Scan code: LN87163 Manufacturer code: 90SV025A-M45CE0

ASUS ESC4000 G3 Server for Intel Xeon E5-2600 CPU Family

ASUS ESC4000 G3 Server, Intel C612 PCH, S2011-3 x2, DDR4 RDIMM/LRDIMM/NVDIMM, 10x PCIe Slots,

Thumbnail 1 : ASUS ESC4000 G3 Server for Intel Xeon E5-2600 CPU Family Thumbnail 2 : ASUS ESC4000 G3 Server for Intel Xeon E5-2600 CPU Family Thumbnail 3 : ASUS ESC4000 G3 Server for Intel Xeon E5-2600 CPU Family Thumbnail 4 : ASUS ESC4000 G3 Server for Intel Xeon E5-2600 CPU Family
Scan code: LN87163 Manufacturer code: 90SV025A-M45CE0
Order now and receive it by Monday, 4th July
£1,620.00
Get it Saturday, 02 JulIn stock
From £37.86 / month (APR 5.9%) or 0% for 4 months
Monthly Payment: £139.24
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,620.00
Total inc. interest: £1,670.87
Monthly Payment: £71.62
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,620.00
Total inc. interest: £1,718.72
Monthly Payment: £49.10
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,620.00
Total inc. interest: £1,767.53
Monthly Payment: £37.86
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,620.00
Total inc. interest: £1,817.14
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 21.9% and may be even lower.

Representative Example:

Purchase Rate: 21.9% p.a. (variable)

Representative: 21.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £40.46 / month (APR 15.9%)
Delivery Options
  • By DPD On 4th Jul to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview

Green500 Champion Successor

ASUS has made it again in the HPC field. The latest ESC4000 G3, based on Intel® Xeon® processor E5-2600 v4/v3 product families, not only offers 4 double-deck GPU support but also features mass storage with eight hot-swappable 3.5” SATA HDD bays, 1+1 80 PLUS Platinum 1620W redundant power supplies and 8+2 PCI-E Gen3 x16 expansion slots. It delivers high density computing power, scalable expansion capability and high power efficiency, making it an ideal choice for the applications in the field of life and medical science, engineering science, financial modeling and virtualisation.


8+2 Flexible Expansion Slots

The ESC4000 G3 supports up to eight PCI-E Gen3 x16 slots in 2U for high density computing and high expandability, compatible with versatile expansion cards, especially in supporting up-to-date Intel® Xeon Phi™ series, NVIDIA Tesla and GRIDTM Family, as well as AMD FirePro S Series of GPU accelerators. Initially, high-density computing is designed specifically to pack greater processing power into a rack. In ESC4000 G3, it can carry up to 4 double-deck GPUs offering extreme high density and parallel computing power. In addition, there is also one PCI-E Gen3 x 24 slot which could perform as two slots if riser is applied for Low Profile HBA & proprietary networking cards in FDR and 10G interface.


Improved Airflow and Lower Running Costs

With intelligent system fan III, independent smart fans provide cooling for each area of the GPU and CPU separately, and a redundant fan design for GPU area provides an extra thermal back-up solution. Intelligent system fan III offers dedicated airflow toward CPUs and GPUs as well as offering flexibility in fan allocation. Additionally, adjustable CPU fan duty in BIOS setting enables the user to configure a preferable system fan settings accommodating to different scenarios.


1+1 Platinum Redundant PSUs

The ESC4000 G3 is equipped with a 2000W/1620W 80 PLUS Platinum level redundant power supply with VR power efficiency up to 95% for energy savings, while the hot swappable design reduces power loss, improves power efficiency and saves more TCO for users.


Design for the User

ESC4000 G3 has a visible Q-Code/port 80 LED display LED for simple monitoring of the entire boot process, from the early hardware-awakening stages to the launch of the operating system and beyond. With the features of quick initialisation guidance of BIOS, users can realise system initialisation state in seconds; furthermore users are able to diagnose system instantly through POST code message in the POST stage. Also, the exclusive tool-less rail kit design helps the user to deploy the servers in an easy and simple way.


