Scan code: LN136466 Manufacturer code: MS108GP

Mercusys MS108GP 8-Port Desktop PoE+ Network Switch

8 Port Mercusys MS108GP, Gigabit Ethernet Desktop Switch, 7 Ports PoE+ (65W Budget), 802.3x, IEEE 802.3af/at Compliant

Thumbnail 1 : Mercusys MS108GP 8-Port Desktop PoE+ Network Switch Thumbnail 2 : Mercusys MS108GP 8-Port Desktop PoE+ Network Switch Thumbnail 3 : Mercusys MS108GP 8-Port Desktop PoE+ Network Switch
Scan code: LN136466 Manufacturer code: MS108GP
£37.99Item currently awaiting an ETA
Pre order
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

7 PoE+ Ports (65 W Budget) for Network Deployment

All eight ports of the MS108GP are gigabit ports, with seven PoE+ ports (1-7). Each PoE+ port supports a maximum of 30 W and is compliant with the 802.3af/at Powered Devices. The total 65 W PoE power budget enables a variety of uses, including surveillance for offices, dormitories, and small businesses. IP cameras, access points, IP phones, PCs, video recorders, and more are all completely compatible with it.


No Fuss

No need for electricians; simplify installation and deployment.


Cost-Efficiency

Getting rid of extra cables and power adapters will save money on infrastructure.


Flexibility

Deployment in complex situations is made possible by more placement possibilities.


Power Management

Improves power usage while intelligently protecting your gadgets from power surges.


IEEE 802.3af/at

PoE ports compliant with the 802.3af/at Powered Devices.


Long-Range up to 250 m with Extend Mode

Extend Mode increases PoE transmission distance to 250 m. MS108GP has 7 long-range ports with PoE+. Turn on the Extend Mode and make it ideal for installing surveillance cameras over wide areas.


Traffic Separation

With only one click, isolation mode divides traffic for ports 1-7 to prevent snooping/tampering and isolate broadcast storms for greater protection.


Port Prioritization

Prioritizing the data of specific ports would ensure the high quality of delicate applications, such as voice and video, in crucial business domains.


Plug and Play

MS108GP offers auto-negotiation (10/100/1000 M) and automated MDI/MDIX. There is no additional configuration needed. It is simple to use and saves time and effort.


Durable and Silent

MS108GP's durable metal case allows for efficient heat dissipation, excellent signal interference prevention, equipment stability, and long network life.


Features


Full Gigabit Ports: 8× 10/100/1000 Mbps RJ45 ports.
Two Cables in One: With 7 PoE+ ports, transfers data and power on one single cable.
High Power PoE+: Support PoE Power up to 30 W for each PoE port and 65 W for all PoE ports.
Long-Range up to 250 m: Increases PoE transmission distance to 250 m by Extend Mode.
Isolation Mode: One click to divide traffic for specific ports for stability and security.
Compliant with Powered Devices: Works with IEEE 802.3af/at compliant PDs.
Durable Metal Casing: Allows for efficient heat dissipation and long network life.
Plug and Play: Simple to use and saves time and effort.

Specifications
Edition Smart Switch
Form Factor Desktop
Total Network Ports 8 x 10/100/1000 (Gigabit) RJ-45
PoE Support Type PoE+
No. of Ports Providing PoE 7 x 10/100/1000 (Gigabit) RJ-45
Other Non-Network Ports
Switching Capacity 20/200/2000 Mbps at Full Duplex
Non-Blocking Throughput
Forwarding Rate
MAC Address Table Size 8K Entries
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3x
Acoustic Noise
Max. Power Consumption 77.33 W
Max. PoE Wattage per Port 30 W
Mean Time Between Failures (MTBF)
Power Supply External Power Supply (Included)
Material
Includes
Dimensions (WxHxD) 171 x 27 x 98 mm
Weight
Additional Information
Scan Code LN136466
Model Number MS108GP
GTIN 6957939001216
