Scan code: LN89236 Manufacturer code: RS6628A

HighPoint 8 Bay Tower RAID Storage T3 to SAS/SATA HDD/SSD

8-Bay HighPoint RocketStor 6628A External Enclosure, RAID 0/1/5/6/10/50/JBOD, 2.5/3.5” SAS/SATA, Thunderbolt3

Thumbnail 1 : HighPoint 8 Bay Tower RAID Storage T3 to SAS/SATA HDD/SSD Thumbnail 2 : HighPoint 8 Bay Tower RAID Storage T3 to SAS/SATA HDD/SSD Thumbnail 3 : HighPoint 8 Bay Tower RAID Storage T3 to SAS/SATA HDD/SSD
Scan code: LN89236 Manufacturer code: RS6628A
With a 10% deposit from just £32.97 / month (APR 15.9%)
Delivery Options
  • By DPD On 19th Nov 2019 to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Product Overview Streamlined RAID Management for Professionals
Each RocketStor 6628A RAID Enclosure includes our newly redesigned, easy to use web-based management utility. The built-in Array Configuration Wizard allows users of any experience level to create any type of RAID array in three easy steps; simply select your RAID level, pick your drives and go! Creating arrays has never been easier!

Optional Advanced Management Features allow customers to fine tune RAID arrays for specific projects, with options to specify block size, enable DV Mode for digital media projects, designate spare disks for recovery, and schedule routine automated maintenance sessions with Email notification to keep one abreast of changing storage conditions while outside of the work environment.

Fast, Consistent, & Smooth Data Transfer for large block size Applications
The RocketStor 6628A 2nd Generation Series Thunderbolt™ 3 RAID enclosures feature the latest iteration of HighPoint’s industry proven Hardware RAID stack, which features substantial refinements to both transfer performance and stability for professional storage applications. RocketStor 6628A benefits from streamlined performance and highly stable transfers for large block size applications such as video production and editing, media streaming and content creation.

Enhanced Storage Cooling Solution
The ability to manage the high-levels of heat generated by pronged, sustained I/O sessions on today’s high-capacity hard disks is a prime concern when choosing the right RAID enclosure solution. RocketStor 6628 Series RAID enclosures seamlessly integrate LED’s, audible alarms, and superior cooling apparatus to ensure your storage investments and the critical data they host stay cool, healthy and productive. Proactive monitoring systems intelligently adjust fan speed on the fly to eject waste heat from the chassis and prolong the life of today’s high-capacity SAS and SATA hard drives.

High-Speed, Big Data or All-In-One: Your Choice!
RocketStor 6628 Series RAID enclosures are significantly more versatile that conventional external storage solutions, which rely on pre-packaged storage comprised solely of drives of the same speed and capacity. Customers are free mix and match disks of different capacities and speed levels to meet the needs of any application; SSD's for Maximum Performance, HDD's for Mass Storage, or a combination of both for tasks that call for high-speed workspace and archiving capability.

Equipped with the latest Thunderbolt™ 3 USB-C technology, the RocketStor 6628A can deliver 40Gbps transfer rates. Projects utilizing 4K DPX 16 bit footage require approximately 1,790MB/s of transfer performance; the RocketStor 6628A is capable of supporting full 4K uncompressed video production, In addition, if the source is ProRes 444, the RocketStor 6628A can support over 5 individual streams!

Safeguard Your Storage Investments
The RocketStor 6628A seamlessly integrates LED features, an audible alarm, and intelligent cooling apparatus to ensure your storage investments stay healthy and accessible.

Uncompromised RAID Architecture
• Storage Availability and Accessibility: Hardware RAID 5 and 6 protection shields storage configurations from 1 or 2 disk failures, respectively. The RocketStor Storage Health Inspector (SHI) proactively maintains the health of arrays to keep storage ready & able.
• HighPoint DV Mode for Streaming Performance: DV Mode Technology intelligently manages the flow of large data blocks and write-back caching to minimize latency and ensure consistent, sustained high-performance transfers for media-rich applications.
• Robust RAID Protection: The built-in NVRAM constantly tracks in-progress writes to preserve the integrity of data in the event of a drive failure or system crash, and streamline recovery procedures while minimizing downtime.
• Open-Box Storage Solution: Features an “open-box” approach to storage, which grants customers the freedom to use their choice of SAS or SATA drive from all major drive brands. Customers can add drives as needed to meet the evolving performance or capacity requirements of the storage application.
• Storage Expansion Ready: Daisy-Chain capability allows customers to link as many as 6 independent RocketStor 6628A units using a single Thunderbolt™ 3 host port. The Online Capacity Expansion and RAID Migration allow customers to modify RAID configurations or expand existing storage while avoiding complicated, time consuming backup and restoration procedures. Features • 2x Thunderbolt™ USB-C Ports featuring 40Gb/s Speed bandwidth.
• Performance up to 2,700MB/s.
• Integrated SAS/SATA Hardware RAID Technology.
• Storage Capacity up to 8x 10TB or Larger Spindle HDD.
• High-Speed Storage up to 8x SSD.
• Blazing Fast, Consistent, & Smooth Data Transfer for large block size Applications.
• Enhanced Storage Cooling Solution.
• Refined 2nd Generation Chassis Design eases Maintenance.
NAS Form Factor Desktop
Bays 8 Bay
Total Storage Included N/A
Type of Drives Included
Edition of Drives Included
Capacity of Drives Included
Max. Storage Capacity Unlimited TB
Drive Interface Support 8 x SAS/SATA III - 6Gb/s
Drive Form Factor Support 8 x 2.5"/3.5"
Internal Flash Memory No
Internal Flash Memory Capacity
DOM Module No
DOM Capacity
CPU Type
CPU Model
CPU Cores
CPU Speed
RAM Memory Included
RAM Memory Type
Max. RAM Memory Supported
Cache Drive Interface
Included Cache Drive Capacity
Included Cache Drive Type
LAN Type N/A
Expansion Slots
External Connectivity 2 x Thunderbolt 3
Cooling Fan
Noise Level
PSU Type
PSU Wattage 250 W
Max. Power Consumption
Physical Security
Dimensions 144.02 x 330.2 x 257.05 (WxHxD mm)
Weight 5.851 kg
Additional Information
Scan Code LN89236
Model Number RS6628A
GTIN 643653662814