Comprehensive RAID Solutions

The ESC4000 G3 supports the optional ASUS PIKE II upgrade kit. Just placing the PIKE II card, such as PIKE II 3x08 series, the latest 12Gb/s SAS and PCI-E 3.0 high reliability enterprise storage solution, ESC4000 G3 can immediately expand bandwidth and offer complete RAID functions, upgrade to 12G solution and improve the performance, making it the great upgrade option.


Complete Remote Server Management

The ASMB8-iKVM (IPMI 2.0-compliant) enables remote update BIOS, standalone KVM/Java utility, video recording and BSOD capture. Based on out-of-band management, even if the server operating system is down or offline, the KVM module can still provide round-the-clock remote monitoring and diagnosis through a user-friendly web-based graphical interface via all major browsers. In addition, ASWM Enterprise software provides one-to-multiple centralised management including BIOS flash, software dispatch, task scheduler, remote control, and power control, all through a colourful and informative graphical interface. Through ASUS remote management solution, user could save time and effort on server management and trouble-shooting.

Features

• 2 x Socket R3 (LGA 2011-3).
• Intel® Xeon® processor E5-2600 v4 product family (145W).
• Intel® Xeon® processor E5-2600 v3 product family(145W).
• Intel® C612 PCH.
• DDR4 RDIMM/LRDIMM/NVDIMM.
• Total Slots : 16 (4-channel per CPU, 8 DIMM per CPU).
• Capacity : Maximum up to 1024GB LRDIMM.
• Expansion slots: 8 + 2 PCI 3.0.
• 8 x SATA3 6Gb/s ports.
• 8 x Hot-swap 3.5" HDD Bays.
• 2 x USB 3.0 ports.

Accessories:
• 1 x MB Support DVD.
• 1 X ASWM Enterprise DVD.
• 1 x ASMB8 SDVD.
• 1 x Bag of Screws.
• 1 x AC Power Cable.
• 8 x GPU air ducts.

Specifications
Edition ESC4000 G3
Form Factor 2U Rackmount
CPU Included No
CPU Type 2x Intel Xeon
CPU Model Intel® Xeon® processor E5-2600 v4/v5
Architecture
Manufacturing Process
Unlocked CPU No
Core
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
Max. TDP
CPU Socket N/A
Chipset N/A
Motherboard Form Factor
Motherboard Model
Memory Type DDR4
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels Quad (4) per CPU/Socket
Memory Type (ECC)
Memory Type (R/U) RDIMM / LRDIMM / NVDIMM
Memory Speed (Mhz)
  • DDR4 - 1333
  • DDR4 - 1600
  • DDR4 - 1866
  • DDR4 - 2133
  • DDR4 - 2400
Max. Memory Capacity 1024GB
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip Aspeed AST2400 with 32MB VRAM
Discrete GPU No
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration No
Max. GPU Resolution
Graphics Interface PCIe 3.0 (x16)
Expansion Slots
  • 4 x PCIe 3.0 x16 (x8 + x8 Link)
  • 1 x PCIe 3.0 x24 (support with riser card)
SATA SATA3
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Optical Drive DVD±RW
Drive Bays 8 x 3.5" Hot-swap
Backplane I/O
RAID Support
Internal I/O N/A
Network Interface Type Wired Gigabit LAN (10/100/1000)
Network Chip/Modules
  • 2 x Intel® I210AT (Gigabit LAN)
  • 1 x Mgmt LAN
Front Panel 2 x USB 2.0
Back Panel
  • 3 x RJ-45
  • 2 x USB 3.0
  • 1 x VGA
Cooling Fans
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 1620 W
PSU Efficiency Rating 80 PLUS Bronze
PSU Redundancy 1+1
Operating System Included No
Operating System N/A
Colour
Dimensions 750 x 444 x 87 (mm WxHxD)
Weight
Includes
Notes
Additional Information
Scan Code LN87163
Model Number 90SV025A-M45CE0
GTIN 4712900847178
