Antelope Audio 10MX Rubidium Atomic Clock

Antelope Audio 10MX Professional Grade Rubidium Atomic Clock, 10x 10 MHz Atomic Reference, 4x Wordclock Out, 2x SPDIF

ANTELOPE
Scan code: LN71589 Manufacturer code: 10MX Request call
£6,179.00Item currently awaiting an ETA
Pre order
Pay on Scan Finance with a 10% deposit from just £154.32 / month (APR 15.9%)
High End
Free Delivery Delivery options Free By DPD DPD Delivered to your specified address. Receive SMS with one-hour delivery window. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout
Product Overview 2017 NAMM Show TEC Awards Nomination in the "Ancillary Equipment" category!

10MX is the newest and the premier member of the Isochrone family. It features technologies from two of Antelope's legendary products. The atomic precision of the 10M and the sophisticated jitter-management algorithm of Trinity are combined in a futuristic, 1U rack space enclosure, providing the world's most stable and musical clocking.

10MX is a fusion of proven technologies and contemporary industrial design, where no compromises are allowed and both build-quality, and performance-excellence are top priority. The new Rubidium Atomic Clock is an epiphany of more than 20 years’ expertise in the digital audio world, making vividly real the clarity, depth, width and 3-dimensionality distinctive of the analog sound.

10MX is perfectly suited for recording, mixing and mastering environments. Its form factor, occupying only 1U of rack space, makes it ideal for live sound application where rack slots are precious commodity.

The multiple atomic outputs allow up to 10 devices to be clocked simultaneously over BNC outputs of 10MHz. The unit can also be used as a master clock with 4 outputs, supporting the outstanding sampling rate of up to 768 kHz via BNC. Two more clocking outputs are available via AES and two via S/PDIF.

The new Rubidium Atomic Clock is equally easy manageable either from the front panel or the intuitive software control panel available for OS X and Windows, connecting via a USB port. Features • Rubidium core with accuracy of 0.05 ppb (parts per BILLION).
• 4th generation Acoustically Focused Clocking (AFCTM ), employing 64-bit DSP.
• Master clocking up to 768 kHz over 4 WC.
• 2 x S/PDIF and 2 x AES/EBU master clocking outputs up to 192 kHz.
• Atomic clocking compatible with any device that accepts 10MHz reference.
• Utmost ease of operation, just connect it and power it on.
• PC/Mac connection via USB, allowing remote control and firmware upgrades.
• Intuitive Software Control Panel.
• Extremely sturdy mechanical construction.

• Atomic Reference Type Rubidium Ultra-Stable Resonance-Controlled Master Oscillator
• Frequency 10MHz
• Frequency Accuracy Better than ±5E-11 @25C (±0.05 PPB)
• Aging
- Daily* ±2.5E-11
- Monthly* ±1E-10
- Yearly ±1E-9
(*After 1 day & 1 month of operation respectively)
• Short Term Stability
- t=1s =3E-11
- t=10s =1.6E-11
- t=100s =8E-12
• Time drift in a 24-hr period <7µs over 0°C to +60°C
• Phase Noise (SSB)
- 1Hz =-70 dBc/Hz
- 10Hz =-87 dBc/Hz
- 100Hz =-114 dBc/Hz
- 1kHz =-130 dBc/Hz
- 10kHz =-140 dBc/Hz
• Warm-Up Time 8 – 10 minutes (depends on ambient temperature)
• Maximum shock withstanding
- Non-operating, flight case mounted: 100m/s2 (~10.2 g*), 11 msec half-sine pulse per IEC 60068-2-27:2008
- Non-operating, in original packing: 300m/s2 (~30.6 g*), 5 msec half-sine pulse per IEC 60068-2-27:2008
* g – gravitational acceleration
• Power Supply Type AC
• Power Supply Input 100 – 240 V~
• Power Consumption 15 W
• Atomic Clock Outputs 10 x BNC Sinusoidal, 10MHZ, 75 Ohm, 1Vpp typical (unload)
• Outputs
- Word Clock: 4 x BNC
- AES/EBU: 2 x XLR
- S/PDIF: 2 x RCA
• USB USB 2.0 Hi-Speed, Type B, only for control

Word Clock Specs
• TTL Level, 75 Ohm Output Impedance
• Operating Temperature 0 – 50°C, 32-122 F
• Humidity 30 – 80% RH non-condensing
• Dimensions
- 482.6 (W) ?228 (D) ? 44 (H) mm
- 19 (W) x 9 (D) x 1.73 (H) inch
• Weight 2.8 kg/6.17 lb

In The Box
• 10MX Rubidium Atomic Clock.
• Owner’s Manual.
• Warranty Card.
• 1 USB Cable.
• 1 AC Power Cable.
Specifications
Specifications
Computer Interface Type USB 2
Analogue Inputs (Total)
Analogue Outputs (Total)
Connections (Input) 1 x BNC Word Clock In
Mic Preamps (Max)
Instrument Inputs (Max)
Phantom Power No
Sample Rate (Max)
Bit Resolution
iPad Compatible No
Dynamic Range n/a dB
Connections (Output)
  • 10 x 10MHz Atomic Reference
  • 2 x AES
  • 4 x BNC Word Clock Out
  • 2 x S/PDIF Coaxial Out
Dimensions (mm)
DSP Processing No
Misc. Notes
