Scan code: LN113388 Manufacturer code: ACFAN00222A

Arctic P14 Static Pressure 140mm PWM Fan White

140mm Arctic P14 PWM, 5 Blade, Static Pressure Fan, 1700rpm, 72.8CFM, Fluid Dynamic Bearing, White,4-pin

Thumbnail 1 : Arctic P14 Static Pressure 140mm PWM Fan White Thumbnail 2 : Arctic P14 Static Pressure 140mm PWM Fan White Thumbnail 3 : Arctic P14 Static Pressure 140mm PWM Fan White Thumbnail 4 : Arctic P14 Static Pressure 140mm PWM Fan White
Scan code: LN113388 Manufacturer code: ACFAN00222A
£7.99
Order now and get it tomorrow, Wed 16th Jun
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 16th Jun to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Optimised for Static Pressure

During the development of the new P14 PWM, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the P14 PWM is particularly suitable for use on heatsinks and radiators.


More Efficient Technology

The motor is powered by a Neodym-Iron-Boron-Magnet ring of the newest generation, which allows the new P14 PWM to run much more efficiently than its predecessors. This saves energy and lowers the coil temperature without comprimising the performance.


Maximum Quietness, Minimum Vibration

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable.
Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter.
Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor.


Extended Life Span

A 10 °C lower motor temperature roughly doubles the life span of a fan.
The new ARCTIC motor has a four times longer service life through its low coil temperature.
Consequently, we have extended the warranty to 10 years.


200 to 1700 RPM Regulated via PWM

Thanks to the 4-pin connector, the RPM can be regulated in a broad spectrum via PWM.
In this way, noise is kept at a minimum while maximum cooling performance is guaranteed when needed.


High Quality Bearing

Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.


Two Way Installation

Push warm air out of the case, Pull cool air into your case

Features

• Optimised for static pressure
• Ideal choice on heatsinks, radiators and (partly-) covered case vents
• PWM signal adjusts fan speed
• Newly developed, very quiet motor
Specifications
Pack Information
Edition P14 PWM
Pack Type Single (1) Fan Standalone Pack
Includes 1 x 140mm Fan/s
Individual Fan Specifications
Fan Diameter 140mm
Fan Depth 27 mm
Fan Speed 1700 rpm
Fan Blades 5
PWM Yes
Fan Specialization Static Pressure
Airflow 72.8 CFM
Air Pressure 2.4 mm H²O
Sound Level (dBA)
Sound Level (Sone) 0.3 @1700 rpm Sone
Motor Type
Bearing Type Fluid Dynamic Bearing
Manual Speed Controller No
Material Plastic
Fan Colour White
LED No
LED Colour
MTBF
Fan Fixing Screw Fixing
Cable length
Connectors 1 x 4-pin
Additional Information
Scan Code LN113388
Model Number ACFAN00222A
GTIN 4895213703093
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Warranty information has not yet been updated for this product. For further information please call 0871 472 4747 or 01204 474747.
