HighPoint RocketStor 6542AW 8-bay U.2/U.3 NVMe RAID Enclosure
HighPoint RocketStor 6542AW 8-bay U.2/U.3 NVMe RAID Enclosure
Scan code: LN151233 Manufacturer code: RS6542AW
£1,999.99Item due on 19 December 2024
Pre Order
Due 19th Dec
  • Thumbnail 1 : HighPoint RocketStor 6542AW 8-bay U.2/U.3 NVMe RAID Enclosure
  • Thumbnail 2 : HighPoint RocketStor 6542AW 8-bay U.2/U.3 NVMe RAID Enclosure
  • Thumbnail 3 : HighPoint RocketStor 6542AW 8-bay U.2/U.3 NVMe RAID Enclosure
  • Thumbnail 4 : HighPoint RocketStor 6542AW 8-bay U.2/U.3 NVMe RAID Enclosure

HighPoint RocketStor 6542AW 8-bay U.2/U.3 NVMe RAID Enclosure

8 Bay HighPoint RocketStor 6542AW U.2/U.3 RAID Enclosure, 8x Hot Swappable 2.5” U.2/U.3 Bays, PCIe Gen4 x16 Controller
MORE INFO
MORE INFO

Scan code: LN151233 Manufacturer code: RS6542AW
£1,999.99
Item due on 19 December 2024
Pre Order
Due 19th Dec
  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • From £41.67 / month (APR 0%) or 0% for 4 months
    Monthly Payment: £166.67
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £1,999.99
    Total inc. interest: £1,999.99
    Monthly Payment: £83.34
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £1,999.99
    Total inc. interest: £1,999.99
    Monthly Payment: £55.56
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £1,999.99
    Total inc. interest: £1,999.99
    Monthly Payment: £41.67
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £1,999.99
    Total inc. interest: £1,999.99
    Example
    Minimum Spend: £99
    Instalment Rate: N/A
    Cost of purchase: £99
    Total inc. interest: £99
    If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

    Representative Example:

    Purchase Rate: 23.9% p.a. (variable)

    Representative: 23.9% APR (variable)

    Assumed Credit Limit: £1,200

    Subject to status. Terms and Conditions apply.
  • With a 10% deposit from just £53.15 / month (APR 19.9%)
Product Overview

RocketStor 6542AW 8-Bay PCIe 4.0 x16 NVMe RAID Enclosure

The Rocket 6542AW NVMe RAID Enclosure delivers unparalleled performance and flexibility for PCIe Gen4 server and workstation platforms. The robust, external form factor is ideal for compact industrial and Edge computing platforms, which often lack the internal space needed to support large arrays of 2.5" storage media.

8 Hot-Swappable, vertically aligned 2.5" drive bays, and powered by our industry proven PCI Switching Architecture and RAID technology, Rocket Stor 6542AW enclosure can deliver up to 28GB/s of transfer bandwidth and support nearly 1/2 petabytes of DC and Enterprise class U.2 and U.3 media configured into as many as four independent RAID 0, 1 or 10 arrays.

RocketStor 651x series solutions have been engineered to deliver uncompromised, host-to-device PCI x16 connectivity. Both the enclosure (device-side) and discreet adapter card (host-side) employ 48-lane PCIe Switch ICs to maximize the performance potential of hosted NVMe media.

The unique hardware architecture enables each solution to provide x16 lanes of dedicated upstream bandwidth (connection to the host computer) and x4 lanes of dedicated downstream bandwidth to each U.2 or U.3 SSD. In addition to maximizing transfer performance, the integrated PCIe switch technology minimizes latency and significantly enhances signal integrity to streamline I/O transmission between the host computer and NVMe storage.

Features


• Compact, Rugged & Portable External NVMe RAID Storage Solutions.
• Up to 8 independent 2.5" NVMe drives bays and nearly 1/2 Petabytes of storage capacity.
• Host & Device side Switch ICs deliver x16 lanes of dedicated upstream and x4 lanes of downstream bandwidth for each drive bay.
• Sustained transfer speeds up to 28,000MB/s.
• Precision Engineered Dual-Width Cooling Solution Enhances reliability & Prevents Thermal Throttling.
• Comprehensive Management & Monitoring Suite.
• Supports up to four RAID 0, 1 or 10 arrays.
• Boot-RAID Capability for Linux & Windows.


Specifications
Edition 6542AW
NAS Form Factor Desktop
Bays 8 Bay
Total Storage Included N/A
Type of Drives Included
Edition of Drives Included
Capacity of Drives Included
Max. Storage Capacity
Drive Interface Support
Drive Form Factor Support 8 x U.3
Internal Flash Memory No
Internal Flash Memory Capacity
DOM Module No
DOM Capacity
CPU Type
CPU Model
CPU Cores
CPU Speed
RAM Memory Included
RAM Memory Type
Max. RAM Memory Supported
Cache Drive Interface
Included Cache Drive Capacity
Included Cache Drive Type
LAN Type 10/100
Expansion Slots
External Connectivity
Cooling Fan
Noise Level
PSU Type Internal
PSU Wattage
Max. Power Consumption
Physical Security Kensington Lock Slot
Dimensions
Weight
Additional Information
Scan Code LN151233
Model Number RS6542AW
GTIN 643653654215
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
Scan
Telephone:
0871 472 4747
