Scan code: LN75246 Manufacturer code: SST-ST30SF v2.0

SFX Series SST-ST30SF 300W SFX PSU from Silverstone

300W Silverstone SFX Series ST30SF v2.0, 80PLUS Bronze, Fully Wired, Single Rail, 25A +12V, 1x92mm Quiet Fan

Thumbnail 1 : SFX Series SST-ST30SF 300W SFX PSU from Silverstone Thumbnail 2 : SFX Series SST-ST30SF 300W SFX PSU from Silverstone Thumbnail 3 : SFX Series SST-ST30SF 300W SFX PSU from Silverstone Thumbnail 4 : SFX Series SST-ST30SF 300W SFX PSU from Silverstone
Scan code: LN75246 Manufacturer code: SST-ST30SF v2.0
£49.99Item due on 28 January 2022
Due 28th Jan
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview

SFX Series - The Reference SFX Power Supply

As the standards bearer of SFF (small form factor) cases and SFX PSUs, SilverStone has released a reference power supply design for the masses in the ST30SF, a 300W SFX unit designed with high affordability and great performance. It has 80 PLUS Bronze efficiency and a silent running fan for class leading efficiency and low noise.To enable users to easily take advantage of this excellent SFX power supply, an adapter is included to convert ST30SF to mount in any ATX case in addition to ones that fit only SFX. For SFF users, the ST30SF is an excellent, well-rounded power supply for any DIY desktop computer.

Features
• Intelligent semi-fanless operation (V1.0 only).
• Supports standard SFX form factor and ATX via included bracket.
• 300W continuous power output at 40° temperature rated for 24/7 operation (V2.0).
• 80 PLUS Bronze level efficiency (82% ~ 85% efficiency at 20% ~ 100% loading).
• Class-leading single +12V rail.
• Silent running 80mm fan (V1.0).
• Silent running 92mm fan (V2.0).
• Single PCI-E 6pin connectors support.
• Active PFC.
Specifications
Size SFX
Edition SFX Series ST30SF
Wattage 300 W
80 PLUS Certification 80 PLUS Bronze
Max. Efficiency (at 230Vac) 82%~85% %
Cooling Fan
Fans 1 x 92mm
Internal +12V Rails Single Rail
Rail 1 +12V 25 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V 25 A
Modular No
Modularity Fully Wired
SLI/CrossFire No
EPS 12V No
Motherboard Connector 20+4-pin
Connectors
  • 1 x 4+4-pin CPU +12V (EPS)
  • 1 x 4-pin FDD Power
  • 2 x 4-pin Molex
  • 1 x 6-pin PCIe
  • 3 x SATA
Dimensions 125 mm × 63.5 mm × 100 mm (WxHxD)
Package Type
Additional Information
Scan Code LN75246
Model Number SST-ST30SF v2.0
GTIN 4710007224304
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
SilverStone Technology GmbH
Telephone:
Carsten Buss Tel.: +49 40 675931-35
