability with the cabinet’s internal-shielding, and you can expect low-noise issues anywhere you set them up. The Mixcube Actives work as the perfect solution to round-out your monitoring setup.
The Tech Spec
| Features | Specifications | Powered | Yes |
|---|---|
| Power Configuration | Single Amp |
| Quantity | Single |
| LF Driver Size | 5.25" |
| LF Driver Type | Paper cone, shielded |
| Total Power | 60W Class AB |
| Frequency Range | 90Hz - 17kHz |
| Maximum Peak SPL | 104 dB SPL @ 1m |
| Input Types | 1 x XLR-1/4" combo |
| Enclosure Type | Sealed |
| Enclosure Material | 18mm medium-density fiberboard (MDF) |
| Dimensions | Width: 6.5" Height: 6.5" Depth: 6.5" |
| Weight | 7.13 lbs. |
