ASUS ESC4000A-E12-SKU1 AMD EPYC Zen 4 2U PCIe Gen5 Barebone GPU Server
ASUS ESC4000A-E12-SKU1 AMD EPYC Zen 4 2U PCIe Gen5 Barebone GPU Server
Scan code: LN134108 Manufacturer code: 90SF02M1-M000W0
£4,319.99Item currently awaiting an ETA
Pre order
  • Thumbnail 1 : ASUS ESC4000A-E12-SKU1 AMD EPYC Zen 4 2U PCIe Gen5 Barebone GPU Server
  • Thumbnail 2 : ASUS ESC4000A-E12-SKU1 AMD EPYC Zen 4 2U PCIe Gen5 Barebone GPU Server
  • Thumbnail 3 : ASUS ESC4000A-E12-SKU1 AMD EPYC Zen 4 2U PCIe Gen5 Barebone GPU Server
  • Thumbnail 4 : ASUS ESC4000A-E12-SKU1 AMD EPYC Zen 4 2U PCIe Gen5 Barebone GPU Server

ASUS ESC4000A-E12-SKU1 AMD EPYC Zen 4 2U PCIe Gen5 Barebone GPU Server

ASUS ESC4000A-E12 AMD EPYC Zen 4 Barebones Server, 2U, 4x PCIe Gen5 x16, 6x Hot-Swap Bays, 2x 1Gb/s RJ45

Scan code: LN134108 Manufacturer code: 90SF02M1-M000W0
£4,319.99
Item currently awaiting an ETA
Pre order

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • From £121.81 / month (APR 16.9%) or 0% for 4 months
    Monthly Payment: £360.00
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £4,319.99
    Total inc. interest: £4,319.99
    Monthly Payment: £180.00
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £4,319.99
    Total inc. interest: £4,319.99
    Monthly Payment: £151.28
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £4,319.99
    Total inc. interest: £5,445.84
    Monthly Payment: £121.81
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £4,319.99
    Total inc. interest: £5,846.51
    Example
    Minimum Spend: £99
    Instalment Rate: N/A
    Cost of purchase: £99
    Total inc. interest: £99
    If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

    Representative Example:

    Purchase Rate: 23.9% p.a. (variable)

    Representative: 23.9% APR (variable)

    Assumed Credit Limit: £1,200

    Subject to status. Terms and Conditions apply.
  • With a 10% deposit from just £114.80 / month (APR 19.9%)
  • paypal short logo blue 0% UP TO   MONTHS Spend £99 or more and choose PayPal at checkout. More info
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview

ESC4000A-E12

AMD EPYC™ 9004 single-processor 2U GPU server that supports four dual-slot GPUs, liquid cooling solution, up to 12 DIMM, 8 PCIe 5.0 slots, six NVMe, OCP 3.0 and ASMB11-iKVM.


Four Dual-Slot GPU Compute in 2U

ESC4000A-E12 is an AMD EPYC™ 9004 single-socket server built for the demands of enterprise AI infrastructure to deliver unprecedented performance with industry-leading GPUs, faster GPU interconnect and higher-bandwidth fabric, and supports up to four dual-slot active or passive GPUs scalable configuration with a choice of NVIDIA NVLink® Bridge or AMD Infinity Fabric™ Link to enable scaling of performance with increased bandwidth — ready to match your AI and HPC workloads.


Faster Storage, Graphics and Networking Capabilities

PCI Express® (PCIe®) 5.0 delivers 32 GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better lane scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready, with scalable designs to satisfy the increasing workloads or modern data centres.


Keep Your Data Centre Green

Data centres can consume huge amounts of electricity, raising environmental concerns. ASUS servers are designed to optimize both total cost of ownership (TCO) and total cost to the environment (TCE), including thermal design, power efficiency and advanced cooling solutions — reducing the impact of our products on the planet.


Comprehensive IT Infrastructure Solutions

Advanced ASUS management tools comprise IT assets management, security and reliability to improve the performance, up-time and real-time monitoring of the servers remotely — highly increasing the efficiency of IT infrastructure.


