ART - SCL2CE - Stereo Compressor
ART - SCL2CE, Dual / Stereo Compressor / Limiter Expander / Gate, Dual Channel or Linked Stereo Operation
Dual / Stereo Compressor / Limiter Expander / Gate
ART - SCL2
for studio recording and live sound
reinforcement applicationsART’s SCL2 is a brilliantly sophisticated and versatile dynamics processing unit designed for quick and simple operation and fantastic tone. The SCL2 us able to be tweaked to deliver anything from smooth subtle compression to hard limiting. Noise reduction is provided by a fast solid gate or a subtle expander.
The onboard Attack and Release functions enable the user to determine the general operating range and then auto adapt to the audio being processed, there’s also a full auto mode available too. The incredibly precise LED meters while the two LED meters show clearly the gain reduction for each channel.
at a glance
• Large diaphragm cartridge provides wider dynamic range for clear highs and strong lows
• 1/4-Inch TRS And XLR Balanced Inputs
• Selectable Auto/ Manual Attack/Release
• Precise Led Level Meters
• All Steel Chassis
The Tech Spec
Features | Specification | Input/Output Connections | ¼-inch TRS balanced |
---|---|
Side Chain Connections | ¼-inch TRS (Tip = Send, Ring = Receive) |
Input Impedance | 10k Ω |
Output Impedance | 200 Ω (bal), 100 Ω (unbal) |
Maximum Input Level | +20 dBu Balanced |
Maximum Output Level | +20 dBu Balanced |
Frequency Response | 10Hz to 40kHz, +/- .5dB |
Dynamic Range | 120 dB |
Attack Time | .25mSec to 100mSec Adjustable |
Release Time | 100mSec to 3 Sec Adjustable |
Total Harmonic Distortion | <0.06% (typical) |
Power Requirements | 120 V 60 Hz/50H, 10W max. |
Dimensions | 1.75″ H x 19.0″ W x 6″ D (4.5 x 48 x 15.2 cm) |
Weight | 4.2 lbs (1.9 kg) |
