ASUS 1U Rackmount 4-Bay RS300 E11 PS4/450W(1+1) Xeon E Barebone Server

4-Bay ASUS RS300-E11-PS4/450W, Xeon E 2300 1U Rack Server, Intel C252, s1200, 4x DDR4, 4 x 3.5” Hot-Swap, M.2, 2x GbE

Thumbnail 1 : ASUS 1U Rackmount 4-Bay RS300 E11 PS4/450W(1+1) Xeon E Barebone Server Thumbnail 2 : ASUS 1U Rackmount 4-Bay RS300 E11 PS4/450W(1+1) Xeon E Barebone Server Thumbnail 3 : ASUS 1U Rackmount 4-Bay RS300 E11 PS4/450W(1+1) Xeon E Barebone Server Thumbnail 4 : ASUS 1U Rackmount 4-Bay RS300 E11 PS4/450W(1+1) Xeon E Barebone Server
Scan code: LN123242 Manufacturer code: 90SF01Y1-M000E0
Order now and get it tomorrow (upgrade to Sunday delivery at checkout)
£1,109.48
Get it Tomorrow, 22 MayIn stock
From £25.93 / month (APR 5.9%) or 0% for 4 months
Monthly Payment: £95.36
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,109.48
Total inc. interest: £1,144.31
Monthly Payment: £49.05
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,109.48
Total inc. interest: £1,177.10
Monthly Payment: £33.63
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,109.48
Total inc. interest: £1,210.46
Monthly Payment: £25.93
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,109.48
Total inc. interest: £1,244.49
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 21.9% and may be even lower.

Representative Example:

Purchase Rate: 21.9% p.a. (variable)

Representative: 21.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £27.71 / month (APR 15.9%)
Delivery Options
  • By DPD On 23rd May to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview

Intel Xeon E-2300 Processors

Small businesses require reliability and security to support their critical business and customer data needs. Available with up to eight cores and featuring a TDP of up to 95 watts, Intel Xeon E-2300 processors deliver essential server performance, expandability and reliability small businesses to support critical business and customer data needs.


PCIe 4.0 Ready

PCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. ASUS RS300-E11 servers are PCIe 4.0 ready to support a diverse array of graphics, storage and networking – enabling flexible scalability for demanding or increasing workloads.


Redundant Platinum PSU Support

RS300-E11-RS4 supports redundant 450W 80 PLUS Platinum power supplies, which are 96%+ efficient, directly reducing operating costs and capital expenses. The 1+1 power-supply design allows the server to keep working even if one power supply requires maintenance, enabling uninterrupted operation.


Enhanced Security

ASUS RS300-E11 servers integrate PFR FPGA as the platform Root-of-Trust solution for firmware resiliency to prevent from hackers from gaining access to infrastructure. ASUS security solutions are fully compliant with the 2018 National Institute of Standards and Technology (NIST) SP 800 193 specification.

In addition, all RS300-E11 servers also include support Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.


Dual Ethernet Bandwidth

Featuring dual onboard LAN ported by Intel I210-AT Ethernet Controller, RS300-E11 server provides server-grade connectivity and supports high-density, high-bandwidth, low-latency access-layer networks to ensure faster transfers of large-size files used in data-intensive applications


ASUS ASMB10-iKVM

ASUS ASMB10-iKVM is the latest server-management solution from ASUS, built upon the ASPEED 2600 chipset running on the latest AMI MegaRAC SP-X. The module provides various interfaces to enable out-of-band server management through WebGUI, Intelligent Platform Management Interface (IPMI) and Redfish® API.


ASUS Control Center

ASUS Control Center (ACC) is a centralized and integrated IT-management platform for monitoring and controlling ASUS servers, workstations and mini PCs. ACC enables remote BIOS updates, monitoring of multiple systems via mobile devices, and one-click software updates and dispatching, allowing easier server management for any IT infrastructure.

Features


• Ideal for remote office/branch office (ROBO) use and everyday business environments.
• Powered by eight-core Intel Xeon E-2300-series processor with support for up to 95 W TDP.
• Four 3.5” or 2.5” hot-swap drives on front panel and one M.2 to enable extensive storage.
• Up to two PCIe® 4.0 slots and one PCIe® 3.0 proprietary slot to drive higher bandwidth.
• High power efficiency with redundant 450 W 80 PLUS Platinum power supplies.
• Dual Intel I210AT Gigabit Ethernet with teaming support.
• Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller.
• Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency.

Specifications
Edition RS300-E11-RS4/450W
Form Factor 1U Rackmount
CPU Included No
CPU Type Intel Xeon
CPU Model E-2300 Family
Architecture
Manufacturing Process
Unlocked CPU No
Core
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
Max. TDP
CPU Socket 1200
Chipset Intel C242
Motherboard Form Factor Proprietary
Motherboard Model
Memory Type DDR4
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels Dual (2)
Memory Type (ECC) ECC/Non-ECC
Memory Type (R/U) UDIMM (Unbuffered)
Memory Speed (Mhz)
  • DDR4 - 2400
  • DDR4 - 2666
  • DDR4 - 2933
  • DDR4 - 3200
Max. Memory Capacity 128GB (4x32GB)
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip Aspeed® AST2600
Discrete GPU No
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration No
Max. GPU Resolution
Graphics Interface PCIe 3.0 (x16)(x8 Bandwidth)
Expansion Slots
  • 1 x M.2, 22-42/60/80/110, PCIe
  • 1 x M.2, 22-42/60/80/110, PCIe/SATA
  • 1 x PCIe 3.0 x16 (x8 Bandwidth)
  • 1 x PCIe 3.0 x8 (x4 Bandwidth)
  • 1 x PCIe 4.0 x16
  • 1 x PCIe 4.0 x8, via Riser, HH, HL
SATA SATA3
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Optical Drive None - Includes Slim Optical Drive Caddy/Bay
Drive Bays
  • 2 x 2.5" Internal
  • 2 x 2.5"/3.5" NVMe/SATA/SAS Hot-Swap (Front)
  • 4 x 2.5"/3.5" SATA/SAS Hot-Swap (Front)
Backplane I/O 4 x SAS/SATA Ports (Front)
RAID Support Support Software RAID 0, 1, 5, 10
Internal I/O N/A
Network Interface Type Dual Wired Gigabit LAN (10/100/1000) + Mgmt LAN
Network Chip/Modules
  • 2 x Intel® I210AT (Gigabit LAN)
  • 1 x Mgmt LAN
Front Panel
  • 2 x USB 3.2 Gen1 Type-A
  • 1 x VGA
Back Panel
  • 1 x HDMI
  • 2 x RJ-45
  • 1 x RJ-45 Mgmt LAN
  • 1 x Serial (COM)
  • 2 x USB 3.2 Gen2 Type-A
  • 1 x VGA
Cooling Fans 4 x 40mm
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 450 W
PSU Efficiency Rating
PSU Redundancy 1+1
Operating System Included No
Operating System O/S Not Included - Please Buy Separately
Colour Black
Dimensions 497 x 44 x 439.5 (mm WxHxD)
Weight
Includes 2 x UK Power Cable