Tool-Less Cover

ASUS servers feature three easy-access covers that can be opened without tools, enabling IT staff to perform maintenance on specific components without removing the server fully from the rack.


Front-Bezel Q-Code

ASUS servers have a visible Q-Code/port-80 LED display LED for simple monitoring of the entire boot process, from power on through loading of the operating system.


Hot-Swap Design

ASUS servers feature multiple hot-swap components, including fans, power supplies and storage for easy troubleshooting to keep 24/7 seamless operations.


AMD EPYC™ 9004 Series Processors

The 9004 Series EPYC CPUs amplifies the AMD history of x86 architecture innovations and record-breaking performance with next generation 5nm technology as well as introducing support for high performant DDR5 DIMMs and fast PCIe® Gen 5 I/O. EPYC 9004 CPUs support 12 memory channels with 2 DIMMs/channel capability, delivering the resources needed for memory hungry AI, ML, HPC, and large in-memory computations.

Features

• Powerful Performance: Powered by AMD EPYC 9004 processors with 96 Zen 4 cores, 12-channel, up to 4800 MHz DDR5 and support for a maximum TDP of up to 400 watts per socket.
• AI and HPC Workloads Ready: Up to four dual-slot active or passive GPUs, NVIDIA NVLink® bridge, and NVIDIA Bluefield DPU support to enable performance scaling.
• Power-Efficient System Design: Independent CPU and GPU airflow tunnels for thermal optimization and support for up to two 2600W Titanium redundant power supplies for uninterrupted operation.
• Comprehensive Cooling Solutions: Designed for both liquid cooling and enhanced air cooling based on CPU TDP for versatile workloads.
• Scale-up Storage and Expansion Design: A total of six bays in combination of Tri-Mode NVMe/SATA/SAS drives on the front panel and eight PCIe 5.0 slots for higher bandwidth and system upgrade.
• Flexible Networking Module Design: Optional OCP 3.0 module with PCIe 5.0 slot in rear panel for faster connectivity.
• Enhanced IT-Infrastructure Management: ASUS ASMB11-iKVM remote control with ASPEED AST2600, ASUS Control Centre IT management software and hardware-level Root-of-Trust solution.

Specifications
Edition 90SF02M1-M000W0
Form Factor 2U
CPU Included Yes
CPU Type AMD EPYC™ 9004 Series
CPU Model
Architecture Zen 4
Manufacturing Process 5 nm
Unlocked CPU No
Core
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
TDP
CPU Socket SP5
Chipset N/A
Motherboard Form Factor
Motherboard Model
Memory Type DDR5
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels
Memory Type (ECC)
Memory Type (R/U) RDIMM (Registered)
Memory Speed (Mhz)
  • DDR5 - 4400
  • DDR5 - 4800
Max. Memory Capacity
On-board/Integrated Graphics No
Processor/Motherboard Graphics Chip N/A
Discrete GPU Yes
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration Yes
Max. GPU Resolution
Graphics Interface PCIe 5.0 (x16)
Expansion Slots
  • 6 x PCIe 5.0 x16
  • 2 x PCIe 5.0 x8
SATA N/A
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Optical Drive None
Drive Bays
  • 2 x 2.5" NVMe/SATA/SAS Hot-Swap
  • 4 x 3.5" SAS/SATA Hot-swap
Backplane I/O
RAID Support
Internal I/O N/A
Network Interface Type Wired Gigabit LAN (10/100/1000)
Network Chip/Modules
Front Panel 4 x USB 3.2 Gen1 Type-A
Back Panel
  • 1 x D-Sub (VGA)
  • 1 x Management LAN
  • 2 x RJ-45
  • 2 x USB 3.2 Gen1 Type-A
Cooling Fans
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 2600 W
PSU Efficiency Rating 80 PLUS Titanium
PSU Redundancy 1+1
Operating System Included No
Operating System N/A
Colour Grey
Dimensions 439.5 x 88.9 x 800 (mm WxHxD)
Weight 24 kg
Includes 1 x Barebone Server
Notes
Additional Information
Scan Code LN134108
Model Number 90SF02M1-M000W0
GTIN 4711387030370
