Silverstone Sugo SG05BB-Lite Mini ITX Case
Silverstone Sugo SG05BB-Lite Mini ITX Case
Scan code: LN50925 Manufacturer code: SST-SG05BB-Lite USB 3.0
£44.99Item currently awaiting an ETA
Pre Order
Pre order
  • Thumbnail 1 : Silverstone Sugo SG05BB-Lite Mini ITX Case
  • Thumbnail 2 : Silverstone Sugo SG05BB-Lite Mini ITX Case
  • Thumbnail 3 : Silverstone Sugo SG05BB-Lite Mini ITX Case

Silverstone Sugo SG05BB-Lite Mini ITX Case

Silverstone SG05BB-Lite USB 3.0 Sugo SFF mini-ITX Case All Black 120mm Silent Fan w/o PSU (SFX)
MORE INFO
MORE INFO

Scan code: LN50925 Manufacturer code: SST-SG05BB-Lite USB 3.0
£44.99
£5.48 Next day delivery
Item currently awaiting an ETA
Pre Order
Pre order
Pay in 3 interest-free payments of £15.00

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores

Finance this product

  • Spend over £390.00 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
  • SCANPROTECT Protect against installation damage for 28 days.
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan.
Product Overview

A Revelation

Introduced in 2009, the Sugo SG05 was a revelation for a form factor originally destined for low powered computing. Designed for use with Mini-DTX and Mini-ITX motherboards, the SG05 was capable of swallowing many standard components while keeping everything cooled.


Breakthrough Design

It was the first Mini-ITX case in its size class equipped with Quiet 120mm fan and capable of accommodating 10 inch long graphics card. This breakthrough design allowed anyone to build a fast and affordable PC in a case smaller than a shoebox. With SFX power supplies becoming more popular thanks to the success of SG05 and subsequent case designs, SilverStone has decided to release a version of SG05 called, “SG05-Lite” that comes without an SFX power supply included. This bare chassis model will enable more affordable price and give users greater flexibility in choosing components.

Features
• Ample space for CPU cooling (82mm in height).
• Elevated standoff for motherboard back side components.
• Unprecedented 120mm fan in mini casing for positive pressure cooling.
• Support 2.5” and 3.5” hard drives.
• Mini-DTX / Mini-ITX motherboard & SFX PSU compatible.
• Standard-length expansion cards support (10 inches).
Specifications
Core Chassis Specifications
Case Edition Silverstone SG05BB-Lite
Case Form Factor Small Form Factor (SFF)
Motherboard Form Factor
  • Mini-DTX
  • Mini-ITX
Back Connect Compatible No
I/O, Bays & Expansion
Front/Side/Top Panel I/O
  • 1 x Headphone Out
  • 1 x Mic In
  • 2 x USB 3.0
Drive Bays
  • 1 x 2.5" Internal
  • 1 x 3.5" Internal
  • 1 x Slim Optical
Standard Expansion Slots
Vertical Expansion Slots
Fans & Filters
Fan Bays 1 x 120mm
Fans Included 1 x 120mm
Fan Controller/Hub
Dust Filters
Liquid Cooling Support
Front Radiator Compatibility
Top Radiator Compatibility
Bottom Radiator Compatibility
Rear Radiator Compatibility
Side Radiator Compatibility
Clearances
Max CPU Cooler Height
Max GPU Card Length
Cable Routing Space
Side Panels
Window/s No
Window Configuration
Window Construction
LED Lighting Functionality
LED Lighting No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control
Power Supply Compatibility
PSU Included No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support SFX
PSU Mounting Location Top Mount, Rear
Max PSU Length
Chassis Physical Specifications
Colour Black
Chassis Construction Materials Plastic
Front Panel Type Mesh
Dimensions 222 x 176 x 276 (WxHxD mm)
Weight
Package Type Retail
Please Note
Additional Information
Scan Code LN50925
Model Number SST-SG05BB-Lite USB 3.0
GTIN 4710007220337
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
SilverStone Technology GmbH
Telephone:
Carsten Buss Tel.: +49 40 675931-35
Loading Please Wait

Please wait . . .

Buying Guide
Not sure which case is right for you? Read our Case Buying Guide
Computer Cases
Computer Cases
Date Issued: 6th Jul 2011

There's more choice than ever before, but which computer case is right for you and which features should you look out for?

Read More

Chassis Airflow
Chassis Airflow
Date Issued: 20th Oct 2008

The modern PC is potentially a mass of heat output and heat production hot spots. With CPUs rated at more than 100W of heat output, single graphics boards carrying similar ratings (and people want to run two!), multiple hard drives the norm, lots of memory and mainboards covered in heatpipes to combat toasty core logic and PWM circuits, a PC appreciably warming up a room when it’s working hard is no joke.

Read More

Silverstone SG05BB-Lite USB 3.0 Sugo SFF mini-ITX Case All Black 120mm Silent Fan w/o PSU (SFX) is rated 4.7 out of 5 by 3.
Rated 5 out of 5 by from Great case for the price This is a great case for your mini itx board. I've installed a laptop type dvd writer in the hidden aperture. Everything fits well with space for 3.5" and a 2.5" cage for drives There's plenty of clearance between the cpu fan and the PSU (not included in the price but wouldn't expect it to be!). Simple 2 button operation on the front (power and reset) and 2 blue led's (power status and hdd access). The front USB3's have a mounded plug that connects to a standard USB3 motherboard socket Overall very pleased with the case. the only downside is the metal thickness. It does feel a little flimsy when dismantled for pc assembly, but once assembled it is very sturdy. (I've bought 2 of these!)
Date published: 2015-06-28
Rated 4 out of 5 by from Tiny and well laid out but a bit flimsy. + You will not find a smaller case that can fit a proper GPU so if you want the smallest SFF box then this is your best choice. It is well laid out, very small and looks pretty nice. + Despite only having one, 120mm fan mount, I do not have cooling issues, even with a 4690K, AIO water cooler and a GTX 970. - The general quality of this case leaves a bit to be desired. I can't really complain, given the price of this case, but the case does flex quite a bit, the paint finish isn't fantastic and the front panel I/O cables are nasty colours. - I don't like the fact that the ODD tray and 3.5 inch drive bay are the same thing and cannot be separated without the use of some tools. This caused me issues as I had to buy an external CD/DVD drive because the ODD tray does not fit with the radiator of my water cooler.
Date published: 2014-11-30
Rated 5 out of 5 by from Great for a HTPC / Mini server The case is great for anyone looking at building a mini server or a HTPC for the living room, plenty of space in the case for cable management.
Date published: 2014-02-03
  • y_2020, m_9, d_10, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_3
  • loc_en_GB, sid_50925, prod, sort_[SortEntry(order=FEATURED, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_scan

PSU Support

Will this case support a micro atx power supply or a standard one?
Asked by: DanL94
This case will only support SFX form factor power supplies. As far as models are concerned, these are your two best options: - http://www.scan.co.uk/products/450w-silverstone-sst-st45sf-g-strider-sfx-modular-80plus-gold-psu - http://www.scan.co.uk/products/600w-silverstone-strider-sst-sx600-g-sfx-80-plus-gold-psu
Answered by: SinkDemon
Date published: 2015-07-17
